Specification Sheet

207/8 (528mm)
41/4
(109mm)
453/4 (1163mm)
18 (457mm)
363/8 (925mm)
337/8 (861mm)
321/2 (825mm)
137/8
(353mm)
137/8
(353mm)
317/8 (807mm)
PLAN VIEW
Mega Top Unit
Mega Top Unit
Model : TST-36SD-15-N6
Turbo Air : 800-627-0032
Warranty : 800-381-7770
GK : 800-500-3519
AC : 888-900-1002
ELECTRICAL DATA
DIMENSIONAL DATA
PLAN VIEW
115/60/1
NEMA 5-15P
2.9
3/8
9
R-600a
36
3/8 (925mm)
34 (864mm)
39
(991mm)
2
2
15
1
11
226
242
15 x 17
(unit : inch)
Food Prep Tables
Super Deluxe Series
Voltage
Plug Type
Full Load Amperes
Compressor HP
Cord Length (ft.)
Refrigerant
Ext. Length Overall (in.)
Ext. Depth Overall (in.)
Ext. Height Overall (in.)
# of Doors
# of Shelves
# of Pans
# of Hood
Net Capacity (cu. ft.)
Net Weight (lbs.)
Gross Weight (lbs.)
Shelf Size (in.)
SIDE VIEW
34
(864mm)
30 (762mm)
9 (229mm)
3 (76mm)
253/8 (643mm)
143/4
(375mm)
171/4 (437mm)
157/8
(403mm)
87/8
291/2 (749mm)
†
*
5(127mm)
3/4(19mm)
OPTIONAL ACCESSORIES :
2.5” caster, ½” diameter & 13 TPI: 30265H0100 (non-brake),
30265H0200 (w/ brake)
5” caster, ½” diameter & 13 TPI: M726500100 (non-brake),
M726500200 (w/ brake)
6” ABS plastic leg: 30221M0200
6” stainless steel leg: 30221M0600
Additional stainless steel shelf: M367800100
Removable food cover: RCT-36-15
Stainless steel double overshelf: TSOS-3R
3 Year Parts and Labor Warranty
Additional 2 Year Warranty on Compressor
Design and specifications subject to change without notice.
Actual shipping weight may differ due to extra packing materials for product protection.
* Depth does not include 3” for cutting boards and 1” for rear spacers.
† Height does not include 5” for caster height.
Anti-corrosion coated evaporator
Self-contained system
Standard 4” dia. swivel casters with locks on the front set
Standard 1/6 size, 4” deep condiment pans included
2.5” dia. casters available (optional) & Legs available (optional)
Removable food covers available (optional)
Stainless steel double overshelf available (optional)
Door lock: extra lead time will apply, please call factory for
more details to order
Ver.20171103
5 YEAR
Compressor
WARRANTY
(
U.S.A only
)
3 YEAR
