Introduction Your BCD996T scanner is a state-of-the-art scanner radio with Trunk Tracker IV™ and automatic scanning capabilities. You can store in the dynamic memory conventional frequencies such as police, fire/emergency, marine, air, amateur, and other communications. You can store and scan services that use Trunked Radio Systems and so much more.
Lower Edge 806.0000 849.0125 894.0125 1240.0000 Frequency (MHz) Upper Edge Modulation 823.9875 NFM 868.9875 NFM 956.0000 NFM 1300.0000 NFM Step (kHz) 12.5 12.5 12.5 25.0 Note: The scanner’s frequency coverage is not continuous and does not include the cellular telephone or UHF TV bands. Feature Highlights General DIN-E and ISO Vehicle Mountable — using an included DIN-E sleeve or a standard ISO technique, the scanner can be easily mounted in most vehicles.
FM Broadcast, Military, Air, and Special searches, to make it easy to search for specific transmissions. “Soft” Search Keys — Lets you quickly search specified ranges. Channel Lockout — You can lock out any system, group, frequency, or channel while scanning. If you lock out a system or group, any channels belonging to that system or group are also locked out. Frequency Lockout — You can lock out up to 500 frequencies (250 permanently locked out + 250 temporarily locked out).
Custom Alerts — For each alert in the scanner (such as channel alert, Close Call alert, emergency alert), you can select from 9 different tone patterns and also set the alert volume level independently from the main volume level. Automatic Channel Step — Accepts frequencies on any valid channel step, even if it does not fall within the band plan’s default step. Frequency Step — Lets you select a frequency step (5, 6.25, 7.5, 8.33, 10, 12.5,15, 20, 25, 50 or 100 kHz) for manual mode and search mode.
Multi-Site Trunking — Lets you share system channels across multiple sites to more efficiently use the scanner’s memory and more easily select sites to monitor. Control Channel Only Scanning — If the scanner is set to scan a Motorola system, you can set it so it scans using only control channel data. You do not have to program voice channel frequencies into memory in this mode as long as all possible control channels are programmed.
CTCSS/DCS Search — Lets the scanner search for CTCSS or DCS tones or codes on any channel or during a search. The scanner can identify up to 50 CTCSS tones and 104 DCS codes. Quick Search — Lets you search from the currently-tuned frequency if you are searching a conventional system. Auto Store Frequency AutoStore — Automatically stores all active frequencies into the selected conventional system. Talk Group ID AutoStore — Automatically stores all new talk group ID’s into a channel group you select.
Memory Storage Limits Systems 500 Sites 1000 Sites per Systems 256 20 Channels per Conventional Systems 1000 Groups per System 6000 Channels per Trunked Systems 250 Total Channels Trunked Frequencies per Site* 750-1000 * depending on the number of TGID in the system.
To use F tap the Scroll Control. This action is written in shorthand as F which is fully explained in the next section. When you tap the control f appears and remains in the upper left corner of the display for 3 seconds. During this time, press any button to access the button’s second function. Or, press and hold the Scroll Control for 2 seconds. The scanner beeps, and the function is “latched” so that is does not return to normal mode until you tap the Scroll Control again.
A Short User’s Guide to Assist the First-Time Scanner Enthusiast Welcome to the family of Uniden scanner users. You have just unpacked your Uniden BCD996T scanner. You are anxious to scan and hear something so you rotate the [VOL/POWER] control and wait a moment as the opening Message and Copyright screens confirm the model information. Then, if you live in a residential area, you probably hear nothing or very little. Why? The reason is simple.
2. Program the system based on the plan. Enclosed with the materials provided with your scanner is a reprinted article from Popular Communications, which, in clear, easy-to-understand language, tells you how to start the programming session. The article also includes a glossary of terms and other valuable data. Be sure to take time out to look it over before proceeding. To provide you with useful sized worksheets and instructions to complete them, we have established links at our company website.
Understanding Scanning and the BCD996T This section provides you with additional background on how scanning works and how your scanner provides that feature. You don’t really need to know all of this to use your scanner, but some further background knowledge will help you get the most from your BCD996T. Understanding the Scanner’s Memory Your scanner’s memory is organized in an architecture called Dynamic Allocated Channel memory.
channels, then press the GQK within 2 seconds. Systems can have up to 20 channel groups, and multiple channel groups can be assigned to the same GQK. What is Scanning? Unlike standard AM or FM radio stations, most two-way communications do not transmit continuously. Your BCD996T scans programmed channels until it finds an active frequency, then stops on that frequency and remains on that channel as long as the transmission continues.
even interfere with each other to the point where it is impossible to clearly receive any of the stations. A scanner, such as your BCD996T, equipped with CTCSS and DCS, can code each received frequency with a specific sub-audible CTCSS or DCS frequency or code. Then, when you receive multiple signals, you only hear the transmission with the CTCSS or DCS tone you programmed. If you do not receive the correct tone with a signal, the scanner’s squelch remains closed and you hear nothing.
Repeater Operation Repeater systems use two frequencies: one transmits from the radio to a central repeater; the other transmits from the repeater to other radios in the system. With a repeater-based system, the repeater is located on top of a tall building or on a radio tower that provides great visibility to the area of operation. When a user transmits (on an input frequency), the signal is picked up by the repeater and retransmitted (on an output frequency).
Trunked Scanning While conventional scanning worked great while there were only a few groups wanting to use the frequencies, with the advent of smaller, lower-cost radios more and more agencies and businesses wanted to take advantage of the utility of 2-way radio. As a result, the bands that were used most became full, so new users were not able to take advantage of the technology as quickly as they wanted.
channels (typically 10, 20, or 28 total channels). When a user presses Push To Talk (PTT) to transmit, their radio first sends the person’s talk group information to the control channel. The computer then assigns that talk group to a specific voice channel and transmits that data over the control channel. All radios in that talk group switch over to the assigned voice channel and the user can begin speaking. This all typically takes place in about a second.
radios in that talk group will switch to the correct channel. To program an EDACS system in your scanner, you will need to know both the frequencies used by the system and the LCN for each frequency. Agency-Fleet-Subfleet — talk group ID’s for EDACS systems are assigned in a way that makes it easy to see at a glance the affiliation of the user. Each radio is assigned a 2-digit agency identifier from 00 — 15.
data matches a talk group ID that you have stored in the talk group ID list and have not locked out. LTR systems are frequently programmed so that each radio has a unique user ID. Startup Configuration Setup/Operation The Startup Configuration option lets you quickly and automatically lock and unlock systems based on your desired configuration. Simply hold down a number button while powering on the scanner or while the opening screens are displayed.
