Specification
PO Box 15732 Brooksville, FL 34604- Phone: 888-987-8877, Fax 850-654-3844 – www.surgestore.com
2019 SurgeStore.com
®
. Rev Date 7/1/2019
Page 1 of 1
Doc # SS06761
2222222222222222222222222222
Product Features
NEMA 4X watertight enclosure for
indoor/outdoor environments.
LED diagnostic indicates power and surge
protection
Parallel connecting device connects to a
dedicated circuit breaker, allowing unit to be
replaced without removing power to other
loads.
Applications
Residential Applications
Small Office / Home Office
Well Pumps, Motors and HVAC Equipment
Dimensions
3.55” L x 2.89” W x 1.64” H
Spike Stopper® RESI
SM02B211
Specifications
Protection Modes:
L-L, L-G
Total Surge
Current Rating:
50 kA
Nominal Discharge
Current Rating (l
n
):
10 kA
Short Circuit
Current Rating:
200 kA
Mechanical Characteristics
Enclosure
NEMA 4X Watertight
Conduit Size:
½” NPT Parallel Wired
Temperature Rating:
-40°C to 75°C
Diagnostics:
LED On = Good
LED Off = check power and/or replace unit
Standards, Quality, and Approval
SPD Type:
Type 1
Product Certifications
Type 1 SPD, ANSI/UL 1449 (VZCA)
Warranty:
5 Year Limited Warranty
The Spike Stopper RESI is a cost-effective
Surge Protective Device (SPD) designed for
residential applications. The Spike Stopper
RESI protects against the damaging effects of
electrical surges in a compact, easy to install
indoor/outdoor rated device. The Spike
Stopper RESI is designed for 120/240
electrical systems commonly found in North
American residential applications.
