Data Sheet

ELECTRICAL & MECHANICAL SPECIFICATION
Switch Rang: 150mA @ 250V ac/dc Life: >10,000 Cycles
1A @ 24V dc Operang Temperature: -30°C to +85°C
Proof Voltage: 1,500V ac (Inial) Operang Torque (nominal): Standard 8.6 ±1 cNm
Insulaon Resistance: >999 MΩ at 500V dc (Inial) Light Acon 3.5 ± 0.5 cNm
Contact Resistance <20 mΩ (Inial) End Stop Torque (nominal): 0.80 Nm
Contact/Terminal Material: Brass CZ108 Ag Plated Moulding Material: Polyamide 6.6 G.F
FEATURES
Standard 30° indexing,
Moulded 27.5mm
diameter
Solder
non-shorng (break before make)
Made in UK
Single wafer switch
4 x 3 posions
TC-DS4X3L
