PVR Remote Control Manual Version 1.
Table Of Contents 1 .Welcome .....................................................................................................................................3 2. Taking Care of your Remote Control ...........................................................................................3 2.1 CLEANING ..............................................................................................................................3 2.2 BATTERIES ..............................................................
1 .Welcome Congratulations on acquiring the new DStv multi-function PVR Remote Control. We are proud to bring you another product at the cutting edge of technology. The PVR Remote Control is essentially a mini hand-held PC and offers significantly more functionality than a normal remote control.
3.
4. What’s New? 4.1 The SHIFT button Quick Summary To access secondary functionality of the keys at the top of the remote control, press SHIFT followed by the required button. The four buttons at the top of the remote control each have a secondary function. Only TV, ALT, TV GUIDE and LANGUAGE buttons are active during normal use. To access the secondary functionality, press SHIFT followed by the required button. After pressing SHIFT, it will flash / blink, confirming the mode of the remote control (ie.
4.2 The Dial Quick Summary RED settings are for TV1. BLUE settings are for TV2. X, Y and X are for controlling Hi-Fi’s and TVs. The dial is used for different TV environments and can be customised for use with the TV and other audio visual equipment in your home. The position of the dial can be seen through the mode window. In the example below, the remote control is in mode 2B. Whenever a button is pressed, the mode window will blink confirming that the command was sent in that mode.
4.2.2 Turning the Dial Place a thumb on each side of the ring (next to the left and right arrow buttons) and push upwards with one thumb. The dial can turn both clockwise and anti-clockwise. 4.3 Blinking Lights Quick Summary Quick blink = OK Slow blink(s) = error SHIFT button blink = advanced mode No blink = invalid button The remote control has various ways of indicating specific conditions.
4.4 Timeouts Quick Summary Don’t worry, if you make an error, it will fix itself. If any button on the remote control is held down continuously for longer than 30 seconds, the remote control will automatically switch off. This is done to conserve batteries if (for example) you sit on the remote control, a book is placed on top of it, etc. Note X If left alone for more than 20 seconds, the remote control will always return to normal operation for the selected mode. 4.
5. Advanced Functionality Please take note of the following important points which are applicable to this section. o Any programming instruction will be abandoned if 20 seconds passes without a button being pressed. o Pressing EXIT will abandon any programming changes and return the remote control to its normal operational mode. Programming a macro is the only exception to this point. o Pressing HELP concludes programming and stores all changes.
Direct set-up 1. 2. 3. 4. 5. Find the 5-digit code for the device from the list provided in this manual (see “Code Tables” from page 22). If there is more than one code listed for the device, start with the first one (they are listed in order of probability). Select the mode (X, Y or Z) that you would like to programme to control the other device. Press and hold the SHIFT button until the mode window blinks 3 times. Enter the 5-digit code using the number buttons on the remote control.
5.2 Volume Redirect Quick Programming Summary Press and hold SHIFT until the mode window blinks 3 times. Press MUTE or V+ or V-. Turn the dial to the mode (X, Y or Z) that you want the volume to be directed to and press HELP to confirm your selection. To toggle between normal and redirected volume, press SHIFT followed by the MUTE or V+ or Vbutton. The SHIFT button will blink instead of the mode window when volume commands are being redirected. 5.2.
5.2.4 Activating and De-activating Volume Redirect TV1 and TV2 modes will independently stay in the selected volume redirect or normal state until changed. To toggle between volume redirect and normal volume functioning, press the SHIFT button before pressing a volume button. While volume redirect is active, the SHIFT button will blink when a volume command is sent, indicating that the volume command has NOT been sent in the currently selected mode.
5.3 Favourite Channels Quick Programming Summary Press and hold SHIFT until the mode window blinks 3 times. Press P+ or P-. Press the number to which you want to assign the favourite channel shortcut. Enter the channel number. Press OK to add another shortcut or HELP to complete the process. 5.3.1 What is this used for? This feature allows you to create a shortcut for 10 of your favourite channels.
5.3.2 Programming Favourite Channels You can set up favourite channels for each of the viewing environments. The settings for TV1 (red mode) will not impact TV2 (blue mode) and vice versa, thus allowing you to set up separate favourite channels for each environment. 1. Next to each number, write down the name and number of the channel for which you wish to create a shortcut.
Note X X Changing one favourite channel will not impact the others you have created. For example, you could change the shortcut on 1 from 36 (M-Net Series) to 35 (kykNET) without impacting any of the other settings. You do not need to set favourite channels in a sequence, ie. you could have favourite channels linked to 1, 3 and 8 only. Tip L If you would like to have the same set of favourite channels in the other TV environment, see the “Copy Environment” section on page 20. 5.3.
5.4 Macros Quick Programming Summary Press and hold SHIFT until the mode window blinks 3 times. Press the WHITE button. Press the colour button to which you want to assign the macro. Enter the command sequence. Press HELP to complete the process. 5.4.1 What is this used for? A macro is used to store a series of commands that you use regularly, for example : you check the 5-day weather forecast for Cape Town every day. You can store the commands and then recall them using a macro.
