Tricity Bendix, 55-77 High Street, Slough, Berkshire SL1 1DZ Consumer care telephone number……08705 950950 OPERATING AND INSTALLATION INSTRUCTIONS FRIDGE-FREEZER FD 845 S © Electrolux plc 2005 2223 277-51
IMPORTANT SAFETY INFORMATION It is most important that this instruction book should be retained with the appliance for future reference. Should the appliance be sold or transferred to another owner, or should you move house and leave the appliance, always ensure that the book is left with the appliance in order that the new owner can get to know the functioning of the appliance and the relevant safety information. This information has been provided in the interest of safety.
CONTENTS Instructions for the User Important Safety Information 2 Instructions for the Installer Operation 4 Technical Specification 13 Before use 4 Installation 14 Setting the temperature 4 Positioning 14 Freezing fresh food 4 Shelf holders 14 Storage of frozen food 4 Electrical Connection 15 Thawing 5 Making ice cubes 5 Rear spacers 16 Fresh food refrigeration 5 Door Reversal 16 Movable shelves 6 Freezing calendar 6 Hints and Tips 7 Maintenance and Cleaning 8 Inter
OPERATION Before using Remove all securing tapes. Wash inside the appliance with lukewarm water and bicarbonate of soda (5 ml to 0.5 litre of water). Do not use soap or detergent as the smell may linger. Dry thoroughly. Setting the temperature The temperature inside the refrigerator is regulated by a thermostat with 6 temperature positions and one «OFF» (O) position. Position 1 = minimum coldness Position 6 = maximum coldness Turn the thermostat dial to the required position.
Rear spacers The plastic bag containing all relevant documentation also contains two spacers to be fitted into special holes in the back of the appliance. Fit the spacers into the holes, taking care to ensure that the arrow (A) is positioned as shown in Fig. Then turn them through 45° (arrow (A) vertical) until they lock into place. A 45° PR60 Door reversal 2.
Movable shelves Electrical connections The walls of the refrigerator have runners so that shelves can be positioned as desired. Any electrical work required to install this appliance should be carried out by a qualified electrician or competent person. WARNING: THIS APPLIANCE MUST BE EARTHED. The manufacturer declines any liability should this safety measure not be observed. D040 For replacement, use a 13amp BSI362 fuse. Only ASTA or BSI approved fuses should be used.
HINTS AND TIPS INSTALLATION Warning IF YOU ARE DISCARDING AN OLD APPLIANCE THAT HAS A LOCK OR CATCH ON THE DOOR, YOU MUST ENSURE THAT IT IS MADE UNUSABLE TO PREVENT YOUNG CHILDREN BEING TRAPPED INSIDE. Depending upon the position which you choose for your appliance, you may wish to reverse the way in which the door opens. To do this, refer to instructions on “Door reversal directions” paragraph.
MAINTENANCE AND CLEANING Before any maintenance or cleaning work is carried out, DISCONNECT the appliance from the ELECTRICITY supply. Internal cleaning TECHNICAL SPECIFICATIONS Changing the light bulb Should the interior light fail to work, first switch off the appliance and disconnect from the electricity supply, then replace the bulb as follows; DIMENSIONS Clean the inside and accessories with warm water and bicarbonate of soda (5ml to 0.5 litre of water). Rinse and dry thoroughly.
GUARANTEE CONDITIONS Standard guarantee conditions We, Tricity Bendix, undertake that if within 12 months of the date of the purchase this Tricity Bendix appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option repair or replace the same FREE OF CHARGE for labour, materials or carriage on condition that: The appliance has been correctly installed and used only on the electricity supply stated on the rating plate.
SOMETHING NOT WORKING Important: If the appliance is not working correctly, please carry out the following checks before calling out an engineer. Symptom Solution No power to the appliance Check there is power at the socket.