I-Call (Motorola/EDACS) I-calls are direct unit-to-unit transmissions that are not heard by other system users. Your BCD996T can receive I-call transmissions. See “Setting I-Call (Motorola and EDACS Systems Only)” on Page 72 for more information about monitoring I-call transmissions. Where To Get More Information By itself, this manual only provides part of what you need to know to have fun scanning — how to program and use the scanner. Other sources provide additional information.
Included With Your Scanner Cigarette Lighter Adapter Power Cord AC Adapter (P/N AD-1009) BCD996T Scanner Three Wire DC Power Cord — See Step 5, “Mounting Using the DIN-E Sleeve” on Page 34 Mounting Bracket and Hardware DIN-E Sleeve and Removal Keys for vehicle installation Remote PC to Scanner Cable (scanner plug to Front PC Connecter) Push-on type Telescopic Antenna Owner’s Manual and Other Printed Material If any of these items are missing or damaged, immediately contact your place of purchase or
Setting Up Your Scanner These guidelines will help you install and set up your new scanner: The BCD996T can be placed on a convenient surface in your home as a base station, and connected to a standard outlet that supplies 120VAC, 60Hz. You must use either the supplied antenna or an electrically correct outdoor antenna, properly and safely mounted at your chosen site. The scanner is also designed to accommodate the DIN-E and ISO-DIN automotive mounting configurations. A DIN-E sleeve is supplied.
BCD996T Desk Surface Wood Screws Bracket Mounting Feet (4) Apply beneath the bracket; between bracket and desk surface. To secure the radio, by means of the mounting bracket, to a surface, follow the steps below: 1. Attach the four protective rubber feet to the mounting bracket when you casually use the scanner on a flat surface. Should you desire to permanently mount the scanner, remove the feet and use wood screws through the bracket as described in Steps 2 and 3. 2.
Insert the connector of the supplied indoor telescoping antenna to the BNC Antenna Connector and apply moderate pressure to secure it. Setting Up an Audio Recording Device or Computer Recording It is best if you plan ahead when you initiate the basic setup of the scanner if you include the components to record incoming reception. You need only an audio recording device which can be controlled by a Voice Operated module (VOX) either externally or from within the unit and the correct connecting cable.
Important: AVOID AIRBAG DEPLOYMENT ZONES. Ignoring this installation concern may result in bodily harm and the inability of the airbag to perform properly. Bracket Star Washers Mounting Screws BCD996T 1. Using appropriate screws or other hardware, secure the bracket. 2. Insert the scanner and insert the bracket knobs to lock the scanner in position. 3. Attach the Cigarette Lighter Power Cord to the rear of the scanner and plug the adapter end into a dash mounted 12V DC socket. 4.
Opening in dash DIN-E Sleeve BCD996T with outer case removed 1. Remove the bracket if previously attached. 2. Remove the four Philips screws on the rear that secure the outer metal case and pull off the case with care. 3. Install the DIN sleeve into the opening in your dashboard, lip facing out. 4. Push out the top and bottom tabs to hold the sleeve firmly in place. 5. Before inserting the scanner in the sleeve, attach the cable from the previously mounted antenna. Attach the DC Power leads.
Removing the Scanner from the DIN-E Sleeve If you plan to connect other devices or wires to the radio, such as a GPS unit, at a later time, you should plan to remove the scanner from the DIN-E sleeve. This is easily done using the provided Removal Keys. Refer to the illustration that shows the removal key(s), on Page 30. Fully insert both Removal Keys into the slots on the left and the right edges of the radio’s dress panel. You cannot remove the radio if only one key is available.
Once the original radio is removed from the vehicle dash and the fit of the scanner is correct, be sure to connect all the power, audio, antenna, and any other cables or wires, to the scanner before the scanner is secured. The following illustration is a typical example of the ISO technique and the general side mounting screw holes often encountered. It does not actually represent your vehicle or your vehicle’s mounting bracket.
WARNING! Never connect anything other than the recommended amplified extension speaker to the scanner’s headphone jack. Damage to the scanner might occur. Connecting an Extension Speaker In a noisy area, an optional amplified extension speaker, positioned in the right place, might provide more comfortable listening. Plug the speaker cable’s 1/8-inch (3.5-mm) mini-plug into your scanner’s back-panel Ext. Sp. Jack.
Controls, Keys, and Functions 15 2 16 1 Antenna Connector Record Out External Spkr 6 5 4 13 7 3 9 8 10 14 11 12 17 DC Adapter DC Vehicle Power In GPS/Remote The knobs and keys on the BCD996T produce several different actions. You can, for example, rotate the knobs as well as press them to achieve a different result. Pressing a key briefly can produce one result while pressing and holding, gives a different result.
Control/Key [Power/VOL] Squelch Label 1 2 Scroll Control and 3 Mode Action All Rotate Power ON — Volume Increase or decrease All Press Backlight enabled and intensity changes: Green Low-Green Medium-Green High-Red Low-Red Medium-Red High Function Press F then tap VOL Rotate Scroll Control Sets APCO threshold All Rotate Sets the Squelch Level to permit strong signals to be heard with no background noise or lower strength signals with some background noise Press Toggle: Close Call DND-CC P
Control/Key [WX] [GPS] [L/O] Label 5 6 7 Mode Action Result WX Scan or WX Alert Scan Press Toggle between WX Scan and WX Alert Scan Other Press Turn to toggle WX Alert Priority On and Off Press & Hold Starts WX Scan All Press Changes to GPS Mode GPS Press & Hold Stores current GPS data F + Press Change GPS Display Press Temporarily locks out a system channel, a search frequency, or location data. Cancelled when Power is turned off.
Control/Key [0] to [9] Label 8 [4] move left [6] move right [.
Control/Key [EYES] Label 10 [SCAN/SEARCH] 11 Mode Action Result MENU Press Use as the key for menu choices Scan Scan Hold Press Edit the channel data for active channel Search Search Hold Close Call Close Call Hold WX Scan WX Scan Hold Press Saves the active frequency Tone-Out Standby Press Switches to Tone Out edit Menu to change Tone Out Settings Scan Hold Press Start Scanning Other than Press Scan or Scan Hold or GPS Instant switch to Scan Mode Search Hold F + Press Toggl
A Look At The Display The display has indicators that show the scanner’s current operating status. The display information helps you understand how your scanner operates. The LCD screens shown here are only a few of many that you will see while in different modes. The ones we show here are more common and will assist you to get started. 㪛㪸㪻㪼㩷㪚㫆㫅㫍㪼㫅㫋㫀㫆㫅㪸㫃 㪚㪪㪠㩷㪦㫇㪼㫉 1. 2. 3. 4. Group Quick Key Site Quick Key Channel Name System Name/ Channel Group Name 5. Hold indicator 6. Signal Strength indicator 7.
Operation Turning On the Scanner and Setting the Squelch To turn the scanner on, rotate [VOL] clockwise. Turn the knob to a comfortable sound level. Rotate the squelch control [SQ] clockwise until you either hear a broadcast or noise just stops. The control is now set for strong signals. If you desire to hear a weaker signal, turn it counter clockwise from that point until you hear background noise once more.
