Residential Single and Double Wall Oven Service Manual

OVEN CONTROLS AND COOKING  THE SPEEDCOOK OVEN
2.5
Basic Cooking
Figure 2.2
 is section explains how to cook a food item by
describing the “standard operation” modes through
which the Speedcook oven progresses.
 e oven is preprogrammed with recipe settings at
the time of manufacture and is ready to operate after
installation.
NOTE: Modes are not always sequential, as shown
in Figure 2.2, above.
-  1: Oven Off
-  2: Select a Food Item
-  3: Confi rm Settings
-  4: Preheat
-  5: Ready to Cook
-  6: Cooking
-  7: 80% Complete
-  8: 100% Complete
-  9: Remove Food from Oven
Mode 1: Oven O
Mode during which the oven is turned off . To begin
cooking, the user must fi rst select, using the Cook-
Wheel, one of the seven speedcook modes (Air-
Crisp, Bake, Broil, Dehydrate, Favorites, Roast, or
Toast).
Happens When...
-  e user turns the CookWheel to the “Off ”
position at any time.
Goes To...
-  2 when the user turns the CookWheel to
Air-Crisp, Bake, Broil, Dehydrate, Roast, or
Toast.
- Favorites when the user turns the CookWheel
to Favorites (for more information on Favorites,
see page 2.3).
Mode 2: Select a Food Item
Mode during which the user specifi es which dish to
cook. Use the inner CookWheel knob to select the
item and item specifi cations. To make a selection,
scroll to the desired option and press the inner
CookWheel knob or start key.
Roast
... Rack of Lamb 14 to 16 oz 1 Rack
To start cook
cycle, select
Begin Preheat
SUGGESTED SETTINGS
mins : secs
Cook Time Oven Temp
Adjust Settings
Begin Preheat
04:00 500
PREHEAT - get screenshot
Ready to cook - get screenshot
Roast
... Rack of Lamb 14 to 16 oz 1 Rack
Cooking has started
The oven will
remind you to
check the dish
and tone when
cooking is 80%
complete.
COOK TIME: 04:00 COOK TEMP: 500
Time Remaining
03:55
Roast
Cook More
Brown More
Cook and Brown More
Done Cooking this Dish
... Rack of Lamb 14 to 16 oz 1 Rack
COOK TIME: 04:00 COOK TEMP: 500 TIME LEFT: 00:00
Roast
Meat Lamb Rack of Lamb 14 to 16 oz
Please select
an option
1 Rack
2 Racks
Roast
No Change
Cook Less
Brown Less
Cook and Brown Less
... Rack of Lamb 14 to 16 oz 1 Rack
COOK TIME: 04:00 COOK TEMP: 500 TIME LEFT: 00:48
1
2
3
7
8
Roast
... Rack of Lamb 14 to 16 oz 1 Rack
Please check
your dish. Be
careful when
removing from
Oven.
SUGGESTED SETTINGS
mins : secs
Cook Time Oven Temp
Save to Favorites Cook Another
Done
04:00 500
9
6
Roast
Lamb Rack of Lamb 14 to 16 oz 1 Rack
COOK TIME: 04:00 COOK TEMP: 500
mins : secs
Preheat Time Oven Temp
03:18 347
Preheating, please wait to insert dish
! Do not put
the dish into
the oven until
preheat is
complete.
4
Roast
Lamb Rack of Lamb 14 to 16 oz 1 Rack
COOK TIME: 04:00 COOK TEMP: 500
mins : secs
Cook Time Oven Temp
04:00 500
Preheat complete, oven ready
Carefully place
dish into oven. To
begin cooking
press the
Start button.
5
Figure 2.2: Standard Operation Modes
