60" Pine Straw/Debris Rake OWNER’S MANUAL WARNING: Carefully read and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury.
Thank you very much for choosing this product! For future reference, please complete the owner’s record below: Model: YTF-60PSR Purchase Date: _______________ Save the receipt, the warranty, and these instructions. It is important that you read the entire manual to become familiar with this product before you begin using it. This product is designed for certain applications only. The manufacturer cannot be responsible for issues arising from modification.
SAVE THESE INSTRUCTIONS WORK AREA • Keep work area clean, free of clutter, and well-lit. Cluttered and dark work areas can cause accidents. • Keep children and bystanders away while operating the Pine Straw/Debris Rake. Distractions can cause you to lose control, so visitors should remain at a safe distance from the work area. • Be alert of your surroundings. Using a Pine Straw/Debris Rake in confined work areas may put you dangerously close to sharp tools and rotating parts.
ASSEMBLY Step #1: Assemble the Connection Plate (#25), the Right Angle Steel Section (with chain eyelet) (#28) and the Left Angle Steel Section (#29) using four 1/2” x 1-1/2” Hex Bolts (#30) and four 1/2” Smaller Nylon Nuts (#36). Step #2: Assemble the twenty-two Single Tines (#27) and the two Tine Sections (#26) to the Right Angle Steel Section (#28) and the Left Angle Steel Section (#29) using twenty-four 1/2” x 1-1/2” Hex Bolts (#30), three pressure plates (#31), and twenty-four 1/2” Nylon Nuts (#23).
Step #4: Assemble the Tongue (#12) to the Axle Frame (#17) using two 3/8” x 2-1/2” Hex Bolts (#9) and two 3/8” Nylon Nuts (#5). Step #5: Assemble the two Axle Mounting Brackets (#20) to the Axle Frame (#17) using four Hex 3/8” x 2-1/2” Bolts (#9) and four 3/8” Nylon Nuts (#5). . Step #6: Attach the two Pneumatic Tires (#18) to Axle Frame (#17), and secure with two 9/16” Nylon Nuts(#35). Step #7: Connect the Spring Assembly to the Axle Assembly with two 1/2” x 1-1/2” Hex Bolts (#30) and two 1/2” Nylon Nuts.
Step #8: Assemble the Lift Handle Support (#6) to the Tongue (#12) using two 3/8” x 2-1/2” Hex Bolts (#9) and two 3/8” Hex Lock Nuts (#5). Step #9: Assemble the Lift Handle C (#3) to the Lift Handle Support (#6) using one 3/8” x 3” Hex Bolt (#34), one Big Washer (#7), one Spring (#8), one Washer (#16), and one 3/8” Nylon Nut (#5). Step #10: Attach the Lift Handle B (#2) and the Lift Handle A (#1) to the Lift Handle C (#3) using four 3/8” x 1” Hex Bolts (#4) and four 3/8” Nylon Nuts (#5).
MAINTENANCE • Maintain your Pine Straw/Debris Rake. It is recommended that the general condition of any Pine Straw/Debris Rake be examined before it is used. Keep your Pine Straw/Debris Rake in good repair by adopting a program of conscientious repair and maintenance. If any abnormal vibrations or noise occurs, have the problem corrected before further use. Have necessary repairs made by qualified service personnel. • Do not exceed 30 PSI in each wheel.
PARTS LIST: Part # Description Qty. Part # Description Qty. 1 1 1 4 13 1 21 23 24 25 26 27 Tine Assembly Mounting Bracket Nylon Nut 1/2” Hex Bolt 1/2” x 1” Connection Plate Tine Section Single Tine Right Angle Steel Section (with chain eyelet) Left Angle Steel Section 2 30 4 1 2 22 1 2 3 4 5 6 Lift Handle A Lift Handle B Lift Handle C Hex Bolt 38/” x 1” Nylon Nut 3/8” Lift Handle Support 7 Washer 1/2” 1 28 Spring Ф36.5 *Ф19.
