Specification

ManualsBrandsUnbranded ManualsElectricalPush-In Wire Connector, 6 Wires, Purple (50-Pack)
1
*Large wire range: accommodates 22-12 AWG solid or stranded copper wire
*Fast, safe and reliable installation saves time and money
*No twisting or taping of conductors required
*Just strip the wire, insert the connector and you are done
*One wire per opening ensures loose connections are eliminated
*Made of strong, UL94V-2 flame retardant polycarbonate
*Rated 600 volts (up to 1,000 volts for fixtures and signs)
*Temperature range from -40F to 221F (-30C to 105C)
*Integrated test port enables continuity testing
*Color coded for easy identification
*Compact design perfect for tight spaces
Catalog
Number
Figure Wire Range Color
No. of
Wires
E A B C D Temp Rating
Max
Voltage
Standard
Package Qty
Easy-Twist™ Push-In Wire Connectors PIWC Series
8
6
5
4
3
2
Drawn - SD
Approved - KM
Title - Easy-Twist™ Push-In Wire Connectors
PIWC-2-C
PIWC-2-B
1
22-12 AWG
Yellow
0.035
0.748
0.463
0.411
105 C
600 V
100
500
PIWC-3-C
PIWC-3-B
2
22-12 AWG
Orange
0.035
0.748
0.626
0.411
105 C
600 V
100
500
PIWC-4-C
PIWC-4-B
3
22-12 AWG
Clear
0.035
0.748
0.789
0.411
105 C
600 V
75
400
PIWC-5-C
PIWC-5-B
4
22-12 AWG
Blue
0.035
0.748
0.953
0.411
105 C
600 V
50
300
PIWC-6-C
PIWC-6-B
5
22-12 AWG
Purple
0.035
0.748
1.116
0.411
105 C
600 V
50
250
PIWC-8-C
PIWC-8-B
6
22-12 AWG
Grey
0.035
0.748
1.443
0.411
105 C
600 V
40
200
Figure 1
Figure 2
Figure 3
Figure 4
Figure 5
Figure 6
