Assembly Instructions Caution: You must read this before you proceed Round Dining Table Part List Label Picture Description QTY A Table Top 1 B Upper Leg Frame (with Pre-installed Levelers) 1 C Lower Leg Frame (with Pre-installed Levelers) 1 Page 1 OF 7
Hardware Label Picture Description QTY ① Bolt (M6*32mm) 13 ② Bolt (M6*38mm) 2 ③ Spring Washer 15 ④ Washer 15 ⑤ Allen Key 1 Assembly Preparation Before Beginning Assembly: Page 2 OF 7
Assembly Steps Table Top (A) Upper Leg Frame (B) Lower Leg Frame (C) FRONT FACING This Round Dining Table has multiple parts and may require up to 30 minutes to assemble. To give you an overview of the Round Dining Table, the above picture is to help you put the various parts into perspective. Please read through the instructions below to familiarise yourself with the parts and steps before assembly.
Step 1 A B C Place the Table Top(A), Upper Leg Frame(B) and Lower Leg Frame(C) onto a clean, non-marring surface. Step 2 Attach Upper Leg Frame(B)and Lower Leg Frame(C)to the bottom of Table Top(A)using Bolt(②) ,Spring Washer(③), Washer(④) with Allen Key(⑤)as shown above. Do not fully tighten the Bolts.
Step 3 3.1) Attach Upper Leg Frame(B)and Lower Leg Frame(C)to the bottom of Table Top(A)using Bolt(①),Spring Washer(③),Washer(④) with Allen Key(⑤) as shown above. Do not fully tighten the Bolts. 3.2) Attach Upper Leg Frame(B)and Lower Leg Frame(C)to the bottom of Table Top(A)using Bolt(①),Spring Washer(③),Washer(④) with Allen Key(⑤)as shown above. Tighten all Bolts fully in a sequential manner.
Step 5 Inspect and make sure all parts are connected and fully secured into position. Your Round Dining Table is ready for use. This Round Dining Table can only be used on a flat, level surface.
Page 7 OF 7
