APPENDIX  REPLACING OVEN COMPONENTS

A.3

Part Details... Locate the Part Here...

Item Part # Oven Page # Illustration #

Element, Broil (240V) RWD-9351 DWO Gen 1 & 2 A.28 A.24

Element, Convection (208V) RWD-9463 DWO Gen 1 & 2 A.28 A.24

Element, Convection (240V) RWD-9353 DWO Gen 1 & 2 A.28 A.24

EMI Filter 104211 All A.14, A.16 A.7, A.9

Front Trim, DWO N/A DWO Gen 1 & 2 A.6 A.1

Front Trim, SWO N/A SWO A.8 A.2

Fuse Block 104183 DWO Gen 1 A.14 A.8

Fuse Holder 100579 DWO Gen 1 A.14 A.7

Fuse, 5 Amp 100635 DWO Gen 1 A.14 A.7

Fuse, 15 Amp, Gen 1 100601 DWO Gen 1 A.14 A.8

Fuse, 15 Amp, Gen 2 100602 DWO Gen 2 & SWO A.18 A.11

Fuse, 20 Amp, Gen 1 100599 DWO Gen 1 A.14 A.8

Fuse, 20 Amp, Gen 2 100603 DWO Gen 2 & SWO A.18 A.11

Handle, Lower Oven RWD-9224 DWO Gen 1 & 2 A.6 A.1

Handle, Speedcook Oven RWD-9011 All A.6, A.8 A.1, A.2

Harness, Clock, Gen 2 RWD-9543 DWO Gen 2 & SWO A.16 None

Harness, Failsafe, Microwave RWD-9555 DWO Gen 1 A.6 None

Harness, Fuse, Cooling Fan RWD-9553 DWO Gen 1 A.6 None

Harness, H.V., Lower Oven, Gen 2 RWD-9539 DWO Gen 2 A.22 None

Harness, L.V., Clock RWD-9437 DWO Gen 1 A.14 None

Harness, L.V., Lower Oven, Gen 2 RWD-9541 DWO Gen 2 A.22 None

Harness, L.V., Upper Oven, Gen 2 RWD-9540 DWO Gen 2 & SWO A.16 None

Harness, Lower Oven RWD-9408 DWO Gen 1 A.22 None

Harness, Power, Lower, DWO RWD-9429 DWO Gen 1 & 2 A.22 None

Harness, Power, Motor Controller RWD-9559 DWO Gen 2 & SWO A.16 None

Harness, Single RWS-9002 SWO A.8 None

Harness, Upper Oven RWD-9407 DWO Gen 1 A.14 None

Harness, Wire, Gen 2 RWD-9538 DWO Gen 2 & SWO A.16 None

Heater Cover Plate RWD-9156 All A.14, A.16 A.8, A.9

Heater, Upper Oven (208V) RWD-9394 All A.24 A.23

Heater, Upper Oven (240V) RWD-9065 All A.24 A.23

High Limit Switch 102075 All A.14, A.16, A.22 A.8, A.9, A.17

Hinge Pocket, Lower, LHS RWD-9119 DWO Gen 1 & 2 A.28 A.24

Hinge Pocket, Lower, RHS RWD-9118 DWO Gen 1 & 2 A.28 A.24

Hinge Pocket, LHS RWD-9098 All A.24 A.22

Hinge Pocket, RHS RWD-9097 All A.24 A.22

Jetplate, Lower RWD-9576 All A.24 A.22

Jetplate, Upper RWD-3017 All A.24 A.22

Lamp, Halogen, Lower Oven RWD-3016 DWO Gen 1 & 2 A.28 A.24

Lamp, Halogen, Upper Oven RWD-3014 All A.24 A.22

Latch Mechanism RWD-9366 All A.22 A.17

Light Switch 104141 All A.11, A.12 A.4, A.5

M.O.V. Filter RWD-9490 All A.14, A.21 A.8, A.16

Mag Air Diverter Assembly, Gen 1 N/A DWO Gen 1 A.14 A.8
