OPERATING & INSTALLATION INSTRUCTIONS MICROWAVE OVEN TRIC750E
t TRIC750E Contents Before using your microwave oven 4 Safety instructions – Utensil safety – Testing suitability of cookware – Food safety – Oven utensils and accessories guide Technical data 4 4 5 5 6 6 Getting Started – Unpacking Installation – Connecting to the mains 7 7 7 7 Electrical connections 8 How to operate your microwave oven – Name and function of parts – Turntable Installation – Control panel – MAFF Rating – Microwave cooking – Microwave Power setting Guide – Defrosting instructions
t TRIC750E 'SRKVEXYPEXMSRW SR XLI TYVGLEWI SJ ]SYV RI[ 1MGVS[EZI 3ZIR Thank you for having chosen a Tricity product. We are convinced that you will find your new microwave oven very useful and that it will be of great help to you. As with all new kitchen appliances, it will take some time to learn all the new functions and features, but with time, this oven will become indispensable to you.
t TRIC750E Testing suitability of cookware • • • • • • • Food safety • Place the cookware in the microwave along with a glass half full of water. Heat on 750 W (100%) for one minute. If the cookware feels hot, you should not use it. If it is just slightly warm, you can use it for reheating but not for cooking. If the dish is room temperature, it is suitable for microwave cooking. Paper napkins, wax paper, paper towels, plates, cups, cartons, freezer wrap and cardboard are great convenience utensils.
t TRIC750E Oven utensils and accessories guide A variety of Utensils and Materials may be used for cooking in your microwave oven. For your safety and to prevent damaging utensils and your oven choose appropriate utensils and materials for each cooking method. The list below is a general guide.
t TRIC750E GETTING STARTED Unpacking Connecting to the mains N.B. When you unpack the oven, check that the product is free from damage. Damage or any missing parts must be reported immediately to the retailer. The oven, parts of the oven or the accessories may be wrapped by a protection foil. If so, you must remove this foil before using the oven. Do not leave packing material so that small children can play with it. This can be hazardous.
t TRIC750E Electrical connections WARNING! THIS APPLIANCE MUST BE EARTHED. The manufacturer declines any liability should this safety measure not be observed. • If the plug that is fitted to your appliance is not suitable for your socket outlet, it must be cut off and the appropriate plug fitted. • Remove the fuse from the cut off plug. The cut off plug should then be disposed of to prevent the hazard of shocks in case it should be plugged into a 13 Amp socket in another part of your home.
t TRIC750E How to operate your microwave oven 2 1 3 5 6 4 4 7 8 Name and function of parts Turntable Installation 1. Cooking compartment. Wipe the compartment clean after using the oven. 2. Viewing window. Food can be checked while the microwave oven is in operation. 3. Oven door. The door must always be firmly closed while cooking. 4. Latch hook & Safety interlock system. 5. Control panel. 6. Drive shaft for turntable. 7. Turntable. Made of special heat-resistant glass.
t TRIC750E CONTROL PANEL 1. Display Window To view either Cook time or Power level 2. Start Button To start your microwave 3. Stop/Clear Button To stop or pause your Microwave 1 4. Power setting Button To set the desired power level Power + increases from 10% - 100% Power - decreases from 100% - 10% 5. Setting control knob To set the desired time or to set auto defrost 2 6.
t TRIC750E MICROWAVE COOKING 1. Open the door, place the food on the turntable. Close the door. To turn off the oven during cooking, simply touch the Stop/Clear button. 2. Press the Power setting button until the desired power level is reached.(See table below.) Note: After use, be sure to press the Stop/Clear button Twice as this will ensure that you have reset the microwave. 3. Set the desired time by turning the setting control knob clockwise.
t TRIC750E Defrosting instructions using 75W Some foods such as bread and fruit, can successfully be thawed manually by using this power setting. FOOD (75W) STANDING TIME 18–20 min. 10–15 min. 20–23 min. 10 min 55–60 sec. 55–60 sec. 2–2 ½ min. 5 min. 5 min. 5 min. Remove from packaging, place on plate. 19–21 min. 15–30 min. Remove from packaging, place on plate. 19–21 min. 15–30 min. Remove from packaging, place on plate. 17– 19 min. 15–30 min. Remove from packaging, place on plate.
t TRIC750E Automatic Defrost 1. Open the door, place the food on the turntable. Close the door. To turn off the oven during cooking, simply touch the Stop/Clear button. 2. Set the desired weight by turning the setting control knob anti - clockwise. The oven will now be in defrost mode. NOTE : After use, be sure to press the Stop/Clear button Twice as this will ensure that you have reset the microwave. 3. Press Start (The oven begins defrosting.
t TRIC750E Microwave Hints • • • • • • • • • • • • • • • • • Microwave Tips Always keep the oven clean – avoid spill-overs and do not forget to clean under the glass tray and the inside of the door. Preferably use round or oval casseroles with a lid when cooking in your microwave oven. Do not use metal or metal decorated casseroles. Certain plastic materials can melt and be warped by hot food. Cover the food when cooking. Use a glass lid, a plate or grease proof paper.
t TRIC750E Care and cleaning The oven must always be clean. Residue of food from spillovers or spatters will attract microwave energy causing it to burn on. This could reduce the efficiency of the oven and may cause bad odours. Do not attempt to tamper with or make any adjustments or repairs to any part of the oven. Repairs should only be done by a qualified service technician. Be sure the oven is disconnected from the electricity supply before cleaning.
t TRIC750E 16
t TRIC750E 17
t TRIC750E 18
82219213-12-01
