UAD System Manual - 107 - Chapter 11: UAD-2 Satellite
Additionally, UAD-2 Satellite can function as a FireWire hub, by using the un-
used ports on the unit to connect other FireWire devices as in Figure 31. Note
that UAD-2 Satellite does not supply FireWire bus power to downstream de-
vices; see “FireWire Bus Power” on page 112 for details.
Figure 28. FireWire bus connections via a hub
Figure 29. FireWire bus connection via daisy chain
Figure 30. FireWire bus connections via hub and daisy chain
Figure 31. FireWire bus connections using UAD-2 Satellite as a hub
Computer
FW Audio Interface
External HD
UAD-2 Satellite
FW Hub
Computer
FW Audio Interface
External HD
UAD-2 Satellite
Computer
FW Audio Interface
External HD
UAD-2 Satellite
FW Hub
External HD
External HD
Computer
FW Audio Interface
External HD
UAD-2 Satellite
External HD
