Manual 0-4731 Rev. AG 8-12 TORCH DATA
Stainless Steel
70A
Air Plasma / Air Shield
Cartridge
22-1020
Electrode
22-1079
Plasma
Gas Distributor
22-1041
Tip
22-1061
Shield Cap
22-1035
Shield Cup
22-1016
Art # A-06046
Shield
Gas Distributor
22-1274
(ga) (in) inch (psi) Ball (psi) Ball (psi) Volts
(in)
±0.005
(ipm) (in) (sec) (in)
10 0.141 84 41 120 94 120 138 0.080 120 0.140 0.3 0.075
3/16 0.188 84 41 120 87 120 144 0.080 100 0.140 0.4 0.082
1/4 0.250 84 41 120 72 120 148 0.130 55 0.180 0.5 0.085
3/8 0.375 84 41 120 72 120 152 0.140 40 0.200 0.6 0.083
1/2 0.500 84 53 120 60 120 160 0.140 25 0.280 0.8 0.080
(bar) Ball (bar) Ball (bar) Volts
(mm)
±0.1
(mm/min)
(mm) (sec) (mm)
5.8 41 8.3 94 8.3 135 2.0 3300 3.6 0.3 1.8
5.8 41 8.3 94 8.3 140 2.0 2870 3.6 0.3 2.0
5.8 41 8.3 87 8.3 145 2.2 2380 3.7 0.4 2.1
5.8 41 8.3 72 8.3 148 2.3 1440 4.5 0.5 2.1
5.8 41 8.3 72 8.3 150 2.4 1200 4.8 0.6 2.1
5.8 41 8.3 72 8.3 153 3.6 960 5.4 0.6 2.1
5.8 53 8.3 60 8.3 158 3.6 720 6.7 0.8 2.1
6
8
10
12
(mm)
3
4
5
Arc
Voltage
Torch
Working
Height
Travel
Speed
Initial
Piercing
Height
Plasma (Air) Shield (Air)
Material
Thickness
Pre Flow
Pr e s s ur e
(Air)
Cut Flow Rates / Pressures
Pierce
Delay
K
er
f
Width
@ Rec.
Speed
Plasma (Air) Shield (Air)
70A Stainless Steel (Air/Air)
Material
Thickness
Pre Flow
Pr e s s ur e
(Air)
Cut Flow Rates / Pressures
Arc
Voltage
Torch
Working
Height
Travel
Speed
Initial
Piercing
Height
Pierce
Delay
Kerf
Width
@ Rec.
Speed
