Model #: P516-001-HR
1-ft. High-Resolution SXGA/UXGA Monitor Y Splitter Cable, (HD15M / 2xHD15F)
Highlights
Splits the SXGA/UXGA signal providing simultaneous display of the same
image on two monitors
HD15 Male splits to 2 HD15 Female, 1 ft.
Description
Tripp Lite's 1 ft. SXGA/UXGA Monitor "Y" Splitter cable provides an inexpensive alternative for splitting the video signal from your PC's VGA port to 2
High-Resolution monitors that use standard 15-pin plugs. 75-ohm coax conductors used for RGBHV signals allow for use with monitors with up to
1600 x 1200 resolutions. Perfect for laptops to display on a separate, larger monitor. Use for short distance applications only. For applications that
require longer distances and highest resolution, see Tripp Lite B114-002-R, powered 2-Port Splitter, or, B114-0H4, powered 4-port Splitter.
Applications
Presentations that require multiple monitors for easier viewing
System Requirements
PC/MAC with 15-pin Female VGA CPU port
Package Includes
1-ft. SXGA/UXGA Hi-Res Splitter Cable, HD15M to 2 x HD15F
Features
HD15 Male to 2 x HD15 Female w/Hex Nuts
RGB cable construction supports resolutions up to 1600 x 1200
Molded, double-shielded construction for maximum EMI/RFI protection
Two monitors display the image from one PC
Inexpensive solution for presentations
Specifications
OVERVIEW
Intended Application Connecting Peripherals
Cable Type MONITOR
Display Style Splitter
