Technical Specifications

# 7 Foundation Weep Screed
The information and recommendations contained herein are, to the best of Phillips Manufacturing Company’s knowledge and belief, accurate and relia ble as of the date issued. Phillips Manufacturing Company has no
control over the conditions of handling and use, and makes no warranty regarding the results obtained from the use of this data. The information and recommendations are offered for the user’s consideration and
examination, and it is the user’s responsibility to determine that they are suitable and complete for its particular use. Phillips reserves the right to make alterations and amendments to the detailed specifications at its
discretion. Phillips disclaims responsibility for all actions, proceedings, liabilities, claims, damages, cost, losses, and expenses in relation to, or arising out of, incorrect utilization of this information.
Version 1.1 / Page 1 of 1
©2012 Phillips Manufacturing Company
Product Benefits
Phillips #7 Foundation Weep Screed provides a stucco stop and screed
at the sill plate line in exterior stucco applications. This product
features many benefits:
 Punched weep holes enable keying as well as moisture weeping
 Perforated flanges aid attachment and plaster keying
 3-1/2” nailing flange meeting applicable code requirements
 Nailing flange serves as a straight-edge stop at the sill plate line
and flashing when water-resistant paper or paperbacked lath is
installed over flange
 G90 Hot Dip Galvanized coating
Certification
Phillips #7 Foundation Weep Screed meets or exceeds ASTM C 1063
Standard Specification for Installation of Lathing and Furring to Receive
Interior and Exterior Portland Cement-Based Plaster.
Storage
Avoid bending or other damage and store in a dry place protected from
moisture.
Installation Recommendations
Phillips recommends installation in accordance with applicable ASTM
standards and using prevalent industry standards. Reference materials
include ASTM C 841, ASTM C 1063 and Phillips Manufacturing’s
website (www.phillipsmfg.com).
Made in the U.S.A.
Phillips is proud that all our beads, trims and accessories, including Phillips #7 Foundation Weep Screed, are made in
the United States of America.
Submittal Approvals:
Job Name: _________________________________________________________________
Contractor: __________________________________________ Date: _________________
Drawing not to scale
