Spec Sheet

TBC-36SD-GF-N TBC-36SB-GF-N
Model : TBC-36SD/SB-GF-N
TBC-36SD-GF-N 1 9.74 93 / 227 Cups 5 1/3 1.6 230 363/4 x 261/2 x 331/4
TBC-36SB-GF-N 1 9.74 93 / 227 Cups 5 1/3 1.6 230 363/4 x 261/2 x 331/4
Glass / Mug Frosters
Glass / Mug Frosters
Model CU./FT.
# of
Shelves
Sliding
Doors HP AMPS
Capacity
8” Mug / 10oz Stein
Crated
Weight
(
lbs.
)
L x D x H
(
inches
)
†
*
Underbar Equipment
Super Deluxe Series
Project :
Model # :
Item # : Qty :
Available W/H :
Approval :
4184 E. Conant St.
Long Beach, CA 90808
Tel. [phone]
Fax. [phone]
www.turboairinc.com
more durable,efficient,beautiful
This product is equipped with a
fine mesh filter to the front of the
condenser to catch dust, and a
rotating brush that moves up and
down daily to remove excess
buildup outward and away.
Patented Self-Cleaning Condenser
TB
C
-36
S
D-
G
F-
N
* Depth does not include 2” for rear spacers. † Height does not include 5” for caster height.
Self-Cleaning Condenser
The accumulation of dust in the condenser can cause the failure or
breakdown of refrigerators. Refrigerators run normally until they reach a
certain level of accumulation. At some point, when they are over the limit,
their performance drops quickly resulting in damage to, or disposal of the
stored products inside. The Self-Cleaning Condenser device keeps the
condenser clean and prevents system failure by automatically brushing daily .
Hydrocarbon refrigerants (R-290)
With innovative and eco-friendly technology, Turbo Air brings you
hydrocarbon refrigerators designed to meet DOE's Energy Conservation
Standards in 2017 and to use EPA's SNAP Program approved HC
refrigerants. Hydrocarbon refrigerants do not deplete the ozone layer and
have very low contribution to global warming (ODP-0, GWP-3).
Stainless steel cabinet construction
Super Deluxe (SD) models boast a stainless steel exterior (except
galvanized steel back and bottom). SB models have an attractive wear-re-
sistant black vinyl exterior. Heavy gauge stainless steel countertop and glide
lids are perfect for sanitation and durability. The interior is stainless steel
except galvanized steel top. Turbo Air Glass Froster model guarantees the
utmost in cleanliness and long product life. It also adds a touch of style to
the most refined setting.
Manual defrost system
High-density polyurethane insulation
The entire cabinet structure is foamed-in-place using high density,
HCFC free polyurethane insulation.
Heavy duty, PE (polyethylene) coated dividers
Heavy duty 10mm thick pure grade PE coated shelves are provided
for maximum storage use.
Direct cooling type
Large capacity cooler cabinet requires only
minimum floor space
Side mount compressor unit
With compressors positioned on the side of the unit, our refrigerators can
now be serviced without being moved. Our innovative, front breathing
feature also allows this model to be highly efficient in narrow spaces.
Glass/mug froster holds -5°F ~ 15°F for the best
in chilling glasses and plates
FEATURES & BENEFITS
3 YEAR
(
U.S.A only
)
7 YEAR
Compressor
WARRANTY
(
U.S.A only
)
ISO 9001:2008
Ver.20200706