Setting a Macro 1. We recommend that you first test the button sequence you want to record and make a note of the total number of commands (keeping in mind that a macro can only be recorded for 8 or fewer commands). Remote control button Example WHITE Macro– TV1 (red mode) What does macro do? Macro– TV2 (blue mode) What does macro do? Go to BBC World Radio1 in the DStv Audio Bouquet Red Blue White Yellow Green 2. 3. 4. 5. 6. 7. 8.
Example 1 Programme a macro on the GREEN button that goes to BBC World Radio 1 in the DStv Audio Bouquet. 1. 2. 3. 4. 5. 6. 7. 8. 9. 10. 11. Use the dial to select the mode (red for TV1 or blue for TV2) that is used to control the PVR where you are now. Press and hold the SHIFT button until the mode window blinks 3 times. Press the WHITE button to indicate that you want to programme a macro. (The mode window will blink 3 times to indicate acceptance). Press the GREEN button.
Example 2 Programme a macro on the RED button to switch on all the equipment and set the environment for watching DStv. Assumptions for this example : The TV has been programmed on the Y mode and uses AV connections. The home theatre is on X mode. The PVR uses input “3” on the home theatre system. You are in the TV1 viewing environment. The PVR is always on. Your favourite channel is 36 (M-Net Series). 1. 2. 3. 4. 5. 6. 7. 8. 9. 10. 11. 12. 13. 14.
5.5 Copy Environment Quick Programming Summary Press and hold SHIFT until the mode window blinks 3 times. Press the RED button to copy TV1 to TV2. Press HELP to complete the process. or Press the GREEN button to copy TV2 to TV1. Press HELP to complete the process. 5.5.1 What is this used for? Both the favourite channels and macros features are only applicable to the TV environment from which they were set.
5.6 Code Verification Quick Programming Summary Press and hold SHIFT until the mode window blinks 3 times. Press the YELLOW button. Press 1 to 5, counting the blinks for each. 5.6.1 What is this used for? The feature allows you to determine the code for a device that you programmed using the “Stepand-Set” method (see page 10). This code can then be used in future. 5.6.2 How to verify a code The device codes for X, Y or Z modes can be verified as follows : 1. 2. 3. 4. 5. 6. 7. 8.
6 . Code Tables This section lists the codes that can be used as explained in “Direct Set-up” (see page 10). Codes are listed in order of probability for each make. If you are unable to find a code for your make of equipment, we recommend the “Step-and-Set” method (see page 10). 6.1 Codes for Televisions 888 A.R.
Allorgan Allstar Ambassador America Action Amplivision Amstrad Anam Anam National Anglo Anhua Anitech Ansonic AOC Aolingpike Aolingpu Apex Digital Apollo Arcam Ardem Aristona ASA Asberg Asora Astra Asuka ATD Atlantic Atori Audinac Audiosonic Audioton Audiovox Aumark Autovox AVP AWA Axxent Axxon Baihe Baile Baird 00236 00324 00247 00067 00586 00207 00210 00247 00039 00207 00067 00546 00294 00392 00401 00248 00442 00463 00586 00611 01934 00067 00586 00039 00210 00191 00891 00067 00191 00586 00680 00085 00039
Bang & Olufsen BaoHuaShi Baosheng Barco Basic Line Bastide Bauer Baur Baysonic Beaumark Beijing Beko Belcor Bell & Howell Bennett Beon Best Bestar Binatone Black Diamond Black Panther Black Strip Blacktron Blackway Blaupunkt Blue Sky Blue Star Bondstec Boots Bosch BPL Bradford Brandt Brandt Electronique Brinkmann Brionvega Britannia Brockwood Broksonic Brother Bruns BSR BTC 00595 00117 00294 00442 00039 00847 00193 00039 00404 00067 00248 00193 00698 00586 00312 00247 00485 00369 01698 00247 00835 00039 00
Bush Caihong Cailing Caishi Candle Canton Capsonic Carad Carnivale Carrefour Cascade Casio Cathay CCE Celestial Centrex Centurion Century CGE Changcheng Changfei Changfeng Changhai Changhong Chengdu Ching Tai Chun Yun Chunfeng Chung Hsin ChungFeng Chunsun Cimline Cinema Cineral Citizen City Clarion Clarivox Clatronic CMS CMS hightec Combitech 00039 00698 00066 00248 00067 00193 00302 00312 00385 00401 00265 00404 00728 00294 00391 00517 00238 00247 00647 00611 00324 00314 00586 00744 01930 01934 01938 016
