Data Sheet
Hardware Specications
US‑24
Dimensions 443 x 43 x 221 mm (17.44 x 1.69 x 8.70")
Weight Rack-Mount Brackets Excluded Rack-Mount Brackets Included
2.51 kg (5.53 lb) 2.60 kg (5.70 lb)
Networking Interfaces (24) 10/100/1000 Mbps RJ45 Ethernet Ports
(2) 1 Gbps SFP Ethernet Ports
Management Interface (1) RJ45 Serial Port Out‑of‑Band, Ethernet In‑Band
Total Non‑Blocking Throughput 26 Gbps
Switching Capacity 52 Gbps
Forwarding Rate 38.69 Mpps
Power Method 100‑240VAC/50‑60 Hz, Universal Input
Power Supply AC/DC, Internal, 25W DC
Max. Power Consumption 25W
LEDs per Port Speed/Link/Activity
Sound Level Fan Level: 0 Fan Level: 1
34 dBa 37 dBa
ESD/EMP Protection Air: ± 24 kV, Contact: ± 24 kV
Rack Mount Yes, 1U High
Shock and Vibration ETSI300-019-1.4 Standard
Operating Temperature ‑5 to 40° C (23 to 104° F)
Operating Humidity 5 to 95% Noncondensing
Certications CE, FCC, IC
