Specification

6 1/8"
156mm
8 7/16"
214mm
8 1/4"
210mm
5 13/16"
148mm
JHB
Product Specifications:
5AFL06
by
2
Accessories
ASME A112.18.1 / CSA B125.1
NSF 61 - Section 9
ANSI A117.1 (ADA)
1:4
Architect/Engineer_________________________________
Model Number
Contractor_______________________________________
Customer/Wholesaler______________________________
Model Specified_____________________ Quantity______
equip.tsbrass.com
Phone: [phone] Fax: [phone]
6" Swing Nozzle & Full Flow Laminar Device
equip Add-On Faucet, Quarter-Turn Ceramic Cartridge,
Travelers Rest, South Carolina 29690
2 Saddleback Cove, P.O. Box 1088
NSF 372 (Low Lead Content)
Scale:JRM Date:Checked:
Drawn:
Approved:KJG
Sheet: 1
of
This Space for Architect/Engineer Approval
Job Name__________________________Date_________
Product Compliance:
equip
Foodservice
10/24/16
w/ Full Flow
Swivel Joint
Laminar Device
5SP-06
6" Swing Nozzle
3/8" NPT
Male Thread
Quarter-Turn Ceramic
Cartridge w/ equip
Lever Handle
3/8" NPT
Female
Thread
3 5/8"
92mm
4 13/16"
122mm
