USER GUIDE & SERVICE MANUAL 5 Class ● UHRE524 ● 24” Refrigerator
USER GUIDE u-line.
USER GUIDE u-line.com WELCOME TO U-LINE Congratulations on your U-Line purchase. Your product comes from a company with over five decades of premium modular ice making, refrigeration, and wine preservation experience. U-Line continues to be the American leader, delivering versatility and flexibility for multiple applications including residential, light commercial, outdoor and marine use.
USER GUIDE Integrated Panel Dimensions u-line.com Integrated Frame Dimensions Metric measurements rounded and optimized. BACK SURFACE MUST HAVE AMPLE FLAT SURFACE TO MOUNT OVERLAY FRAME FLAT AND WITHOUT INTERFERENCE INTEGRATED FRAME NOTICE 3/4" (20 mm) 23-1/2" (595 mm) Due to differences in surrounding cabinetry the panel may not perfectly align with door. The procedure below is designed to provide a finished integrated panel that seamlessly integrates with surrounding cabinetry.
USER GUIDE u-line.com HANDLELESS INTEGRATED FRAME 3. Prepare the insert(s) that will back up the handleless design. Wooden Insert – Cut 1/8" (3 mm) thick The following procedure is designed to provide a finished, wooden insert(s) to the dimensions below. handleless frame for a 24" (600 mm) door that seamlessly integrates with its surrounding cabinetry.
USER GUIDE u-line.com Handleless Integrated Frame Dimensions 1/8" (3 mm) Top Design 1/4" (6 mm) 7/8" (22 mm) Ref.
USER GUIDE u-line.com EXTENDED INTEGRATED FRAME 3. Optional: Install handles and hardware. NOTICE Due to differences in surrounding cabinetry the NOTICE panel may not perfectly align with door. The The door panel must not weigh more than 20 lbs procedure below is designed to provide a (10 kg). finished panel that seamlessly integrates with surrounding cabinetry.
USER GUIDE u-line.com Extended Integrated Frame Dimensions BACK SURFACE MUST HAVE AMPLE FLAT SURFACE TO MOUNT OVERLAY FRAME FLAT AND WITHOUT INTERFERENCE 3/4" (20 mm) Integrated Grille If you would like to cover the grille with an integrated panel, purchase U-Line’s adjustable grille accessories. 23-1/2" (595 mm) 24” - Sales Accessory: ULAGRILLE24 Complete instructions, including dimensions of the integrated grille panel, are included with the accessory.
