User's Manual

2
Copyright 2012 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.
Features
Powerful system
 Microsoft Windows Embedded
Handheld 6.5 operating system
 TI OMAP3 AM3715 processor
with speed of up to 806 MHz
System memory
 512MB Mobile DDR
 512MB NaNDFlash
Display
 3.8” TFT LCD touch screen
 480 (W) x 800 (H) resolution
(WVGA)
 Supports display rotation
Communication
 USB 1.1 Host & Client
 Bluetooth 2.1 EDR (supports
Bluetooth Printer, Bluetooth
Modem, Bluetooth ActiveSync,
and Bluetooth Headset)
Camera
 Built-in 5M/AF camera with
2 flash LEDs
Audio
 MIC
 Speaker
 Receiver (Headphone)
Expansion slot
 MicroSD memory card slot,
supporting up to 32GB
Wireless connectivity
 WLAN, 802.11a/b/g/n
 WWAN, GSM/GPRS/EDGE :
UMTS/HSDPA/HSUPA (DL
14.4Mbps, UL 5.7Mbps)
 WPAN, Class II, Bluetooth
2.1+EDR
 GPS/AGPS
 RFID/HF (Optional)
 G-Sensor
User-friendly interface
 Special keys to launch particular
applications and display the
on-screen keyboard
 Keys for barcode scanning
Barcode scanner engine
 1D Engine (Optional)
 2D Engine (Optional)
RFID Reader (Optional)
 Frequency: 13.56MHz
 Tag Support: ISO15693,
ISO14443A, ISO14443, and
NFC