[MENU] Search for… Edit Custom F Select a Custom Range F Search with Scan F Set Startup Key F F Assign all the systems/sites that you want to scan at the same time to the same startup key [0] to [9]. You can only assign a site/system to one startup key. To leave a system unassigned, press [.No]. Scanning Systems To begin scanning preprogrammed or programmed systems, press [SCAN/SEARCH].
Preprogrammed System Tips All systems preprogrammed into the scanner are assigned to a Quick Key. See “Preprogrammed Systems with Quick Keys” on Page 139 for a list of preprogrammed systems and their Quick Key assignments. Notes: • The systems preprogrammed into the scanner are located primarily in major metropolitan areas. • You might hear transmissions on frequencies assigned to very distant stations. This will happen if a local system also uses the same frequency.
Locking/Unlocking Systems Follow these steps to lock out a system so that it does not scan even if its quick key is selected. 1. Tap F to switch to the Function Mode then rotate the control to select the desired system. 2. Press [L/O] to temporarily lock out the system. Temporary L/O appears. Or, quickly press [L/O] twice to permanently lockout the system. Locked Out appears. 3. To unlock temporarily locked out systems, turn power off and then back on.
To toggle between ID Scan and ID Search, press while the scanner is scanning the system. F then press [SCAN/SEARCH] If the scanner does not scan the system long enough for you to easily do this, press F and rotate the Scroll Control to select the changed system. Then, press [SCAN/SEARCH] within 2 seconds. Holding On a System To temporarily hold on a system, tap F. To hold on a different system, tap F then rotate the control to select the system.
If you enter a frequency then press [EYES], the scanner stores it in the Qck Save Grp group in a system called Qck Save Cnv Sys. These groups are created if they do not exist. Then, the scanner prompts you to save other channel settings. If you enter a talk group ID then press [EYES], the scanner stores it into a channel group named Qck Save Grp in the current system.
Toggling the Display Mode To change the display so the channel and frequency or Talk Group ID appear instead of extended channel information, hold on any channel then press F + [0]. The scanner displays Display Mode 2. To return to Mode 1, press F + [0] Mode1 indicates the channel data under the Channel Name. Mode2 indicates the frequencies under the Channel Name for Conventional systems or the TGID number for Trunked systems.
Optimizing P25 Performance You can optimize the scanner’s performance with digital APCO 25 systems. Follow these steps for each system where you can hear APCO 25 traffic. Notes: These steps work only when you can clearly receive the system. If you are in a weak-signal area or receive interference, these steps will not work. These steps do not compensate for weak signals or signals subject to interference.
• The next to last line on the display now shows the digital error rate and the AUTO decode threshold start level (0-20). • The last line on the display shows the decode threshold levels for the system. Allow the scanner to monitor channel activity for several minutes. The error rate should drop for each transmission and the threshold levels should automatically adjust to a more optimal setting. Then, once the threshold level settles to a stable setting, write down these values.
Using the Menu The BCD996T incorporates an effective menu system that lets you make all the necessary setting options required to program the scanner and effectively use the many features. To use the menu, press [MENU]. You immediately see the screen display the menu title at the top and three of ten menu options beneath. Using the Multifunction Scroll Control, you can rotate the control left or right to quickly review all ten listings. The depth of each menu selection is extensive.
Programming General Settings This section covers your scanners general settings. Setting and Using the Backlight The LCD has a backlight that can be set to green or red with three levels of intensity for each color plus OFF. To make your selection, press [VOL]. Each time you press the control, the backlight cycles in the following order.
Manual — Use this setting to manually set the dimmer level to High, Middle, Low, or Off. To guide you in your selection, at each setting the display shows what you can expect to see. Setting the Backlight Color F [MENU] Settings Set Backlight F Set Color F Set this option to either Red or Green. Adjusting the Key Beep [MENU] Settings Adjust Key Beep F F Auto — the scanner automatically sets the key beep to match the master volume setting level you select.
Setting the Display Orientation [MENU] Settings Set Upside-down F F This setting controls the orientation of the display. If you set Upside-down to On, the scanner inverts the display text and graphics. Adjusting the Display Contrast There are 15 contrast levels. As you scroll from level 1 to 15 you see the contrast change. Press the Scroll Control to lock the desired level until the time you desire to change it.
This setting controls the format used for displaying the time on the GPS data screens. 12H — the scanner displays time in 12-hour format using am for mornings and pm for evening times. 24H — the scanner displays time in 24-hour format using 0 for midnight and 23 for 11 pm. Setting the Time Zone [MENU] Settings Set GPS Format F Set Time Zone F F This setting controls the format used for adjusting Universal time to local time. Set your local time’s offset from UTC (formally known as GMT).
For Serial Port Speed (Baud Rate), select from 4800 bps 9600 bps 19200 bps 38400 bps 57600 bps 115200 bps OFF Displaying Scanner Information Viewing Memory Used [MENU] Settings See Scanner Info % Memory Used F F F The scanner displays the percent of memory that is used and the number and the percent of systems, sites and channels that are created. Press any key to return to the previous menu, then press any key to exit the menu.
You are given a last opportunity to keep the factory programmed data when you see the question: Restore Preprogram List? Yes=”E”/”No= ”.” If you do not say Yes, the scanner is totally empty. Connecting Your Scanner to a Personal Computer You can connect your scanner, by means of the supplied cable, to a personal computer to download data from the computer to the memory of the scanner. Before you proceed, you must first set the scanner’s communications speed as described in the previous section.
gender changer (neither included), available at most computer stores. Then you must set one scanner as the source and the other as the target. Connected as shown, and with both ports correctly selected, no other hardware is needed. 1. Select the Front Port for the Master. Select the Rear Port for the Slave or vice versa. 2. Plug the 9-pin serial connector into the unit designated as the Rear Port. 3. Plug the smaller connector into the front port of the unit designated as Front Port. 4.
Programming Your Scanner Your BCD996T comes preprogrammed with over 500 state and local agencies, both analog and digital, selected from the most populous areas in the US. This should let you get started quickly to enjoy your new scanner. However, to get the most enjoyment from your scanner (especially if you do not live near one of these counties), you must customize the programming for your area. To edit an existing system, use the menu to navigate to the system setting you want to change.
System Settings MOTOROLA System Settings CNV EDACS TYPE I P25 / TYPE II Wide /Narrow SCAT LTR See Pages Edit Name • • • • • • P. 67 Edit Sys Option • • • • • • P. 68 • • • • • P. 76 • P. 83 Edit Site Edit Group • • • • Copy System • • • • • • P. 76 Delete System • • • • • • P. 76 LTR See Pages System Options MOTOROLA System Option Settings CNV TYPE I P25/ TYPE II EDACS WIDE/ NARROW SCAT Set Quick Key • P. 68 Set Startup Key • P.
