Residential Single and Double Wall Oven Service Manual

APPENDIX  REPLACING OVEN COMPONENTS
A.1
Part Details... Locate the Part Here...
Item Part # Oven Page # Illustration #
Access Panel, EC, Lower RWD-9127 DWO Gen 1 & 2 A.22 A.17
Air Switch 102009 SWO A.8 A.2
Blade, Convection Fan 104169 DWO Gen 1 & 2 A.28 A.25
Blower Motor Controller 100446 All A.24 A.23
Blower Motor, Lower RWD-9042 All A.24 A.23
Blower Motor, Upper RWD-9040 All A.24 A.23
Blower, Dual 104164 All A.14, A.16 A.7, A.9
Blower, Exhaust 104190 SWO A.8 A.2
Bracket, Capacitor 104198 DWO Gen 1 A.14 A.7
Bracket, Control Assembly RWD-9367 All A.12 A.5
Bracket, Convection Fan RWD-9238 DWO Gen 1 & 2 A.28 A.25
Bracket, Display, Lower RWD-9142 DWO Gen 1 & 2 A.11 A.4
Bracket, Fuse and Terminal Block RWD-9391 DWO Gen 1 A.14 A.8
Bracket, Relay Attachment, Gen 1 RWD-9126 DWO Gen 1 A.22 A.17
Bracket, Relay Attachment, Gen 2 RWD-9126 DWO Gen 2 A.22 A.18
Cable, Display, L.V., DWO RWD-9427 DWO Gen 1 & 2 A.6 None
Cable, Display, Upper RWD-9438 All A.14, A.16 None
Cable, Interconnect, Relay Board RWD-9542 DWO Gen 2 & SWO A.16 None
Cable, Ribbon, 6” 104208 DWO Gen 1 A.6 None
Capacitor, H.V. 100213 All A.14, A.20 A.7, A.13, A.14
Catalytic Converter RWD-9066 All A.24 A.23
Clock Assembly RWD-9253 All A.12 A.5
Clock Ring Gasket RWD-9450 All A.12 A.5
Clock Transformer 104139 DWO Gen 1 A.18 A.10
Control Board, Gen 1 RWD-3003 DWO Gen 1 A.18 A.10
Control Board, Gen 2 RWD-3015 DWO Gen 2 & SWO A.18 A.11
Control Housing Assembly N/A All A.11 A.3, A.4
Control Housing, Upper RWD-9046 All A.12 A.5
Controls Assembly N/A DWO Gen 1 A.14 A.7
Controls Assembly, Gen 2 N/A DWO Gen 2 & SWO A.16 A.9
Convection Fan 104158 DWO Gen 1 & 2 A.28 A.25
Convection Fan Assembly N/A DWO Gen 1 & 2 A.28 A.24
Comprehensive Table of Oven Components
DANGER: Before removing or replacing any oven component, ensure the oven is removed from any
power source (i.e., the breaker is turned off ). Failure to do so can result in serious injury or death.
WARNING: Before removing or replacing any oven component, thoroughly read the safety instructions
found at the front of this manual and in Oven Systems (Section 5) and Troubleshooting (Section 6). Adhere to
all precautions and warnings outlined in these sections, as failure to do so could result in serious injury or death.
CAUTION: Before removing/installing any component, make sure it is disconnected from the wire
harness (where applicable).
