A.28 APPENDIX  REPLACING OVEN COMPONENTS
Item Description Item Part # Hardware Description Hardware Part Number(s)
Blade, Convection Fan 104169
Nut, Convection Fan
Ring, Shim, Convection Fan
104170
104171
Bracket, Convection Fan RWD-9238 None None
Convection Fan 104158
Screw, #8-32 x 1/2, PPHD, INT SEMS, SS
Nut, #8-32, HEX, SS
102923 (x3)
101000 (x3)
Convection Fan Assembly N/A Screw, SH MTL, #8 x 1/2 Serrated PHTRH 101688 (x8)
Cover, Bake Element RWD-9242 Screw, SH MTL, #8 x 1/2 Serrated PHTRH 101688 (x5)
Cover, Hinge Pocket, Lower RWD-9149 Screw, SH MTL, #8 x 1/2 Serrated PHTRH 101688 (x2)
Cover, Meat Probe RWD-9128 Screw, SH MTL, #8 x 1/2 Serrated PHTRH 101688 (x2)
Cover, Rear, Lower Oven RWD-9225 Screw, SH MTL, #8 x 1/2 Serrated PHTRH 101688 (x8)
De ector, Broiler RWD-9235 Screw, SH MTL, #8 x 1/2 Serrated PHTRH 101688 (x4)
Door Receiver 104123 Screw, 10-32 x 1/4 LG, PFLH 100 DEG, SS 101402 (x2)
Element, Bake, Concealed (208V) RWD-9464 Screw, SH MTL, #8 x 1/2 Serrated PHTRH 101688 (x2)
Element, Bake, Concealed (240V) RWD-9354 Screw, SH MTL, #8 x 1/2 Serrated PHTRH 101688 (x2)
Element, Broil (208V) RWD-9462 Screw, SH MTL, #8 x 1/2 Serrated PHTRH 101688 (x4)
Element, Broil (240V) RWD-9351 Screw, SH MTL, #8 x 1/2 Serrated PHTRH 101688 (x4)
Element, Convection (208V) RWD-9463 Screw, SH MTL, #8 x 1/2 Serrated PHTRH 101688 (x2)
Element, Convection (240V) RWD-9353 Screw, SH MTL, #8 x 1/2 Serrated PHTRH 101688 (x2)
Hinge Pocket, Lower, LHS RWD-9119 Screw, SH MTL, #8 x 1/2 Serrated PHTRH 101688 (x3)
Hinge Pocket, Lower, RHS RWD-9118 Screw, SH MTL, #8 x 1/2 Serrated PHTRH 101688 (x3)
Lamp, Halogen, Lower Oven RWD-3016 None None
Panel, Convection, Porcelain RWD-9575 Screw, SH MTL, #8 x 1/2 Serrated PHTRH 101688 (x4)
Plate, Convection Fan RWD-9237
Spacer, #8 x 5/16 OD x 1-1/2 LG, SS
Screw, #8 x 2.00 PH MOD TRUSS SS
103326 (x4)
104184 (x4)
Rack Guide RWD-9385 Screw, #8 x 3/8 PH MOD TRUSS, CRES 101682 (x2)
Rack, Lower Oven RWD-9384 None None
Rack, Roller, Lower Oven RWD-9383 None None
Receptacle, Meat Probe 104159 None None
RTD RWD-9364 Screw, #8 x 3/8 PH MOD TRUSS, CRES 101682 (x2)
Separator, Convection Fan RWD-9223 Screw, SH MTL, #8 x 1/2 Serrated PHTRH 101688 (x4)
Snubber, Electrical RWD-9497 None None
Stand-O , Broil Element RWD-9215 Screw, SH MTL, #8 x 1/2 Serrated PHTRH 101688 (x2)
Stand-O , Rear, Lower RWD-9130 Screw, SH MTL, #8 x 1/2 Serrated PHTRH 101688 (x3)
Lower Oven Cavity Component Detail, DWO Gen 1 and DWO Gen 2
DANGER: Before removing or replacing any oven component, ensure the oven is removed from any
power source (i.e., the breaker is turned off ). Failure to do so can result in serious injury or death.
WARNING: Before removing or replacing any oven component, thoroughly read the safety instructions
found at the front of this manual and in Oven Systems (Section 5) and Troubleshooting (Section 6). Adhere to
all precautions and warnings outlined in these sections, as failure to do so could result in serious injury or death.
CAUTION: Before removing/installing any component, make sure it is disconnected from the wire
harness (where applicable).