MOTOROLA System Option Settings CNV EDACS LTR See Pages TYPE I P25/ TYPE II WIDE/ NARROW Set I-Call • • • P. 72 Emergency Alert • • • P. 73 • P. 73 EDCS ID Format • • • Rvw ID:Srch L/O • • Clr All L/O IDs • • Set Record Adjust P25 Level 64 • • SCAT • • P. 74 • • P. 74 • • P. 74 P.
Site Settings MOTOROLA TYPE I MOTOROLA P25/TYPE II EDACS Site Setting L T R 800MHz Standard 800MHz Splinter P25 800MHz Standard 800MHz Splinter 900MHz Band VHF Band UHF Band Edit Name • • • • • • • • • • Set Quick Key • • • • • • • • • • • • Set Startup Key • • • • • • • • • • • • Set Frequencies • • • • • • • • • • • • Set Modulation • • • • • • • • Set Attenuator • • • • • • • • • • • • Set Lockout • • • • • • • •
Channel Settings Channel Setting CNV MOT TYPE I MOT TYPE II/P25 EDACS LTR Edit Name • • • • • Edit Frequency • • • • • • • • • Edit TGID Set Audio Type • Set Modulation • Set Attenuator • Set Priority • Set Alert • • • • • Set Record • • • • • Set Lockout • • • • • Copy Channel • • • • • Delete Channel • • • • • New Channel • • • • • Programming Conventional Systems [MENU] Program System F New System F Conventional F Confirm? Yes=”E” / No=”.
Programming Trunked Radio Systems [MENU] Program System New System F Then, select the system type: F MOT TYPE 1 — Motorola Type I systems MOT TYPE 2/P25 — Motorola Type II and APCO 25 systems EDCS WIDE/NARROW — EDACS Wide and Narrow systems EDCS SCAT — EDACS SCAT systems LT — LTR Systems The scanner creates an empty system with a default name of System n x. Note that “n” is a number that increments as you add new systems.
Specifying the Correct System Type In order for trunk tracking to work properly, you have to specify the correct system type when you create the system. Here are some tips for selecting the correct type: • Use online resources, such as the www.radioreference.com database, to identify the system type. • Even though a system has digital channels, it is not necessarily a P25 system.
Notes: • Access single-digit system/site Quick Keys by pressing the single digit on the keypad during scanning. Access two-digit system Quick Keys by pressing [.No] then both digits. • You can assign as many systems to the same quick key as you want. • To be scanned, a system’s Quick Key must be activated and the system must be unlocked. Setting the Startup Key [MENU] Program System Select a conventional system Edit Sys Option F Set Startup Key F C F F Select a startup key from 0-9 or select [.
Setting the System Hold Time [MENU] Program System Select a conventional system Edit Sys Option F Set Hold Time F C F F Set how long the scanner will remain scanning on this system before moving to the next system (up to 255 seconds). Note that the scanner will scan all unlocked channels at least one time, regardless of the system hold time setting.
This setting controls whether the scanner automatically skips channels it identifies as data. This includes channels with either no audio or a constant-level audio source. If turned on, the scanner resumes scanning as soon as it detects the data signal. Setting Location Information [MENU] Program System Select a Conventional system Edit Sys Option F Set LocationInfo F C F F This setting control whether the system is automatically enabled and disabled when you connect a GPS to the scanner.
Setting the Status Bit [MENU] Program System F Select a Motorola Type I or II system Edit Sys Option F Set Status Bit F M F Ignore — the scanner rounds all received ID’s down to the next interval of 16. The default setting is Ignore. Yes — the scanner treats all received ID’s as unique ID’s. Note: Motorola analog systems use talk group ID’s in multiples of 16. ID numbers that fall between these ID’s indicate special status flags for the system.
Off — the scanner ignores I-calls. The default setting is Off. Only — the scanner only tracks I-calls and ignores other radio traffic on the system. Press F to select. Note: To set the I-Call to a wildcard receive condition, press [.No] + [0]. Setting the Emergency Alert Option ME [MENU] Program System F Select a Motorola Type I, II or EDACS Wide/Narrow system Edit Sys Option F Emergency Alert F F Off — the scanner does not alert you to emergency transmissions.
Setting the System Record Option [MENU] Program System Select a system F Edit Sys Option F Set Record F MELCS F This setting controls how the scanner handles the record option for channels in the system. All Channel — The scanner sends the audio for all channels in the system to the REC jack, regardless of the channel’s record option setting. Marked Channel — The scanner only sends the audio for channels that have the Record option turned on to the REC jack.
Adjust the P25 Decode Threshold [MENU] Program System Select a conventional system Edit Sys Option F Adjust P25 Level F C F F This setting determines some system-specific parameters for digital channels. In most cases, setting this to Auto provides the best performance. However, you can also manually set the digital decode threshold. This setting affects all channels in the current system. See “Optimizing P25 Performance” on Page 52.
Copying Systems MECSL Occasionally you might want to copy and rename a system to highlight one group over another. One system might be called City - Fire and the same system City - PD with adjustments to data within. This lets you quickly locate the desired set of data.
MS1: Motorola 800 MHz Type I Standard MS2: Motorola 800 MHz Type II Standard MP1: Motorola 800 MHz Type I Splinter MP2: Motorola 800 MHz Type II Splinter P25: APCO 25 (all bands) M92: Motorola 900 MHz MV2: Motorola VHF MU2: Motorola UHF EDW: EDACS Wide EDN: EDACS Narrow Follow these steps to change the system name. [MENU] Program System Select a trunked system F Edit Site F Select a Site F Edit Name F F To enter a letter, turn the Scroll Control until the character you want appears.
Notes: • Access single-digit system/site Quick Keys by pressing the single digit on the keypad during scanning. Access two-digit system Quick Keys by pressing [.No] then both digits. • You can assign as many systems to the same quick key as you want. • To be scanned, a system/site’s Quick Key must be activated and the system must be unlocked.
Note: If you select Control Channel Only mode (see “Setting Control-Channel Only (Motorola Systems Only)” on Page 81), you only need to enter the frequency(s) that can be assigned as the control channel. Most frequency lists usually indicate which of the frequencies are the control channel frequencies. Otherwise, you must enter all of the frequencies.
Edit Site F Select a site F Set Lockout F Select from the following choices then press F Unlocked — the system is scanned when its quick key is enabled. Temporary L/O — the system is locked for this session. Lockout — the system is not scanned. Setting Site Hold Time [MENU] Program System Select a trunked system F Edit Site F Select a site F Set Hold Time F MESL F This setting controls how many seconds the scanner looks at a site before moving to the next unlocked site or system.
