Residential Single and Double Wall Oven Service Manual

A.6 APPENDIX  REPLACING OVEN COMPONENTS
Item Description Item Part # Hardware Description Hardware Part Number(s)
Cable, Display, L.V., DWO RWD-9427 None None
Cable, Ribbon, 6” 104208 None None
Cover, Back, DWO RWD-9184 Screw, SH MTL, #8 x 1/2 Serrated PHTRH 101688 (x19)
Diverter, Vent Outlet RWD-9584 None None
Door Sensing Switch 104229 Screw, SH MTL, #8 x 1/2 Serrated PHTRH 101688 (x3)
Door Skin, Replacement RWD-3004-X None None
Door, Lower RWD-3021 None None
Door, Speedcook Oven RWD-3019-X
Screw, SH MTL, #8 x 1/2 Serrated PHTRH
Cover, Hinge Pocket
Screw, #8-32 x 3/8, PPH, THD-Forming, PLT
101688 (x4)
RWD-9472 (x2)
104227 (x2)
Door, Speedcook Oven, Inner RWD-3022 None None
Electrical Compartment, Lower,
Gen 1 (see pages A.22-A.23)
N/A None None
Electrical Compartment, Lower,
Gen 2 (see pages A.22-A.23)
N/A None None
Electrical Compartment, Upper,
Gen 1 (see pages A.13-A.15)
N/A None None
Electrical Compartment, Upper,
Gen 2 (see pages A.16-A.17)
N/A None None
Front Trim, DWO
(see pages A.10-A.11)
N/A
Screw, #8 x 3/8 PH MOD TRUSS CRES
Screw, SH MTL, #8 x 1/2 Serrated PHTRH
Screw, #8 x 2.00 PH MOD TRUSS SS
101682 (x16)
101688 (x4)
104184 (x2)
Handle, Lower Oven RWD-9224 Bolt, Handle, Lower Oven RWD-9457 (x2)
Handle, Speedcook Oven RWD-9011 Bolt, Handle, Speedcook Oven RWD-9458 (x2)
Harness, Failsafe, Microwave RWD-9555 None None
Harness, Fuse, Cooling Fan RWD-9553 None None
Oven, Lower
(see pages A.28-A.29)
N/A None None
Component and Assembly Location, DWO Gen 1 and Gen 2
DANGER: Before removing or replacing any oven component, ensure the oven is removed from any
power source (i.e., the breaker is turned off ). Failure to do so can result in serious injury or death.
WARNING: Before removing or replacing any oven component, thoroughly read the safety instructions
found at the front of this manual and in Oven Systems (Section 5) and Troubleshooting (Section 6). Adhere to
all precautions and warnings outlined in these sections, as failure to do so could result in serious injury or death.
CAUTION: Before removing/installing any component, make sure it is disconnected from the wire
harness (where applicable).
Removing the Oven
In order to remove the oven from the wall, the two mounting screws (P/N: 104184), located on the inside of
the Speedcook oven’s outer trim, must be removed (additionally, some older DWO oven models have 2
cabinet screws in the lower oven’s outer trim).  e oven may be safely pulled away from the wall approximately
11” (280 mm) to remove the front top cover, lower EC access panel, and the door switch covers. Any further
removal requires the oven to be fully removed from the wall and placed upon a cart capable of supporting
approximately 410 lbs (186 kg).
