READ AND SAVE THESE INSTRUCTION MANUAL CONTENTS TECHNICAL CHARACTERISTICS---------------------------------1 MAIN PARTS NAME--------------------------------------------------2 INSTALLATION REQUIREMENT-----------------------------------3 INSTALLATION PROCEDURES--------------------------------- 4-5 OPERATION INSTRUCTION--------------------------------------5-8 INSTALLATION-------------------------------------------------------8 MAINTENANCE-------------------------------------------------------9 TO REPLACE THE
TROUBLE SHOTTINGS CAUTION: Disconnect the power supply before servicing. STATUS CAUSE & METHOD OF REPAIRING The power supply is damaged If the power supply is damaged, please call the technician to repair. The motor does not run A). The fan was blocked, check the fan make sure it is in the correct place. B). The motor was blocked, check the motor and make sure it’s in the correct place. C). The motor was broken, replace a new one. D). The switch was broken, replace a new one. E).
MAIN PARTS NAME Hook Hook Inner duct cover Inner duct cover Outer duct cover Exhaust pipe Outer duct cover Exhaust pipe Air outlet Blower box Blower box Glass Filter Filter 9
8
7
OPERATING INSTRUCTION Expanding Tube 5x50 Metal Screw C Hook 200 367 A B Step5: A ccording to the size of hook key holes. Drill 3 holes in level in the wall with 10mm in diameter and 75~85mm in depth. Press the 3 expanding tube provided into the holes. Fix the hook using the 5x50 metal screw provided. Then insert three M5X50 screws to A and B And C holes to fix the hook on the wall steadily. Step 6: Hang the entire hood onto the hook, ensure the hood is level and vertical.
