Data Sheet

MPU-6000/MPU-6050 Product Specification
Document Number: PS-MPU-6000A-00
Revision: 3.4
Release Date: 08/19/2013
33 of 52
9 Digital Interface
9.1 I
2
C and SPI (MPU-6000 only) Serial Interfaces
The internal registers and memory of the MPU-6000/MPU-6050 can be accessed using either I
2
C at 400 kHz
or SPI at 1MHz (MPU-6000 only). SPI operates in four-wire mode.
Serial Interface
Pin Number
MPU-6000
MPU-6050
Pin Name
Pin Description
8
Y
/CS
SPI chip select (0=SPI enable)
8
Y
VLOGIC
Digital I/O supply voltage. VLOGIC must be ≤ VDD at all times.
9
Y
AD0 / SDO
I
2
C Slave Address LSB (AD0); SPI serial data output (SDO)
9
Y
AD0
I
2
C Slave Address LSB
23
Y
SCL / SCLK
I
2
C serial clock (SCL); SPI serial clock (SCLK)
23
Y
SCL
I
2
C serial clock
24
Y
SDA / SDI
I
2
C serial data (SDA); SPI serial data input (SDI)
24
Y
SDA
I
2
C serial data
Note:
To prevent switching into I
2
C mode when using SPI (MPU-6000), the I
2
C interface should be disabled by
setting the I2C_IF_DIS configuration bit. Setting this bit should be performed immediately after waiting for the
time specified by the “Start-Up Time for Register Read/Write” in Section 6.3.
For further information regarding the I2C_IF_DIS bit, please refer to the MPU-6000/MPU-6050 Register Map
and Register Descriptions document.
9.2 I
2
C Interface
I
2
C is a two-wire interface comprised of the signals serial data (SDA) and serial clock (SCL). In general, the
lines are open-drain and bi-directional. In a generalized I
2
C interface implementation, attached devices can
be a master or a slave. The master device puts the slave address on the bus, and the slave device with the
matching address acknowledges the master.
The MPU-60X0 always operates as a slave device when communicating to the system processor, which thus
acts as the master. SDA and SCL lines typically need pull-up resistors to VDD. The maximum bus speed is
400 kHz.
The slave address of the MPU-60X0 is b110100X which is 7 bits long. The LSB bit of the 7 bit address is
determined by the logic level on pin AD0. This allows two MPU-60X0s to be connected to the same I
2
C bus.
When used in this configuration, the address of the one of the devices should be b1101000 (pin AD0 is logic
low) and the address of the other should be b1101001 (pin AD0 is logic high).
9.3 I
2
C Communications Protocol
START (S) and STOP (P) Conditions
Communication on the I
2
C bus starts when the master puts the START condition (S) on the bus, which is
defined as a HIGH-to-LOW transition of the SDA line while SCL line is HIGH (see figure below). The bus is
considered to be busy until the master puts a STOP condition (P) on the bus, which is defined as a LOW to
HIGH transition on the SDA line while SCL is HIGH (see figure below).