Select a site F Edit Band Plan F You can enter up to 3 band plans. Select the plan to enter or edit, then follow the prompts to enter the Base Frequency, Channel Step, and Channel Offset for the site. Setting P25 Band Plans M (P25 Only) The BCD996T includes two operation modes for P25 systems: explicit mode and implicit mode channel assignment. Explicit mode systems include all information needed to determine voice frequencies on the control channel.
Select a non-P25 site Set C-Ch Only F F This setting determines the frequencies you need to enter for Motorola systems. Select your setting, then press F. On — You only need to enter control channel frequencies. Off — You must enter all voice and control channel frequencies. Note: The scanner defaults to On.
manually set the digital decode threshold. This setting affects all channels in the current site. See “Optimizing P25 Performance” on Page 52. Auto — the scanner automatically adjusts the digital decode threshold to match the transmission you are hearing when it receives a strong signal and has a high decode rate. Manual — lets you manually adjust the digital decode threshold. To manually adjust the P25 level, select Manual. Default — sets the digital decode threshold to the default value.
Select a New Group Edit Name F F Follow these steps to enter/edit the group name. 1. The current name displays with the first character of the name highlighted. 2. Rotate the Scroll Control to select a new first letter. Press [6] to move one character to the right. Repeat the Scroll Control action to change the character. To move one character to the left, press [4]. 3. Repeat Step 2 until you have entered the system name. Then press F to accept the setting.
Select an existing group Set Lockout F F This setting determines whether the scanner will scan this group of channels. Select your setting, then press F. Lockout — the group is not scanned. Temporary L/O — the group is not scanned for this session. The L/O is cancelled when you cycle power. Unlocked — the group is scanned. The default setting is Unlocked. Deleting Channel Groups [MENU] Program System Select a system F Edit Group F Select a channel group F Delete Group F Confirm Delete? Yes=”E” / No= ”.
Edit Group F Select the channel group Edit Channel F Select the channel F Edit Name F F Follow these steps to enter/edit the channel name. 1. The current name displays with the first character of the name highlighted. 2. Rotate the Scroll Control to select a new first letter. 3. Press [6] to move one character to the right. 4. Repeat the Scroll Control action to change the character. To move one character to the left, press [4]. Press [.No] twice to delete the current character. Press [.
Editing the Talk Group ID [MENU] Program System Select a trunked system F Edit Group F Select a channel group F Edit Channel F Select the channel F Edit TGID F MEL F To edit the Talk Group ID, enter the Talk Group ID you want using the number keys. Then press F. Setting the Audio Type MECL For each channel, you can select the audio type that the channel receives.
Edit Group F Select the channel group Edit Channel F Select the channel F Set Audio Type F Analog Only F F At this point you can scroll to CTCSS or DCS and select the subaudible frequency in the CTCSS range or the DCS code. CTCSS or DCS F This setting controls how a sub audible CTCSS or DCS is used for the channel. Select your setting, then press F. Off — any signal opens squelch. The default setting is Off.
Select the Channel Set Modulation F F Auto — the scanner uses the default modulation for the channel. The default setting is Auto. AM — the scanner uses AM (amplitude modulation) for the channel. FM — the scanner uses FM (frequency modulation) for the channel. NFM — the scanner uses narrowband FM for the channel. WFM — the scanner uses wideband FM for the channel. WFM (Broadcast) — the scanner uses FM Broadcast for the channel. This setting controls the modulation method used for the channel.
Select the channel Set Priority F F This setting controls whether the scanner treats the channel as a priority channel while scanning. Select On or Off, then press F. On — when you turn on the Priority feature, the channel will be scanned every 2 seconds. Off — the channel will not be treated with priority. The default setting is Off.
On — the scanner outputs the signal. Off — the scanner does not output any audio. Note: In order for the function to work, you must set the channel to record. You must also set the system’s record option to either All Channel (which will record all channels regardless of the channel’s record setting) or Marked Channel (which only records the channels you’ve set to record).
Edit Group F Select a channel group Edit Channel F Select a channel F Delete Channel F F You see Confirm Delete? Yes= ”E” / No= ”.” Select one to delete the channel or to cancel.
Searching and Storing Service Search Service Search lets you select and search the scanner’s preprogrammed search ranges. During service search, the scanner searches starting with the lowest frequency in the search range you select to the highest frequency in the range. There are two ways to do this. [MENU] Search for ... Service Search F Select the service search range F F The other approach is: F + [SCAN/SEARCH] Quick Search? Yes=”E” / No=”.” Press [.
To lock out a frequency found while searching, press [L/O] one time to temporarily lock it out (Temporary L/O appears) or twice to permanently lock it out (Locked Out appears). Notes: • If all frequencies in the search range you selected are locked out, All Locked! appears and the scanner does not search the range. • If the service range you select uses channels (such as CB Radio or Marine), the scanner displays the service channel number.
The scanner starts custom search of the custom search range you selected, stopping on any transmission it finds and displaying the frequency. Turn the Scroll Control to change the search direction. An arrow appears, showing the current search direction. To turn search ranges on or off, press [0] and [1] - [9]. To hold searching, press [HOLD/RESUME]. To resume searching, press [HOLD/RESUME]. To lock out a frequency found while searching, press [L/O].
Set Delay Time — lets you set the amount of time the scanner will delay before continuing to search after a transmission ends. Set Modulation — lets you set the custom search range’s modulation type. Set Attenuator — lets you set whether the scanner will attenuate reception by 20 dB during search. Set Data Skip — lets you set whether the scanner will skip data transmissions during search. Set Step — lets you set the custom search range’s step (the gap between frequencies).
for your metropolitan area that are unlocked and have their System Quick key enabled. In addition to this scan you can search any of the preprogrammed service or custom search ranges. While scanning, press F. Rotate the Scroll Control until you reach the desired service or custom search range. Press [L/O] to unlock it. You can also assign a System Quick Key to the search to make it easy to quickly enable/disable the search range for search and scan.
Set Delay Time Choose a delay time to set how long the scanner stays on a transmission after it ends. to select a value from 1 sec, 2 sec, 3 sec, 4 sec, 5 sec, and Off. F Set Attenuator Choose to attenuate all frequencies by about 20 dB. to select to choose an attenuation for all frequencies in the range. F On — the frequencies are attenuated. Off — the frequencies are not attenuated. Set Record to enable real time audio output from REC to an audio recording device. On — the scanner outputs the signal.
Saving a Found Channel (Quick Save) If you hold on a channel or receive a desired channel, you can save it by pressing [EYES] instead of using Direct Entry. The alpha data is also stored. If a GPS unit is attached, the longitude and latitude data is saved and becomes the name of that channel. For example, if the position is 32°57’33.60 N latitude and 97°05’34.18 W longitude, the name saved is 3257.33-09705.34.
line changes to Memory Check when the scanner detects a transmission while it is checking to see if the frequency has already been stored. When the scanner finds an active transmission, it checks to see if the frequency has already been stored in the system. If it has already been stored, the scanner continues to search. If the frequency has not been stored, it stores the frequency into a group named Found Channels, then resumes searching. The scanner creates this group if it doesn’t already exist.
