UAD System Manual - 88 - Chapter 9: UAD Delay Compensation

Upsampling Values Table

Table 7 lists the additional latency produced by upsampled UAD plug-ins.

*EMT 250 Note The EMT 250's anti-aliasing filters for its A/D and D/A conversion are not lin-

ear-phase filters; therefore our emulation does not have a latency that is the

same at all frequencies. Thus, we cannot report to the delay compensation en-

gines a delay that is correct for all frequencies. The value we report is good

at low frequencies, but becomes off at high frequencies.

For example, when the plug-in is in Delay program mode and set with zero

delay time and predelay values, the plug-in output will not be completely can-

celled when mixing with flipped phase against an unprocessed track; high

frequencies will leak through. However, the latency through the dry side of the

wet/dry mix, and the latency when the plugin is bypassed via the EMT 250

Power switch, do not have this issue and will be fully compensated by the

DAW.

Table 7. Upsampled UAD plug-ins with additional latencies

Sample Rate (kHz)

Upsampled Plug-In 44.1 48 88.2 96 176.4 192

Precision Limiter 64 69 129 140 259 281

Neve 33609

FATSO Jr./Sr.

Massive Passive

Moog Filter

Studer A800

UA 1176 Limiter Collection

55 55 55 55 88 88

Precision Maximizer 67 67 67 67 42 42

Helios Type 69

Harrison 32C

Neve 1073, 1081, 31102

Precision EQ

Pultiec EQ/Pultec-Pro

SSL E Channel Strip

Trident A-Range

31 31 13 13 0 0

Precision Multiband 15,360 16,896 30,720 33,792 61,440 66,048

Little Labs IBP 32 32 14 14 1 1

Lexicon 224 84 79 90 97 107 116

EMT 250* (see note) 75 11 85 24 107 50

Ampex ATR-102 2262 2455 4408 4798 8818 9598

MXR Flanger/Doubler 31 31 0 0 0 0
