Specification Sheet
14"
(356 mm)
17" (432 mm)*
26-1/16"
(662 mm)
9" (229 mm)
*Add 1-1/2" For Water Line Clearance
15 3/32”
(383 mm)**
**Applies to SS1095FC
Model SS1095
Amps: Running (115v) 2.5 amps
Amps: Running (220-240v) 1.2 amps
Amps: Max Start Up (115v) 18 amps
Amps: Max Start Up (220-240v) 6 amps
Control Type
Defrost Type Manual
Dimensions (NF): Product Depth 17” (432 mm)
Dimensions (NF): Product Height
Dimensions (NF): Product Width 14” (356 mm)
Dimensions (FC): Product Depth 17” (432 mm)
Dimensions (FC): Product Height
Dimensions (FC): Product Width
Dimensions (FD): Product Depth 17" (432 mm)
Dimensions (FD): Product Height
Dimensions (FD): Product Width
ENERGY STAR N/A
Ice Production Per Day 23 lb (10,4 kg)
Ice Storage 12 lb (5,4 kg)
Product Weight: Max 60 lb (25 kg)
Refrigerant Type R134A
No
No additional clearance around sides, top or rear of
unit is needed for ventilation.
Cut-Out
Height
26-1/16"
(662 mm)
Filler Panel (Not Provided by U-Line) –
Needed to Attach Mounting Flange on Unit
18-1/2"
(470 mm)
Minimum
See Electrical
Specifications
for Power Supply
14-3/4"
(375 mm)
Cut Out Width
3/4"
(19 mm)
Minimum Flange
Mounting Area
3/4"
(19 mm)
Minimum Flange
Mounting Area
4"
(102 mm)
7"
(178 mm)
Preferred location
for water line and
electrical outlet is
in adjacent
cabinet.
5/8"
(16 mm)
Warranty
plus
eligible
1
warrantywarranty
179
SS1095
Marine Series • 14” Marine Crescent Ice Maker
DIMENSIONS SPECIFICATIONS
INSTALLATION NOTES
UL listing only applies to 115 v models.
CE only applies to 220-240v models.
CABINET CUT-OUT
Please visit u-line.com to view this model’s User Guide & Service
Manual. All Specications are subject to change without notice.