Using the Close Call Feature Your scanner’s Close Call™ feature lets you set the scanner so it detects, displays the frequency of, and lets you hear a nearby strong radio transmission. You can set the scanner so the Close Call feature works “in the background” while you are scanning other frequencies, turn off normal scanning while the Close Call feature is working, or turn off the Close Call feature and use the scanner normally.
Call mode and stores any Close Call hits, up to the maximum you specified in the Max Auto Store setting. If the scanner stores more hits than this setting, it stops auto store operation. Turn the Scroll Control to display an option, then press F. Set CC Mode — Lets you select the Close Call mode. If you set CC Pri, then every 2 seconds the scanner switches the filter settings to the ones set by the CC Bands option. This does not occur with CC DND. Off — Close Call is turned off for all modes.
Set CC Bands — Lets you select the Close Call band settings. You can turn the following bands on or off. VHF Low 1 — (25.0000 - 53.9800 MHz) VHF Low 2 — (54.0000 - 107.9000 MHz) Air Band — (108.0000 - 136.9750 MHz) VHF High 1 — (137.0000 - 224.9800 MHz) VHF High 2 — (225.0000 - 319.9750 MHz) UHF — (320.0000 - 512.0000 MHz) 800MHz+ — (764.0000 - 775.9875 MHz, 794.0000 - 823.9875 MHz, 849.0125 868.9875 MHz, 894.0125 - 956.0000 MHz,1240.000 - 1300.
resuming scan. This lets you continue to hear transmissions detected with the Close Call feature, even after you are no longer close enough to receive it as a Close Call hit. Follow these steps to set up the option. [MENU] Close Call F Hits with Scan F Set Quick Key or Set Lockout or Set Hold Time F Set the available option as you would for other menu items. This special channel group is automatically cleared whenever you cycle the scanner’s power.
Search and Close Call Options The settings in this section affect custom searches, service searches, and Close Call operation. The following table shows what options are available for various search modes. Setting Service Custom Search1 Search1 Quick Search Freq.
Unlocking All Frequencies [MENU] Srch/CloCall Opt Freq Lockouts F Unlock All F F The scanner prompts you to confirm the change in lockout status. To confirm the change of all locked-out frequencies, press F. If no frequencies are locked, you see Nothing Locked Press Any Key. Otherwise, to cancel, press [MENU]. Reviewing Locked-Out Frequencies [MENU] Srch/CloCall Opt Freq Lockouts F Rvw Search L/O F F The scanner displays the first locked-out frequency and prompts you to unlock the frequency.
This setting determines whether the scanner automatically ignores transmissions found during Custom Search, Quick Search, or Close Call operation that are on common broadcasts, paging systems, and other annoyance radio sources. Note: Broadcast screening does not work in All service search ranges. Set All Band On — turns on broadcast screen on each band. Set All Band Off — turns off broadcast screen on each band. Set Each Band — lets you set broadcast screen only on specific bands you select.
Repeater Find On or Off F F This feature sets whether the scanner tries to tune to a repeater output frequency during Custom Search, Quick Search, or Close Call operation when it detects a transmission on a repeater input frequency.
AM — the scanner uses AM (amplitude modulation) for the frequency band. FM — the scanner uses FM (frequency modulation) for the frequency band. NFM — the scanner uses narrowband FM for the frequency band. WFM — the scanner uses wideband FM for the frequency band. WFM (Broadcast) — the scanner uses FM Broadcast for the frequency band. Setting Attenuation Turn on this setting if you are near other strong signal sources.
Setting the Delay Time [MENU] Srch/CloCall Opt Set Delay Time F F This setting determines how long the scanner waits after a transmission ends before resuming Quick Search or Close Call operation. 1-5 sec — The scanner waits the set amount of time after the transmission ends before resuming. The default setting is 2 sec. Off — The scanner resumes immediately when the transmission ends.
Adjust P25 Level You can select the best threshold for the APCO mode. [MENU] Srch/CloCall Opt Adjust P25 Level F F Auto — The automatic adjust feature is enabled. Manual — you can set the threshold manuals depending on your circumstances. Default — sets the factory default value. Note: Applies to P25 signals received during Search and Close Call. Priority Scan If you activate a Priority Scan while scanning, the radio interrupts its scan every two seconds to check the priority channel (P-Ch).
Using Weather Alert (SAME) Your BCD996T has been primarily designed as a multi-band, general services scanner. While it incorporates a weather alert ability as one of its features, we recommend that you not use the scanner as your sole means for receiving emergency alerts. Your local electronics retailer can supply a selection of weather radios that are dedicated to weather service monitoring including SAME alerts. Such radios can be more dependable for this application.
Turning Weather Alert On/Off In weather alert mode, your scanner functions as a severe weather warning radio. This is especially useful when your area is expecting severe weather conditions late at night. When you set the scanner to weather alert mode, it holds on the weather channel, but does not play the channel’s audio. If it detects a weather alert, it sounds a tone, displays information about the weather alert, and turns on the audio so you can hear the weather broadcast.
n: A special sub-county designator. For an entire county, use 0. SS: The state code. CCC: The county code. For example, Tarrant County in Texas is assigned to FIPS code 048439. 0 indicates the entire county 48 indicates the state of Texas 439 indicates Tarrant County To get the FIPS code for your county, visit the National Weather Service web site at http://www.nws.noaa.gov and search for “FIPS Listing”.
Fire Tone-Out Your scanner can be set to respond to fire tone-outs, a system comprised of standardized two-tone sequential paging, short one-tone paging, and long group tone paging. You can save up to 10 settings. When you select a setting in standby mode, the scanner also monitors for any other setting that uses the same transmit frequency, modulation, and attenuation settings. To quickly switch to Fire Tone-Out mode, press F and then [SQ].
• Edit Frequency — Enter the desired frequency that the scanner should monitor for the tone-out. • Set Modulation — Set the modulation type for the paging signal. Next choose the modulation setting: • Auto — The scanner uses the default modulation for the frequency band. If the default modulation is AM, WFM, or FMB, the modulation operates as FM. • FM — The scanner uses FM for the frequency band. This is the default setting. • NFM — The scanner uses NFM modulation.
After you select an alert pattern, the scanner prompts for the alert level for a received alert. Level options 1 to 15 sets a fixed audio level independent of the main volume setting. AUTO uses the main volume setting for the alerts. Tone-Out Multi-Channel Monitoring The scanner can check multiple tone combination pages for channels whose settings are the same. To achieve this, set the channel to the same frequency, modulation, and attenuation.
