Specification

rev January 23, 2015 4:23 PM
PRODUCT INFORMATION
LED Lifetime (Hrs):
36,000
Input Voltage (V):
120V
Power Draw (W):
10.5W
Fixture Height:
3 in. (74mm)
Trim Width:
4.9 in. x 4.9 in. (125mm x 125mm)
DLQ4
4” Downlight Square
Product Description
Circle gets the square. The DLQ4 from NICOR® is a square trim 4” recessed LED
Everything you love about the DLR4 is now available with the aesthetics of a square
while achieving a light output to over 690 lumens. The enriched 90+ CRI light output
provides superior color quality. Not only is the light quality better, but this design
improvement meets new industry standards like Title 24.
Construction
Die cast aluminum trim routes heat away from electrical components
Optical System
Electrical
Utilizes high performing LEDs with greater than 90 CRI and an R9 greater than 50
Dimmable to 10% with most standard dimmers
Operating temperature rating of 0°F to 120°F (-18°C – 49°C)
Input voltage of 120V
L70 rated for greater than 36,000 hours
LM-79, LM-80 testing performed in accordance with IESNA standards.
Finish
Installation
Compatible with most 4” recessed housings
Quick and easy installation with a screw-in Edison base (GU24 socket string available) and friction
clip mounting system
Warranty
5-year limited system warranty standard
Ordering Information
Series Version Voltage CCT’s Trim Color
DLQ4 10 (1.0) 120 2K (2700) WH (white)
3K (3000)
4K (4000)
Example: DLQ4-10-120-3K-WH
4.9”
125mm
3”
74mm
Type
Date
Project
5 YEAR
WARRANTY
