Universal DVR/PVR 5-Device Remote User's Guide

www.urcsupport.com
21
Clearing the Master Power Key
RE-ASSIGNING DEVICE KEYS
The Atlas DVR/PVR 5-Device Universal Remote Control
with Learning can be set up to control a second device of
an already-assigned type. For example, to have the unit
control a TV, a Cable Converter, and two DVD players,
re-assign the unused AUX key to operate the second DVD
Player as follows:
NOTE: AUX is preset at the factory to control an RCA
VCR. Performing the steps below will over-
write those settings.
The AUX key is now ready to be programmed for your
second DVD player. See “Programming Device Control”
on page 8. To re-assign other device keys, repeat these
and substitute the key sequence using the following
chart:
1. On the remote control, press and hold SETUP
until the last-selected device key blinks twice.
2. Enter 9 9 5. The last-selected device key
blinks twice.
3. Press and release PWR.
4. Press and hold SETUP until the CBL key blinks
twice.
1. On the remote control, press AUX once; it will
blink once. Then press and hold SETUP until
the AUX key blinks twice.
2. Enter 9 9 2. The AUX key will blink twice.
3. Press DVD once, then press AUX once. The AUX
key will blink twice.