Using the BCD996T with a GPS The scanner lets you connect a compatible GPS device to it to provide two very convenient operation features: • automatically locks and unlocks systems and sites based on data you input. This fine-tunes the scanning operation and makes it that much enjoyable. • provides you with valuable displayed information and audio alerts for Points of Interest, Dangerous Roads, and Dangerous Crossings. The GPS works in close coordination with your scanner.
Location-Based (GPS) Scanning The BCD996T uses data, supplied by an attached GPS unit, that lets the radio automatically unlock and lockout sites based on the geographical information you provide. • Latitude (the center of the range or site) • Longitude (the center of the range or site) • Range (the radius of a circle around the latitude and longitude coordinates selected from up to 50 miles from that center).
Another Example of Multiple Site Creation The geographic area of Arlington, TX, is separated into multiple site locations to enable automatic lockout and unlock as one moves from area to area. Non-Radio Location Based GPS Features When connected to a GPS, you can program specific location information which will trigger an alert from the scanner. The scanner becomes an extension of the GPS device. The following geographical values are typical of use you might find valuable while traveling.
To store your current location, press and hold [GPS] for about 2 seconds. You are prompted to enter the type of entry (Dangerous Xing, Dangerous Road, or POI), as well as the other location parameters. When you set the beep type, you are next prompted to set the alert volume. While you are in normal GPS mode or Scan Mode and you press and hold [GPS] for about 2 seconds, location data at that point is stored. The scanner opens a dialog to store your current location.
Menu Option Delete Location POI Dangerous Xing Dangerous Road • • • Setting the Options [MENU] Program Location F Select a location type (POI, Dangerous Xing, or Dangerous Road). New Location F F The scanner assigns a sequentially created number to the location. Edit Name F Use the Scroll Control and F to give the New Location a name. You could, for example, enter the name of the place or the Route Number.
Once you make a Tone selection you are immediately asked to assign a volume level to that selection. Set Alert Volume F Select from 15 sound levels, plus Auto. As you rotate the Scroll Control the Alert tone you set is played louder and louder. Press F to select a volume level. You can also select Auto, a level that is the same setting as your master volume control. Set Range F Input how far away the alert sounds for the site (only available for POI’s and between 0.1 and 2.
For example: If the Dangerous Road location is toward the Northeast and you are driving in that direction, then choose NE (45°) If you know you will be driving on a road which has many curves to that site center, choose All Range which will trigger the alert regardless of direction as long as the other requirements (range, speed) are met. If you travel in a Northeast direction and do not travel either side of a northeast line by up to 22 degrees, the alert system will function.
Elevation Display Speed Display Location Display GPS Review Location Mode If you have programmed data for a Point of Interest, Dangerous Crossing, and a Dangerous Road, you can review each set on a screen dedicated to showing just that data. Press [EYES] in GPS Mode. The most recent stored location is displayed. Use the Scroll Control to display the next screen for review. The following keys also have a different function while in GPS Review Mode. [MENU] — returns to GPS Mode.
1. 2. 3. 4. 5. POI — Indicates a Point of Interest location. DXG — Indicates a Dangerous Crossing location. DRD — Indicates a Dangerous Road location. Range — Indicates the programmed distance to your POI. Head — Indicates the selected heading to the designated Dangerous Crossing from any direction. 6. Head — Indicates the selected heading to the designated Dangerous Road from a specific direction. 7. LS — Indicates the maximum Speed Limit you set.
Care and Maintenance General Use Turn the scanner off before disconnecting the power. If memory is lost, simply reprogram each channel. Always press each button firmly until you hear the entry tone for that key entry. Location Do not use the scanner in high-moisture environments such as the kitchen or bathroom. Avoid placing the unit in direct sunlight or near heating elements or vents.
Troubleshooting From time to time, Uniden might update the BCD996T’s firmware to change the scanner’s performance or incorporate new features. These updates can be applied by you using the supplied PC cable and the software that we will provide. Please note that firmware data must be input by means of the front panel serial cable connection, not the rear connector. We recommend you visit the Uniden web site periodically to check for the latest updates.
Problem Scan won’t start. Weather scan doesn’t work. Possible Cause Suggestion You must press [SCAN/SEARCH] to scan. Press [SCAN/SEARCH]. The squelch might need to be adjusted. Adjust the squelch threshold. See “Turning On the Scanner and Setting the Squelch” on Page 45. One or more channels might be locked out. Make sure the channels you want to scan are not locked out. The antenna might need to be adjusted. Check the antenna connection. The squelch might need to be adjusted.
Problem Possible Cause Suggestion Scanner won’t acquire the data channel. The squelch might need to be adjusted. Adjust the squelch threshold. See “Turning On the Scanner and Setting the Squelch” on Page 45. The frequency used for the data channel might be missing. Check your frequency list for the data channel. The scanner might need to be changed to a Type 1 scanner setup. Change to a Type 1 scanner setup. See the programming instructions on the web at www.uniden.com/scanners.
Specifications Certificated accordance with FCC Rules and Regulations Part 15 Subpart C as of date of manufacture. Dynamic Allocation Capacity Systems : 500 max Groups : 20 per system Site : 1000 max (All) 256 per system Channels : up to 6000 (3000 typical) Channels per Trunked System : up to 250 Band Coverage : 31 Bands Frequency Range : Range (MHz) 25.0000 to 26.9600 26.9650 to 27.4050 27.4100 to 27.9950 28.0000 to 29.6800 29.7000 to 49.9900 50.0000 to 53.9800 54.0000 to 71.9500 72.0000 to 75.
Range (MHz) Step (kHz) 764.0000 to 775.9875 12.5 794.0000 to 805.9875 12.5 806.0000 to 823.9875 12.5 849.0125 to 868.9875 12.5 894.0125 to 956.0000 12.5 1240.0000 to 1300.0000 25 Mode NFM NFM NFM NFM NFM NFM Public Service Band Public Service Band Public Service Band Public Service Band Public Service Band 25 cm Amateur Band Sensitivity (nominal) 12dB SINAD : 0.4µV 0.3µV 0.7µV 0.3µV 0.6µV 0.4µV 0.3µV 0.6µV 0.3µV 0.4µV 0.4µV 0.3µV 0.7µV 25 - 27.995 MHz 28 - 53.98 MHz 54 - 71.95 MHz 72 - 75.
Remote Interface Jack 4pin Mini Type GPS / Remote Interface Jack D-sub 9pin Male Type Ext. DC Power / ORNG Wire Jack 3pin (Center Orange Wire) Operating Temperature : Size : Nominal -20°C to +60°C -4°F to +140°F Close Call -10°C to +60°C +14°F to +140°F 7.2 in. (W) x 6 in. (D) x 2.2 in. (H) 184mm (W) x 154mm (D) x 56mm H) Weight : 3.5 lbs [1.6 kg.] (without Mounting Bracket) Features, specifications, and availability of optional accessories are all subject to change without notice.
