FC-890 Flying Chains
An adjustable length flying chain, consisting of a top hook, chain with adjusting choke, and a
cabinet link, is used to connect the cabinets to the flybars. The top chain from the flybar to
the first cabinet can be adjusted to gain more height on the system and also improve the
looks. Alternatively if you are flying four or more cabinets deep with a lot of kelp it is good to
give the top chain some additional length as this makes racheting easier.
Chains are universal (not handed) and therefore can be used for either side of the cabinet. FC-
890 flying chains are load tested to 560kg.
TS-890 Tilting Straps
4m
0.59m
The tilting strap, TS-890, is in two parts. The longer part is attached to the tilt strap point on
the flying bar using the buckle at its end. The other part of the strap with the ratchet is
hooked into the tilt strap point on the underside of the bottom enclosure. The free end is then
threaded through the ratchet and the strap tightened to achieve the desired tilt. The tilt strap
is designed to ratchet in both directions so that the amount of tilt on a column may easily be
increased or reduced incrementally.
