Datasheet Managed Gigabit Switches with SFP Models: US-24, US-48 Non-Blocking Throughput Switching Performance Gigabit Ethernet RJ45 Ports SFP+/SFP Fiber Connectivity Options
Datasheet Overview Switching Performance Fiber Connectivity Build and expand your network with Ubiquiti Networks® UniFi® Switch, part of the UniFi line of products. The UniFi Switch offers the forwarding capacity to simultaneously process traffic on all ports at line rate without any packet loss. Each model includes two SFP ports for uplinks of up to 1 Gbps.
Datasheet UniFi Controller Designed for convenient management, the UniFi Controller software allows admins to configure and monitor the UniFi Switch and other UniFi devices using a graphical user interface. You can download it from www.ubnt.com at no extra charge – there is no separate software, licensing, or support fee. Multi-Site Management A single instance of the UniFi Controller running in the cloud can manage multiple UniFi sites within a centralized interface.
Datasheet Models Model: US-24 • • • • • • • • (24) Gigabit RJ45 Ports (2) SFP Ports (1) Serial Console Port Non-Blocking Throughput: 26 Gbps Switching Capacity: 52 Gbps Forwarding Rate: 38.69 Mpps Maximum Power Consumption: 25W Rack-Mountable Model: US-48 • • • • • • • • • (48) Gigabit RJ45 Ports (2) SFP+ Ports (2) SFP Ports (1) Serial Console Port Non-Blocking Throughput: 70 Gbps Switching Capacity: 140 Gbps Forwarding Rate: 104.
US-24 Dimensions Weight 443 x 43 x 221 mm (17.44 x 1.69 x 8.70") Rack-Mount Brackets Excluded Rack-Mount Brackets Included 2.51 kg (5.53 lb) 2.60 kg (5.70 lb) Networking Interfaces (24) 10/100/1000 Mbps RJ45 Ethernet Ports (2) 1 Gbps SFP Ethernet Ports Management Interface (1) RJ45 Serial Port Out-of-Band, Ethernet In-Band Total Non-Blocking Throughput 26 Gbps Switching Capacity 52 Gbps Forwarding Rate 38.
Switch Datasheet Datasheet Hardware Specifications US-48 Dimensions Weight 443 x 43 x 286 mm (17.44 x 1.69 x 11.26") Rack-Mount Brackets Excluded Rack-Mount Brackets Included 3.56 kg (7.85 lb) 3.65 kg (8.
