Owner’s Manual TRG-100 Umotion Remote
TRG-100 UMOTION REMOTE This remote control was Custom Programmed for you by: For questions about your Custom Programming call: Custom Programming of a complex home theater and/or a multi-room system is one of the most challenging tasks within an audio/video installation. It involves an intimate knowledge of how the components interact and exact details on the proper sequences of control.
TRG-100 UMOTION REMOTE Congratulations! 1 Parts Guide 1 Using the TRG-100 Umotion Remote 2 Installing the Batteries 4 Pairing to a TRF-GE1 and/or MRX-20 5 Maintaining Your TRG-100 Umotion Remote 6 Specifications 6 Limited Warranty Statement 7 End User Agreement 9 Federal Communication Commission Interference Statement 10 Declaration of Conformity 11
TRG-100 UMOTION REMOTE Congratulations! Thank you for purchasing the Total Control TRG-100 Umotion Remote. The TRG-100 works to control the MRX-20 Advanced System Controller’s user interface. View and control your connected devices throughout your home with the user interface via a connected HDTV. Control the on-screen interface with the remote’s built in gyroscopic motion The TRG-100’s built-in gyroscopic motion allows for on-screen control and selection of all your connected devices.
TRG-100 UMOTION REMOTE Using the TRG-100 Umotion Remote The TRG-100 remote consists of basic buttons found on many other remotes with the exception of the special Umotion button. Use these functions to control your rooms and connected devices. All buttons may vary based on your Custom Professional’s programming. Main Turns ON the connected A/V devices while displaying the MRX-20’s System menu. For further details, refer to the MRX-20 Owner’s Manual. Power Turns the A/V connected devices in the room OFF.
TRG-100 UMOTION REMOTE Using the TRG-100 Umotion Remote (cont...) In addition to the basic options, it is important to know the additional features the buttons listed below provide, when controlling an MRX-20 Advanced System Controller. Power: Turns the connected devices in the room OFF. l When a room is ON: Pressing Power sends out a series of commands to turn off all connected A/V devices in that room,such as a display device or an optional SNP-1 music player.
TRG-100 UMOTION REMOTE Main: Displays the MRX-20’s System menu via a connected display device. l When a room is OFF: Pressing Main sends out a series of commands to turn ON all required devices to view the on-screen display. l When a room is ON: Pressing Main, while the display device is on, opens the System Main menu of the MRX-20. Umotion: Allows for motion control and button selection via on-screen interface. Press the Umotion button to activate on-screen movement.
TRG-100 UMOTION REMOTE Pairing to a TRF-GE1 and/or MRX-20 Before you can begin to use the TRG-100 Umotion remote, it is necessary to pair it with either a TRF-GE1 Extender or the MRX-20 Advanced System Controller. To pair, press and hold the Main and Sel buttons for three seconds. Once paired, the Umotion button will flash three times. Keep in mind, a TRG-100 remote can only be paired with one MRX-20/TRF-GE1 at a time.
TRG-100 UMOTION REMOTE Maintaining Your TRG-100 Umotion Remote The TRG-100 Umotion Remote is not waterproof. Do not use it in any location that is damp or wet. If you spill water on it, remove the batteries and let the TRG-100 Umotion Remote dry for 48 hours before you try powering it up again. If you spill coffee or another beverage on it, clean it with distilled water. Make sure no water gets inside the TRG-100 Umotion Remote. Keep it away from extreme cold or heat.
TRG-100 UMOTION REMOTE Limited Warranty Statement 1. Limited Warranty and Disclaimers Universal Remote Control, Inc. (“URC”) warrants that the URC equipment shall be free from defects in material and workmanship under normal usage for two (2) years from purchase when such is purchased from URC. This limited warranty is valid only in the United States of America. URC warrants that the software will substantially conform in any material respect to its functional specifications at the time of delivery.
TRG-100 UMOTION REMOTE SKILL AND CARE, OR OUTCOME OR RESULTS. WITHOUT IN ANY WAY LIMITING THE GENERALITY OF THE OTHER PROVISIONS HEREIN, WARRANTY DOES NOT COVER: (I) DAMAGE FROM MISUSE, NEGLECT OR ACTS OR NATURE, (II) MODIFICATIONS, (III) INTEGRATION WITH THIRD PARTY CONTENT (IV) BEYOND THE WARRANTY PERIOD AND/ OR FAILURE TO FOLLOW URC WARRANTY CLAIM PROCEDURE.
TRG-100 UMOTION REMOTE equipment are authorized for online internet sales. Buying URC’s PC programmable remotes or any of our Total Control® whole-house equipment online means buying equipment that does not have a URC’s limited warranty. Such equipment is not eligible for URC tech support or software support, either. 2.
TRG-100 UMOTION REMOTE Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
TRG-100 UMOTION REMOTE Declaration of Conformity Company Name : OH SUNG ELECTRONICS CO., LTD.
NOTES Page 12
NOTES Page 13
NOTES Page 14
NOTES Page 15
500 Mamaroneck Avenue, Harrison, NY 10528 Phone: (914) 835-4484 Fax: (914) 835-4532 www.universalremote.
