RZA 1 0 00 00 0 11 01 0 00 11 0 11 0 01 11 11 10 RZA Big rack and tight door of the room - that‘s exactly the situation addressed for RZA cabinet. Thanks to the design of individual parts and sophisticated way to assably by Tap-Tide screws maintain high capacity and stability same as for welded version.
BREAKOUT-TYPE BLANKING PANELS Entry openings for cables (370 x 90 mm) in the rear part of the cabinet are covered with breakout-type blanking panels. To avoid dust penetration, it is possible to seal the cables at the entry opening by a brush strip, eventually just secure by a plastic protective frame (both supplied with the cabinet).
CASTORS, NIVELATION FEET Preparation for mounting of castors and nivelation feet. DOOR FOR FAN UNITS With this cabinet type, it is possible to order a special metal door with a preparation for mounting of RAx-CH-X0x-X3 fan units. Further informations are available in section Active cooling. 25 RZA DEMOUNTABILITY Individual RZA parts are joined together by a system of bolted joints to a compact unit with the same maximal loading capacity as a welded cabinet.
RZA 600 x 600 TYPE A B C D E Openings for fan* Weight gross (kg) Weight net (kg) RZA (mm) RZA-15-A66-CAX-A1 770 668 487 600 600 1 42,5 35,7 RZA-18-A66-CAX-A1 900 798 487 600 600 1 46,3 39,5 RZA-22-A66-CAX-A1 1080 978 487 600 600 2 51,5 44,6 RZA-27-A66-CAX-A1 1300 1198 487 600 600 2 59,8 52,8 RZA-32-A66-CAX-A1 1525 1423 487 600 600 3 66,6 59,6 RZA-37-A66-CAX-A1 1750 1648 487 600 600 3 73,7 66,5 RZA-42-A66-CAX-A1 1970 1868 487 600 600 3 80
RZA 600 x 1100 A B C D E Openings for fan* Weight gross (kg) Weight net (kg) (mm) RZA-15-A60-CAX-A1 770 668 487 600 1100 1 61,0 49,5 RZA-18-A60-CAX-A1 900 798 487 600 1100 1 67,6 54,7 RZA-22-A60-CAX-A1 1080 978 487 600 1100 2 74,8 61,9 RZA-27-A60-CAX-A1 1300 1198 487 600 1100 2 84,0 70,9 RZA-32-A60-CAX-A1 1525 1423 487 600 1100 3 93,0 79,9 RZA-37-A60-CAX-A1 1750 1648 487 600 1100 3 102,2 89,0 RZA-42-A60-CAX-A1 1970 1868 487 600 1100 3 111,
RZA 800 x 600 TYPE A B C D E Openings for fan* Weight gross (kg) Weight net (kg) RZA (mm) RZA-15-A86-CAX-A1 770 668 687 800 600 1 53,3 43,2 RZA-18-A86-CAX-A1 900 798 687 800 600 1 57,6 47,4 RZA-22-A86-CAX-A1 1080 978 687 800 600 2 63,4 53,1 RZA-27-A86-CAX-A1 1300 1198 687 800 600 2 72,5 62,1 RZA-32-A86-CAX-A1 1525 1423 687 800 600 3 80,1 69,6 RZA-37-A86-CAX-A1 1750 1648 687 800 600 3 87,9 77,2 RZA-42-A86-CAX-A1 1970 1868 687 800 600 3 95
RZA 800 x 1100 A B C D E Openings for fan* Weight gross (kg) Weight net (kg) (mm) RZA-15-A80-CAX-A1 770 668 687 800 1100 1 79,7 65,8 RZA-18-A80-CAX-A1 900 798 687 800 1100 1 85,4 71,6 RZA-22-A80-CAX-A1 1080 978 687 800 1100 2 93,3 79,4 RZA-27-A80-CAX-A1 1300 1198 687 800 1100 2 101,9 87,9 RZA-32-A80-CAX-A1 1525 1423 687 800 1100 3 111,8 97,7 RZA-37-A80-CAX-A1 1750 1648 687 800 1100 3 121,8 107,5 RZA-42-A80-CAX-A1 1970 1868 687 800 1100 3 1
RZA FREE-STANDING CABINET DESCRIPTION, PURPOSE OF USE • 19“ free-standing cabinet with IP20 protection • Cabinet includes 4 sliding vertical rails for device mounting (6 rails for cabinets deeper than 800 mm). • Cabinet construction: – Steel frame joined by bolts from welded parts, with removable side panels – Single or double doors in variants fully-metal, perforated (80% air permeability) or glazed with safety tempered glass 4mm. They can be on the front or back of the cabinet. RZA • Max.
