Residential Single and Double Wall Oven Service Manual

A.22 APPENDIX  REPLACING OVEN COMPONENTS
Item Description Item Part # Hardware Description Hardware Part Number(s)
Access Panel, EC, Lower RWD-9127 Screw, SH MTL, #8 x 1/2 Serrated PHTRH 101688 (x3)
Bracket, Relay Attachment,
Gen 1
RWD-9126 Screw, SH MTL, #8 x 1/2 Serrated PHTRH 101688 (x2)
Bracket, Relay Attachment,
Gen 2
RWD-9126 Screw, SH MTL, #8 x 1/2 Serrated PHTRH 101688 (x2)
Cooling Fan, EC, Lower 104125 Screw, SH MTL, #8 x 1/2 Serrated PHTRH 101688 (x3)
Harness, H.V., Lower Oven, Gen 2 RWD-9539 None None
Harness, L.V., Lower Oven, Gen 2 RWD-9541 None None
Harness, Lower Oven RWD-9408 None None
Harness, Power, Lower, DWO RWD-9429 None None
High Limit Switch 102075
Screw, SH MTL, #8 x 1/2 Serrated PHTRH
Screw, M4X 0.7 x 8, PPHD, INT Tooth, SS
Bracket, High-Limit Switch, Lower
101688 (x4)
101672 (x2)
RWD-9140
Latch Mechanism RWD-9366
Screw, SH MTL, #8 x 1/2 Serrated PHTRH
Bracket, Door Lock Support, GEN 1
101688 (x4)
RWD-9595
Relay, K10 104202 Screw, #6 x 1/2, PPHD, DRL-PT, SS 101687 (x2)
Relay, K11 101281 Screw, SH MTL, #8 x 1/2 Serrated PHTRH 101688 (x2)
Relay, K12 101281 Screw, SH MTL, #8 x 1/2 Serrated PHTRH 101688 (x2)
Relay, K13 104179 Screw, #6 x 1/2, PPHD, DRL-PT, SS 101687 (x2)
Snubber, Electrical RWD-9497 None None
Terminal Block 104145
Screw, #8 x 3/4, PPHD, PLT-STL
Bracket, Terminal Block
Screw, SH MTL, #8 x 1/2 Serrated PHTRH
104178 (x2)
RWD-9147
101688 (x2)
Thermostat, 160F, Close on Rise 104236 Screw, #6 x 1/2, PPHD, DRL-PT, SS 101687 (x2)
Thermostat, 280F, Open on Rise 104167 Screw, #6 x 1/2, PPHD, DRL-PT, SS 101687 (x2)
Wire, Canada, Black RWD-9531 None None
Wire, Canada, Orange RWD-9530 None None
Wire, Canada, Short RWD-9529 None None
Wire, L.V., P9 Conn., DWO RWD-9430 None None
Wire, Switch, Lower RWD-9428 None None
Lower Electrical Compartment Detail, DWO Gen 1 and DWO Gen 2
DANGER: Before removing or replacing any oven component, ensure the oven is removed from any
power source (i.e., the breaker is turned off ). Failure to do so can result in serious injury or death.
WARNING: Before removing or replacing any oven component, thoroughly read the safety instructions
found at the front of this manual and in Oven Systems (Section 5) and Troubleshooting (Section 6). Adhere to
all precautions and warnings outlined in these sections, as failure to do so could result in serious injury or death.
CAUTION: Before removing/installing any component, make sure it is disconnected from the wire
harness (where applicable).
Di erentiating Between DWO Gen 1 and DWO Gen 2
Use the serial number to tell if the oven being serviced is a DWO Gen 1 or DWO Gen 2 oven. To view the
serial number, open the Speedcook oven door and locate the serial plate (between the Speedcook oven door’s
hinges). If the serial number’s fi rst fi ve characters are “TDO2D” (or “TSO2D” for SWO models), the oven is a
Gen 2 oven. If the fi rst fi ve characters are NOT “TDO2D” (or “TSO2D”), the oven is a DWO Gen 1 oven.
