Owner’s Manual

1111 W. 35th Street Chicago, IL 60609 USA

Customer Support: (773) 869-1234 • www.tripplite.com

Important Safety Instructions

Mounting

Quick Installation

Basic Operation

Storage and Service

Audio/Video

Automatic Voltage Regulation (AVR)

UPS Systems

• Intelligent, Line-Interactive Operation • Sine-Wave Output*

• 500VA - 1500VA Capacities • Extended-Run Options

* Except 500VA: sine wave output on line; PWM output on battery.

Not suitable for mobile applications.

Battery Replacement

Optional Installation

WARRANTY

REGISTRATION

to win a FREE Tripp Lite product!

www.tripplite.com/warranty

Warranty Registration

200507083 93-2477 Sinewave SmartPro Rackmount UPS OM.qxd 10/19/2005 10:35 AM Page 1

Summary of content (12 pages)

PAGE 1
200507083 93-2477 Sinewave SmartPro Rackmount UPS OM.qxd e TY N chanc t! N c O A a du I RR RAT ay forte pro nty A i d T L W IS e to p warra G lin Trip m/ REter on REE lite.co F gis a ipp Re win w.tr to ww 10/19/2005 10:35 AM Owner’s Manual Audio/Video Automatic Voltage Regulation (AVR) UPS Systems • Intelligent, Line-Interactive Operation • Sine-Wave Output* • 500VA - 1500VA Capacities • Extended-Run Options * Except 500VA: sine wave output on line; PWM output on battery.
PAGE 2
00507083 93-2477 Sinewave SmartPro Rackmount UPS OM.qxd 10/19/2005 10:35 AM Important Safety Instructions SAVE THESE INSTRUCTIONS This manual contains important instructions that should be followed during the installation, operation and storage of all Tripp Lite UPS Systems. Failure to heed these warnings will void your warranty. UPS Location Warnings • Use caution when lifting UPS.
PAGE 3
200507083 93-2477 Sinewave SmartPro Rackmount UPS OM.qxd 10/19/2005 10:35 AM Rack Mounting Mount your equipment in either a 4-post or 2-post rack or rack enclosure (see next page for 2-post mounting). The user must determine the fitness of hardware and procedures before mounting. If hardware and procedures are not suitable for your application, contact the manufacturer of your rack or rack enclosure.
PAGE 4
200507083 93-2477 Sinewave SmartPro Rackmount UPS OM.qxd Rack Mounting 10/19/2005 10:35 AM continued 2-Post Mounting Mount 1U UPS models in 2-post racks with included hardware following the procedure below. If you mount 2U UPS models in 2-post racks, they require the addition of a Tripp Lite 2-Post Rackmount Installation Kit (model: 2POSTRMKITWM, sold separately). See Installation Kit owner’s manual for installation procedure for 2U UPS models.
PAGE 5
200507083 93-2477 Sinewave SmartPro Rackmount UPS OM.qxd Quick Installation 1 Plug the UPS into an outlet on a dedicated circuit.* NOTE! after you plug the UPS into a live AC outlet, the UPS (in “Standby” mode) will automatically charge its batteries,** but will not supply power to its outlets until it is turned ON (see Step 3 below). * Select models include an additional plug which can be switched by a qualified electrician. ** The BATTERY CHARGE LED will be the only LED illuminated.
PAGE 6
200507083 93-2477 Sinewave SmartPro Rackmount UPS OM.qxd 10/19/2005 10:35 AM Optional Installation These connections are optional. Your UPS will function properly without these connections. 1 USB and RS-232 Serial Communications (all models) Use the included USB cable (see 1a ) and/or DB9 serial cable (see 1b ) to connect the UPS to a Media Center PC, home automation system or server. Install the Tripp Lite PowerAlert Software appropriate to your equipment's operating system.
PAGE 7
200507083 93-2477 Sinewave SmartPro Rackmount UPS OM.qxd 10/19/2005 10:35 AM Basic Operation Buttons (Front Panel) “ON/OFF/STANDBY” Button • To turn the UPS ON: with the UPS plugged into a live AC wall outlet*, press and hold the “ON/OFF/STANDBY” button for one second.** Release the button. If utility power is absent, you can “cold-start” the UPS (i.e.: turn it ON and supply power for a limited time from its batteries***) by pressing and holding the “ON/OFF/STANDBY” button for one second.
PAGE 8
200507083 93-2477 Sinewave SmartPro Rackmount UPS OM.qxd Basic Operation 10/19/2005 10:35 AM continued Indicator Lights (Front Panel) All Indicator Light descriptions apply when the UPS is plugged into a wall outlet and turned ON. “POWER” LED: this green LED lights continuously when the UPS is ON and supplying connected equipment with AC power from a utility source.
PAGE 9
200507083 93-2477 Sinewave SmartPro Rackmount UPS OM.qxd Basic Operation 10/19/2005 10:35 AM continued Other UPS Features (Rear Panel) 15 amp/120V NEMA 5-15R AC Receptacles: Your UPS features 15-amp AC outlets, and select models also feature 20-amp and 30- amp AC outlets. These output receptacles provide your connected equipment with AC line power during normal operation and battery power during blackouts and brownouts.
PAGE 10
200507083 93-2477 Sinewave SmartPro Rackmount UPS OM.qxd Basic Operation 10/19/2005 10:35 AM continued Accessory Slot: Remove the small cover panel from this slot to install optional accessories to remotely monitor and control your UPS. Refer to your accessory’s manual for installation instructions. Contact Tripp Lite Customer Support at (773) 869-1234 for more information, including a list of available SNMP, network management and connectivity products.
PAGE 11
200507083 93-2477 Sinewave SmartPro Rackmount UPS OM.qxd 10/19/2005 10:35 AM Storage and Service Storage Before storing your UPS, turn it completely OFF: with the UPS ON and receiving utility power, press and hold the "ON/OFF/STANDBY" button for one second (an alarm will beep once briefly after the interval has passed); then, unplug the UPS from the wall outlet.
PAGE 12
200507083 93-2477 Sinewave SmartPro Rackmount UPS OM.qxd 10/19/2005 10:35 AM Battery Replacement Under normal conditions, the original batteries in your UPS will last many years. See Safety section before replacing batteries. The batteries are designed for hot-swap replacement (i.e. leaving the UPS in ON mode), but some qualified service personnel may wish to put the UPS in the OFF mode and disconnect equipment before proceeding.
