Data Sheet

MPU-6000/MPU-6050 Product Specification
Document Number: PS-MPU-6000A-00
Revision: 3.4
Release Date: 08/19/2013
5 of 52
1 Revision History
Revision
Date
Revision
Description
11/24/2010
1.0
Initial Release
05/19/2011
2.0
For Rev C parts. Clarified wording in sections (3.2, 5.1, 5.2, 6.1-6.4, 6.6, 6.9, 7,
7.1-7.6, 7.11, 7.12, 7.14, 8, 8.2-8.4, 10.3, 10.4, 11, 12.2)
07/28/2011
2.1
Edited supply current numbers for different modes (section 6.4)
08/05/2011
2.2
Unit of measure for accelerometer sensitivity changed from LSB/mg to LSB/g
10/12/2011
2.3
Updated accelerometer self test specifications in Table 6.2. Updated package
dimensions (section 11.2). Updated PCB design guidelines (section 11.3)
10/18/2011
3.0
For Rev D parts. Updated accelerometer specifications in Table 6.2. Updated
accelerometer specification note (sections 8.2, 8.3, & 8.4). Updated qualification
test plan (section 12.2).
10/24/2011
3.1
Edits for clarity
Changed operating voltage range to 2.375V-3.46V
Added accelerometer Intelligence Function increment value of 1mg/LSB
(Section 6.2)
Updated absolute maximum rating for acceleration (any axis, unpowered) from
0.3ms to 0.2ms (Section 6.9)
Modified absolute maximum rating for Latch-up to Level A and ±100mA (Section
6.9, 12.2)
11/16/2011
3.2
Updated self-test response specifications for Revision D parts dated with
date code 1147 (YYWW) or later.
Edits for clarity
Added Gyro self-test (sections 5.1, 6.1, 7.6, 7.12)
Added Min/Max limits to Accel self-test response (section 6.2)
Updated Accelerometer low power mode operating currents (Section 6.3)
Added gyro self test to block diagram (section 7.5)
Updated packaging labels and descriptions (sections 11.8 & 11.9)
5/16/2012
3.3
Updated Gyro and Accelerometer self test information (sections 6.1, 6.2, 7.12)
Updated latch-up information (Section 6.9)
Updated programmable interrupts information (Section 8)
Changed shipment information from maximum of 3 reels (15K units) per shipper
box to 5 reels (25K units) per shipper box (Section 11.7)
Updated packing shipping and label information (Sections 11.8, 11.9)
Updated reliability references (Section 12.2)
8/19/2013
3.4
Updates section 4
