How to Guide

tritontools.com
TCM PL
Compact Palm Planer
Voltage
230V 50 Hz 120V 60Hz
Power 420W 3.5A
No Load Speed 13000rpm
Planing Depth 1.5mm
1
⁄16"
Planing Width 60mm 2
3
⁄8"
Blade Type
2 x Reversible 60mm HSS 2 x Reversible 2
3
⁄8" HSS
Weight
2.4kg 5.3lbs
Key SpecificationsSelling Points
• Efficient 420W / 3.5A motor
• 2 x 60mm / 2
3
⁄8
" planing width
• 0 - 1.5mm / 0 -
1
⁄16
" adjustable planing depth
• Rubber over-moulded grip increases control & safety
• Twin V-groove increases range of edge bevelling depths
• Automatic park foot automatically folds away when planing
• Compact design for single-handed use
• 2 x 60mm / 2
3
⁄8
" HSS Reversible Blades
• Extraction Adaptor
• Hex Key
• Blade Removal Hex Spanner
• 2 x Drive Belts
What's in the Box
Compact yet powerful palm planer, which is light, easy-to-handle and includes all the features of a conventional sized planer and more. Utilising twin 60mm /
2
3
⁄8" solid HSS blades, the TCMPL offers the perfect combination of power and balance with excellent grip for safe, one-handed operation. The 420W / 3.5A
motor and 60mm / 2
3
⁄8" planing width make this planer ideal for fast material removal on small to medium-sized workpieces. Up to 1.5mm /
1
⁄16" of material can
be removed in one pass, and the adjustable planing depth with 3 bevelling grooves ensures atness and improves cutting accuracy. A power lock-off switch
prevents accidental operation, and the foldaway blade protection foot prevents damage to the blades when the planer is resting on a surface.
Slim Handle Design
is easy to hold & control
using one hand
Power Lock-Off
to prevent accidental
operation
Power On-Off
for power to the tool
Rubber Over-Moulded Grip
increases control & safety
Parking Stand
protects the blades and workpiece
from damage on run down
Adjustable Dust Extraction
allows chips to be directed away
from the workpiece
3 Bevelling Grooves
increases range of edge
bevelling depths
Stepped Depth Control
allows for accurate
cutting depth from
0-1.5mm / 0 -
1
⁄16"
