UAD System Manual - 79 - Chapter 7: Using UAD Powered Plug-Ins
DSP Loading Information
The UAD devices feature either one (UAD-2 Solo), two (UAD-2 Duo), or four
(UAD-2 Quad) on-board DSP chips for processing Powered Plug-Ins.
Multi-DSP UAD-2 systems use significantly enhanced load balancing routines.
UAD-2 plug-ins are always allocated as efficiently as possible, which is not
necessarily on the DSP with the lowest resource usage.
UAD FireWire
Devices
Because Firewire has significantly less bandwidth than the PCIe protocol, if
UAD-2 Satellite and/or Apollo is running with UAD-2 PCIe card(s) in a multi-
device system, UAD plug-ins will load on the UAD-2 card(s) before the
Firewire device in order to maximize Firewire bandwidth. See “FireWire
Bandwidth vs. UAD DSP” on page 111 for more information.
Table 3. Keyboard shortcuts
Keyboard Action: Result:
Control + Click Parameter (Mac only) Select parameter for keyboard control
(without changing its value)
Shift + Drag Fine Control
UpArrow
RightArrow
Shift + PageUp
Increment Fine
DownArrow
LeftArrow
Shift + PageDown
Decrement Fine
Shift + UpArrow
Shift + RightArrow
PageUp
Increment Coarse
Shift + DownArrow
Shift + LeftArrow
PageDown
Decrement Coarse
Control + Click parameter (Windows)
Modifier* + Click parameter (Mac)
(*Modifier key set in Configuration Window)
Toggle initial editor setting (the value when the
editor window was last opened)
Control + Shift + Click parameter (Windows)
Modifier* + Shift + Click parameter (Mac)
(*Modifier key set in Configuration Window)
Revert to initial editor setting (the value when the
editor window was last opened)
