Specification

1000W PowerVerter Compact Inverter for Trucks
with 4 Outlets
MODEL NUMBER: PV1000HF
Description
Utilize your vehicle's battery to efficiently power office equipment on the road or power tools at a work site. Continuously supplies up to 1000 watts of 120V AC
power to 4 AC outlets from any 12V battery. Includes a set of DC terminals for simple installation. Compact, lightweight metal case design is among the
smallest, most rugged inverters available at this power level.
NOTE: To protect against high current draw that may occur during inverter failure, a fuse link rated at 175a should be positioned no more than 18" from the
PV1000HF's battery in the positive line.
Features
Allows users to run AC appliances from any properly-sized 12V battery or automotive DC system
Converts 12V DC battery power to 120V AC power
1000 watts continuous output power; 2000 watts peak output power (instantaneous)
4 outlets
Compact, lightweight design with all-metal housing
Remote control jack provides optional remote monitoring and control when used with optional remote module (APSRM4, sold separately)
Low battery alarm with auto-shutoff prevents deep battery discharge
High-efficiency operation conserves batteries to prolong run time
Battery charge level LEDs indicate the approximate charge level (high/medium/low) of connected batteries
Connected load level LEDs indicate the approximate wattage load level (high/medium/low) of connected equipment
Operating mode switch controls inverter operation
Battery Charge Conservation Dial conserves battery power by setting the load-level at which the inverter automatically shuts off
Cooling fan regulates internal temperature and prolongs service life
Mounting flanges provide safe, fixed installation
Grounding lug connects to vehicle ground
Grooved cooling surface provides additional surface area for more efficient cooling
Highlights
12V DC input; 120V AC output; 4
outlets
1000 watts continuous output
2000 watts peak output
(instantaneous)
Powers an entire mobile office
Package Includes
PV1000HF Inverter
Warranty information
Instruction manual
