Leading by reputation.

Call your Toro distributor at 800-803-8676

• Powerful Tier 4 compliant engines –

featuring Yanmar® 3-cylinder, liquid-cooled,

diesel engines.

• Proven Reliability & Performance – time

tested platform delivers exceptional durability,

high performance and versatility.

• Enhanced climbing and hillside stability –

CrossTrax® all-wheel drive system is based

on the Toro patented Series/Parallel™ design.

If one of the front tires begins to slip, power

is transferred to the opposite rear tire for

optimum traction.

• Precise Monitoring & Control – an onboard

InfoCenter allows viewing and changing of

settings. It also provides essential information

about service intervals, diagnostics and

faults. Toro’s Mow Speed Limiter is a simple

mechanical design which produces consistent

results regardless of the operator.

• Unparalleled Operator Comfort – with a

tilt steering wheel and easy-access steps for

every size operator, to a deluxe suspension

seat, and a well thought out design that

moved the radiator to the rear of the engine

compartment to move heat rejection

and noise away from operator,

these fairway mowers are

designed for a comfortable,

all-day operation.

• Outstanding Quality of Cut –

Dual Precision Adjustment (DPA)

cutting units – featuring Toro’s

all new EdgeSeries™ reels combine

to deliver a consistent, high quality cut

and superior after cut appearance, while

reducing maintenance with improved reel

edge retention.

FEATURES

Reelmaster

5410/5510/5610

FAIRWAY MOWERS

Performance, productivity and quality are just words if a piece of equipment has not

earned them through actual customer usage. After 10 years of satisfying customers,

the Reelmaster 5410, 5510 and 5610 have earned a reputation for delivering exceptional

performance, maximum productivity and high quality. And we haven’t stood still over the

years. Toro spends a lot of time listening closely to our customers to better understand

their evolving requirements. Based on customer input, Toro engineers continually work to

refine and improve each fairway mower to meet those needs. Everything from operator

comfort and efficiency, to tractor performance, to cutting unit

after-cut-appearance improvements, and even ease of

maintenance is reviewed in our relentless effort to maximize

productivity and efficiency.

EdgeSeries

™

Reels

Summary of content (7 pages)

PAGE 1
Reelmaster 5410/5510/5610 ® FA I R WAY M O W E R S F E A T U R E S •P owerful Tier 4 compliant engines – featuring Yanmar® 3-cylinder, liquid-cooled, diesel engines. • Proven Reliability & Performance – time tested platform delivers exceptional durability, high performance and versatility. • Enhanced climbing and hillside stability – CrossTrax® all-wheel drive system is based on the Toro patented Series/Parallel™ design.
PAGE 2
Reelmaster 5410 / 5410-D Specifications ® * REELMASTER 5410 DIESEL, MODEL 03675 ENGINE REELMASTER 5410-D TIER 4 DIESEL, MODEL 03606 Kubota® 4-cylinder, liquid cooled, diesel engine. 35.5 hp (26.5 kW) @ 3000 rpm. LUBRICATION Pressurized lubrication system with 5.0 quart (4.7 liter) capacity. FUEL FILTER Replaceable spin-on fuel filter/water separator. AIR CLEANER Heavy-duty three-stage, radial seal air cleaner with restriction indicator.
PAGE 3
Reelmaster 5410 / 5410-D Accessories* ® 8-BLADE CUTTING UNIT, MODEL 03621 11-BLADE CUTTING UNIT, MODEL 03623 TYPE 5-plex, hydraulically driven, balanced cutting units with adjustable rear weight transfer spring. Cutting units feature quick disconnect for removal/installation and are interchangeable to all positions. Cutting units also feature rear throw capability. SIZE 22" (56 cm) wide, 5" (12.7 cm) diameter, 8 & 11" blade cutting units. WIDTH OF CUT 100" (254 cm) HOC RANGE 0.25”-1.5” (6.4-38.
PAGE 4
Reelmaster 5510 / 5510-D Specifications ® * REELMASTER 5510, MODEL 03676 ENGINE REELMASTER 5510-D (A), TIER 4 DIESEL, MODEL 03607 Kubota® 4-cylinder, liquid cooled, diesel engine. 35.5 hp (26.5 kW) @ 3000 rpm. LUBRICATION Pressurized lubrication system with 5.0 quart (4.7 liter) capacity. FUEL FILTER Replaceable spin-on fuel filter/water separator. AIR CLEANER Heavy-duty three-stage, radial seal air cleaner with restriction indicator.
PAGE 5
Reelmaster 5510 / 5510-D Accessories ® * 8 AND 11-BLADE CUTTING UNITS, MODELS 03638, 03639 AND 03641 TYPE 5-plex, hydraulically driven, balanced cutting units with adjustable rear weight transfer spring. Cutting units feature quick disconnect for removal/installation and are interchangeable to all positions. Cutting units also feature rear throw capability. SIZE 22" (56 cm) wide, 7" (17.8 cm) diameter, 8 and 11 blade cutting units. WIDTH OF CUT 100" (254 cm) HOC RANGE 0.25”-1.5” (6.4-38.
PAGE 6
Reelmaster 5610 Specifications ® ENGINE * REELMASTER 5610 4WD, MODEL 03678 REELMASTER 5610-D 4WD, MODEL 03679 Kubota 4-cylinder, liquid cooled, diesel engine. 44.2 hp (33 kW) @ 3000 rpm. Yanmar® 3-cylinder, liquid cooled, turbo-diesel engine. 43.5 hp (32.4 kW), 74.4 ft. lbs. (105 Nm) torque, 1.64 liter displacement. Tier 4 Final Compliant. ® LUBRICATION Pressurized lubrication system with 5.0 quart (4.7 liter) capacity. FUEL FILTER Replaceable spin-on fuel filter/water separator.
PAGE 7
Reelmaster 5610 Accessories ® * 8 AND 11-BLADE CUTTING UNITS, MODELS 03638, 03639 AND 03641 TYPE 5-plex, hydraulically driven, balanced cutting units with adjustable rear weight transfer spring. Cutting units feature quick disconnect for removal/installation and are interchangeable to all positions. Cutting units also feature rear throw capability. SIZE 22" (56 cm) wide, 7" (17.8 cm) diameter, 8 and 11 blade cutting units. WIDTH OF CUT 100" (254 cm) HOC RANGE 0.25”-1.5” (6.4-38.
