Specification Sheet

MODEL: IND17-6V
DIMENSIONS: inches (mm)
BATTERY: Flooded/wet lead-acid battery
COLOR: Maroon (case/cover)
MATERIAL: Polypropylene (internal cell container)
Polyethylene (outer container)
Page 1 of 2
CHARGING INSTRUCTIONS
CHARGER VOLTAGE SETTINGS AT 77°F/25°C
Voltage per cell
Absorption charge 2.35-2.45
Float charge 2.20
Equalize charge 2.58
Do not install or charge batteries in a sealed or non-ventilated compartment.
Constant under or overcharging will damage the battery and shorten its life
as with any battery.
OPERATIONAL DATA
TRJN_IND17-6V • DS0811
PRODUCT SPECIFICATION
A. The amount of amp-hours (AH) a battery can deliver when discharged at a constant rate at 80°F (27°C) and maintain a voltage above 1.75 V/cell. Capacities are based on nominal performance.
B. Dimensions are based on nominal size. Dimensions may vary depending on type of handle or terminal.
C. Dimensions taken from bottom of the battery to the highest point on the battery. Heights may vary depending on type of terminal.
Trojan’s battery testing procedures adhere to both BCI and IEC test standards.
TYPE CAPACITY
A
Amp-Hours (AH) ENERGY
(kWh)
VOLTAGE DIMENSIONS
B
Inches (mm) WEIGHT lbs. (kg)
5-Hr
Rate
10-Hr
Rate
20-Hr
Rate
48-Hr
Rate
72-Hr
Rate
100-Hr
Rate
240-Hr
Rate
100-Hr
Rate
Length Width Height
C
Dry Wet
DEEP CYCLE BATTERY
IND17-6V 711 805 897 1011 1061 1090 1101 6.54 6 26-11/16 (678) 10-1/4 (260) 24 (610) 331 (150) 415 (188)
CHARGING TEMPERATURE COMPENSATION
To the Voltage Reading -- Subtract 0.005 volt per cell (VPC) for every 1°C above 25°C or add 0.005 volt per cell for every 1°C below 25°C.
EXPECTED LIFE VS. TEMPERATURE
Chemical reactions internal to the battery are driven by voltage and temperature. The higher the battery temperature, the faster chemical reactions will occur.
While higher temperatures can provide improved discharge performance the increased rate of chemical reactions will result in a corresponding loss of battery life.
As a rule of thumb, for every 10°C increase in temperature the reaction rate doubles. Thus, a month of operation at 35°C is equivalent in battery life to two months
at 25°C. Heat is an enemy of all lead acid batteries, FLA, GEL, and AGM alike and even small increases in temperature will have a major inuence on battery life.
CAPACITY AMPHOURS AH
Cutoff Voltage 5-Hr 10-Hr 20-Hr 48-Hr 72-Hr 100-Hr 240-Hr
1.75 vpc 711 805 897 1011 1061 1090 1101
1.80 vpc 641 757 861 991 1041 1067 1085
1.85 vpc 581 684 791 911 971 1006 1009
1.90 vpc 424 550 661 801 861 894 901
Operating Temperature Self Discharge Specic Gravity
-4°F to 113°F (-20°C to +45°C).
At temperatures below 32°F
(0°C) maintain a state of
charge greater than 60%.
Up to 4% per
week
The specic gravity at
100% state-of-charge
is 1.260
IND17-6V Data sheet
INDUSTRIAL LINe
