UH305SX-2NB uhf cb Transceiver For more exciting new products please visit our website: Australia: www.uniden.com.au New Zealand: www.uniden.co.
Controls & Indicators Included in your Package • UH305SX-NB Radio* • Operating Guide • Belt Clips* dup ch/ scan *UH305SX-2NB (x2), UH305SX-4NB (x4) Other printed materials may be included.
Getting Started NOTE BATTERY WARNING The UH305SX-2NB will consume a small amount of battery power when switched off. To prevent the batteries from running down, remove them from the radio if the UH305SX-2NB will not be used for long periods Battery Installation Your UH305SX-2NB radio uses 3 AAA ALKALINE batteries for power. Use only good quality alkaline batteries for maximum life and range. Note: Batteries are not supplied. D OL W NE To avoid damage to the unit do not mix old and new batteries.
Getting Started WATER WARNING Uniden does not represent this product to be waterproof. Do not expose this product to Rain or Moisture. Belt Clip To attach the belt clip: Slide the belt clip until it snaps into place. Pinch Belt Clip and Latch To remove the belt clip: To remove the belt clip. Pinch and hold belt clip and latch (see arrows indicated) and slide the belt clip in the direction shown.
Operation Power On/Off Press and hold to turn the Radio ON. The channel number will appear on the display. Press and hold to turn the Radio OFF. Volume Press volume or to increase or decrease the volume level. The Channel indicator will flash when the volume is being adjusted. dup ch/ scan vol/ mon mic ch/ scan dup vol/ mon mic Adjusting the Key Beeps Your radio emits a beep each time one of the keys (except for the PTT button) are pressed. To turn OFF the beep: Press and hold the Radio.
ch/ scan Operation dup vol/ mon mic To Transmit and Receive The UH305SX-2NB uses the UHF-CB Channels. Refer to page 9 for UHF channel usage. (Channels 22 and 23 are for telemetry and telecommand applications. Transmit is inhibited on these channels). PTT Switch dup 1. The transmit power of the UH305SX-2NB is 500mW which will PTT provide a range of up to 3+Km. PTT Switch dup ch/ scan vol/ mon mic switch 2. Before you transmit, listen for activity on the selected channel. 3.
Operation Range Maximum Range Reduced Range Automatic Squelch Feature The UH305SX-2NB is equipped with an Automatic Squelch system which shuts of weak transmissions and unwanted noise. Monitor This feature enables users to listen in for weak signals on the current channel at the press of a button. To use monitor or for 2 seconds. When Monitor is on you • Press and hold Volume will hear noise if there is no signal.
Operation To Operate in Duplex Mode (Repeaters) The Duplex function enables you to access local repeater stations. You can only activate Duplex from CH01-CH08 and CH41-CH48. UHF CB Repeaters are used to retransmit or relay your signal. Repeaters will extend the range of your radio and overcome the shielding effect caused by solid obstructions. Contact your retailer for a list of repeaters available in your area. NOTE Operation With the Aid of a Repeater Eg.
Operation Key Lock Press and hold / to lock or unlock the keypad. and keys remain functional when key lock is on. When key lock setting is turned on, appears momentarily and will appear when an inactive key is pressed. Scanning The scan function scans all channels and stops at an active channel. When the signal stops, the UH305SX-2NB waits 2 seconds (Drop-Out Delay) before scanning resumes. To initiate scanning 1. Assuming the unit is on CH1 when switched on. 2.
UHF Channels and Frequencies NOTE Always listen on a channel (or observe the receive signal level meter) to ensure it is not already being used before transmitting. Channels 5 and 35 are used for emergency channels. CTCSS will not operate on these channels. Please follow these guidelines for channel use in Australia: • Channels 05 and 35 are Emergency Channels. • Channel 11 is a Calling Channel. • Channels 22 and 23 are for telemetry and telecommand applications and TX is inhibited on these channels.
Warranty UNIDEN UH305SX-2NB UHF CB Transceiver IMPORTANT: Satisfactory evidence of the original purchase is required for warranty service Please refer to our Uniden website for any details or warranty durations offered in addition to those contained below. Warrantor: The warrantor is either Uniden Australia Pty Limited ABN 58 001 865 498 (“Uniden Aust”) or Uniden New Zealand Limited (“Uniden NZ”) as the case may be.
Warranty User-generated Data: This warranty does not cover any claimed loss of or damage to user-generated data (including but without limitation phone numbers, addresses and images) that may be stored on your Product. Statement of Remedy: If the Product is found not to conform to this warranty as stated above, the Warrantor, at its discretion, will either repair the defect or replace the Product without any charge for parts or service.