Reference Preset Fleet Maps Note: Size Codes in parenthesis indicates that the Size Code spans more than one block.
Preset Map 7 Block 0 1 2 3 4 5 6 7 Size Code Size Code 10 Size Code 10 Size Code 11 Size Code 4 Size Code 4 Size Code 4 Size Code 4 Size Code 4 Preset Map 9 Block 0 1 2 3 4 5 6 7 Size Code Size Code 4 Size Code 4 Size Code 0 Size Code 0 Size Code 0 Size Code 0 Size Code 0 Size Code 0 Preset Map 11 Block 0 1 2 3 4 5 6 7 Size Code Size Code 4 Size Code 0 Size Code 0 Size Code 0 Size Code 0 Size Code 0 Size Code 0 Size Code 0 Preset Map 13 Block 0 1 2 3 4 5 6 7 Size Code Size Code 3 Size Code 3 Size Cod
Preset Map 15 Block 0 1 2 3 4 5 6 7 Size Code Size Code 4 Size Code 4 Size Code 4 Size Code 11 Size Code 11 Size Code 0 Size Code 12 (Size Code 12) Preset Map 16 Block 0 1 2 3 4 5 6 7 Size Code Size Code 3 Size Code 10 Size Code 10 Size Code 11 Size Code 0 Size Code 0 Size Code 12 (Size Code 12) User Defined Fleet Maps Type I Programming Information When a Type I system is designed, the address information for all the ID’s is divided into 8 equal sized blocks, numbered 0–7.
seems. Select a size code for a block, and then press Scan. Now listen to the communications. If you decide you are receiving most of the replies to the conversations with ID’s assigned to the block you just programmed, then you’ve probably selected the right size code and can work on the next block of the map. Finally, for most public safety systems there are some size codes which are more common. S-3 and S-4 are probably the most common, followed by S-10, S-11, and S-12.
Preprogrammed Systems and Lockout Options Your scanner is preprogrammed with over 500 channels covering police, fire, and ambulance operations in the 25 most populated counties in the US. The following list details the preprogrammed information. By default, only the Nationwide systems are unlocked, and your scanner begins to scan them when you turn it on. To speed up scanning, you can lock out systems that are beyond your reception area (typically no more than 25 miles using the supplied antenna).
Preprogrammed Systems with Quick Keys State, or City Area Alameda, CA Area Alaska Albuquerque, NM Area Atlanta, GA Area Austin, TX Area Boston, MA Area Charlotte, NC Area Chicago, IL Area Cincinnati, OH Area Cleveland, OH Area Colorado Connecticut Dallas-Fort Worth, TX Area Detroit, MI Area Harrison County, WV Houston County, GA Houston, TX Area Indiana Las Vegas, NV Area Los Angeles, CA Area Massachusetts Miami-Dade, FL Area Michigan Minnesota Montana Nationwide New York City, NY Area Newark, NJ Area Oakla
State, or City Area Quick Key San Antonio, TX Area San Diego, CA Area Santa Fe, NM Area Seattle, WA Area South Texas St. Clair County, IL Tucson, AZ Area Virginia 54 26 44 57 55 33 23 56 CTCSS Frequencies 67.0 82.5 100.0 123.0 151.4 171.3 189.9 210.7 69.3 85.4 103.5 127.3 156.7 173.8 192.8 218.1 71.9 88.5 107.2 131.8 159.8 177.3 196.6 225.7 250.3 74.4 91.5 110.9 136.5 162.2 179.9 199.5 229.1 254.1 77.0 94.8 114.8 141.3 165.5 183.5 203.5 233.6 79.7 97.4 118.8 146.2 167.9 186.2 206.5 241.
506 612 703 516 624 712 523 627 723 526 631 731 532 632 732 546 654 734 565 662 743 606 664 754 Preprogrammed Systems with Quick Keys 141
Index A Alert Channel 13 Custom 13 Dangerous Xing-Road 123 Duplicate Frequency 14 Emergency 73 GPS 15 POI 122-124 Setting Channel 90 Weather 15, 113 Antenna 19, 31, 33, 37 APCO 14, 15, 24, 26, 40, 52, 87, 111 Attentuator, Attenuation 13, 44, 79, 89, 98,109 Auto Store 16, 99, 101, 102, 108 B Backlight 14,35, 55, 56 Band Plan 80-81 Beep 18, 26 Alert 73, 123 Close Call 102 Key 56 Birdies 14, 127 Broadcast 13 Broadcast Screen 106 C Channel Add CTCSS/DCS 87 Alert 13 All 33 Attenuation 89 Control 15, 25, 26 Contr
Delay 70 Delete 85 Deleting 91 Display Mode 51 Editing 75 Found, Saving 99 Group 16, 21 Group Name 44 Holding 49 Lock/Unlock 48, 83-84 Lockout 13 Logical Number 26 Marked 33 Memory 12 Modulation 88 Priority 89 Programming 83 Single Autonomous 27 Step 14 System 47 Tone-Out 118 Close Call DND 102 Feature 12 Hits with Scan 103 Options 105 Setting 101 Using 101 Contrast 57 Conventional Auto Store 16 Feature 14 Programming 66 Scanning 23 Search and Store 99 Startup Options 45 System 52 Copy Channels 91 Systems 7
Service Search 97 Sites 75 System Quick Key 68 Talk Group ID 85 End Code 72 F Fleet 26, 27, 71, 135, 137 G GPS Compatible 118 Connecting 118 Distance Units 58 Features 15 Initial Operation 118 Location Based Scanning 119 Location Information 71 Non-Location Based 120 Position Format 57 Saving Longitude/Latitude 99 Setting Format 57 Time Format 57 Time Zone 58 Using the Scanner 119 I I-Call Feature 29 Operations 72 ID Scan 48, 49, 70 Indicators 44, 47, 50 ISO 31, 36, 37 L Lockout Automatic 120 Channel Groups
Preprogrammed 12, 15, 19, 47, 62, 93, 113, 139, 140 Preset Edit Maps 71 Fleet Maps 134-135 Search Ranges 94 R Range All 124 Display 126 Edit 95 GPS 15 Search 22, 45, 94, 98 Set 71 S Scan Close Call Hits 103 Control Channel Only 15 Conventional 23 Function 17 ID 48 Legally 9 Priority 16, 111 Search Delay 13 Search With 13, 96 Selecting Systems 47 Systems 46 Trunked 25 Understanding 21 What is 22 SCAT 14, 26, 27, 76, 80, 84, 100 Search Assigning a Range to a Search Key 98 Auto and Store 99 Close Call Options
