User guide

LYDKRAFT ApS
Mose Allé 20, DK 2610 Rødovre
Denmark
2
(100301)
Removing a module:
Unscrew the top and bottom centre screws of the module.
Fix the removing tools in the top and bottom holes (M5 thread) and cautiously pull out the
module. When inserting a module observe that the PCB slides freely into all six PCB guides.
Under no circumstances, replace modules with power connected to the frame.
IMPORTANT!!!!!!!
For safety reasons, it is important that each module is securely fixed with two
screws (top and bottom of module) otherwise modules might slide out of the
frame, exposing the very high voltage on the neighbouring module PCB and the
module connecting PCB inside the frame.
For the same reason, it is important that slots not holding modules are covered
with blind panels.
Under no circumstances, replace modules with power connected to the frame.
It is very important that the air holes in the top and bottom of the frame, is kept
free from any covering.
No user serviceable parts inside.
Technical specifications:
Dimensions: Height: 195 mm 7,7"
Width: 445 mm 17,5"
Depth: 360 mm 14,2"
Weight: Net: 8,9 kg 19,7 lbs.
Shipping: 10,2 kg 22,5 lbs
Power requirements:
@ 115 V/230 V, 50-60 Hz: 20-140 W
