User Manual

Manual 0-4731 Rev. AG 8-18 TORCH DATA
Cartridge
22-1020
Electrode
22-1078
Plasma
Gas Distributor
22-1041
Tip
22-1060
Shield Cap
22-1034
Shield Cup
22-1016
Art # A-06813
Shield
Gas Distributor
22-1274
Aluminum
50A
Air Plasma / Air Shield
(ga) (in) inch (psi) Ball (psi) Ball (psi) Volts
(in)
±0.005
(ipm) (in) (sec) (in)
16 0.064 100 60 120 75 120 124 0.100 140 0.200 0.0 0.06
12 0.097 100 60 120 75 120 125 0.105 90 0.200 0.0 0.067
11 0.120 100 60 120 75 120 129 0.110 60 0.200 0.0 0.068
3/16 0.188 100 60 120 75 120 133 0.120 40 0.200 0.2 0.074
(bar) Ball (bar) Ball (bar) Volts
(mm)
±0.1
(mm/min)
(mm) (sec) (mm)
6.9 60 8.3 75 8.3 124 2.6 2990 5.1 0.0 1.6
6.9 60 8.3 75 8.3 129 2.8 1520 5.1 0.0 1.7
6.9 60 8.3 75 8.3 131 2.9 1240 5.1 0.1 1.8
6.9 60 8.3 75 8.3 134 3.1 950 5.1 0.2 1.9
50A Aluminum (Air/Air)
Material
Thickness
Pre Flow
Pr e s s ur e
(Air)
Cut Flow Rates / Pressures
Arc
Voltage
Torch
Working
Height
Travel
Speed
Initial
Piercing
Height
Pierce
Delay
Kerf
Width
@ Rec.
Speed
Plasma (Air) Shield (Air)
Material
Thickness
Pre Flow
Pr e s s ur e
(Air)
Cut Flow Rates / Pressures
Pierce
Delay
Kerf
Width
@ Rec.
Speed
Plasma (Air) Shield (Air)
Arc
Voltage
Torch
Working
Height
Travel
Speed
Initial
Piercing
Height
5
(mm)
2
3
4