Concerto Concorde Condor Conia Conic Conrad Conrowa Contec Continental Edison Cosmel Craig Crosley Crown Crown Mustang Crystal CS Electronics CTC Curtis Mathes CXC CyberHome Cybertron Daewoo Dainichi Danichi Dansai Dansette Dantax Datsura Dawa Daytek Dayton Daytron Dayu de Graaf DEC Decca Deitron Denon Denver DER Desmet Diamond 00086 00039 00067 00400 00586 00246 00039 00312 00132 00277 00448 00441 00193 00294 00784 00851 00062 00067 00586 00039 00294 00442 00726 00728 00783 00039 00210 00246 00066 00187
Digatron Digiline Digitor Dixi DL Dongda Donghai DSE DTS Dual Dual Tec Dumont Dunai Durabrand Dwin Dynatron E-Elite Ecco ECE Ectec Edison-Minerva Elbe Elbe-Sharp Electroband Electrohome Elekta Elektra Elin Elite Elta Emco Emerson Envision Enzer Epson Erres ESC EstFle Ether Etron Eurofeel EuroLine Euroman 00067 00067 00586 00135 00698 01698 00067 00586 00918 00039 00067 00586 00277 00247 00117 00878 00921 00902 00810 00067 00039 00039 00918 00039 00574 00247 00067 00586 00289 00382 00193 01934 00247 00047
Europa Europhon Expert Fagor Family Life Feilang Feilu Feiyan Feiyue Fenner Ferguson Fidelity Filsai Finlandia Finlux Firstar Firstline Fisher Flint FNR Formenti Formenti-Phoenix Fortress Fraba Friac Frontech Fujitsu Fujitsu General Funai Furi Futronic Future Futuretech Galaxi Galaxis Galeria Ganxin GBC GE 00067 00586 00067 00546 00132 00193 00247 00586 00277 00461 00246 00236 00289 00193 00067 00586 00067 00586 00039 00039 00847 00294 00442 00039 00847 01074 00404 00039 00067 00139 00655 00220 00317 0036
GEC Geloso General General Electric General Technic Genesis Genexxa Giant Gibralter Gintai Goldfunk Goldline GoldStar Gooding Goodmans Gorenje GPM Gradiente Graetz Granada Grandin Grundig Grunpy Haaz Haier Haihong Haiyan Halifax Hallmark Hammerstein Hampton Hanimex Hankook Hanseatic Hantarex Hantor Harley Davidson Harsper Harvard 00067 00193 00073 00391 00102 00247 00546 00586 00039 00277 00193 00404 00216 00620 00139 00317 00501 00317 00039 00039 00067 00586 00193 00248 00067 00586 00442 00039 00247 000
Harwood Hauppauge Havermy HCM Hedzon Hello Kitty Hema Highline Hikona Himitsu Hinari Hisawa HISense Hit Hitachi Hitachi Fujian HMV H˜her Hongmei Hongyan Hua Tun Huafa Huanghaimei Huanghe Huanglong Huangshan Huanyu Huaqiang Huari Huodateji Hyper Hypersonic Hypson Hyundai Iberia ICE Ices Imperial Imperial Crown 00039 00442 00062 00067 00586 00517 00067 00586 00123 00039 00312 00442 00067 00586 00247 00248 00448 00294 00586 00067 00481 00247 00039 00294 00067 00586 00504 00248 00210 00809 00039 00238 00066 0
Indiana Ingelen Inno Hit Innova Inteq Interactive Interbuy Interfunk Internal International Intervision IRT Isukai ITC ITS ITT ITT Nokia ITV Jean JEC Jensen Jiahua Jialicai Jinfeng Jinhai Jinque Jinta Jinxing JMB Jubilee Juhua JVC Kaige Kaisui Kamp Kangchong Kanghua Kangli Kangyi Kapsch 00067 00586 00193 00517 00640 00744 00391 00039 00102 00546 00067 00586 00248 00320 00247 00277 00132 00312 00067 00047 00067 00586 00042 00117 00542 00357 00193 00391 00400 00139 00441 00039 00067 00294 00277 00542 00586 0
Karcher Kathrein Kawasho KB Aristocrat KEC Kendo Kennedy Kenwood KIC Kingsley Kiota Kioto Kiton KLL Kneissel Kolin Kolster Kongque Konichi Konka Kontakt Korpel Kosmos Kotron Koyoda Kriesler KTV Kuaile Kuba Kuba Electronic Kulun Kunlun Kyoshu Kyoto LaSAT Leader Lecson Legend Lemair Lenco Lesa Levis Austria 00067 00586 00451 00400 00640 00193 00312 00132 00294 00744 00586 00067 00246 00193 00210 00067 00640 00265 00392 00586 00193 00542 00400 00407 00441 00132 00277 00193 00236 00049 00060 00135 00247 00359
Leyco LG Liesenk & Lifetec Lihua Lloyd's Lloytron Loewe Logik Logix Longjiang Luma Lumatron Luxman Luxor LXI Madison Magnadyne Magnafon Magnavox Magnum Mandor Manesth Manhattan Marantz Mark Maruman Masuda Materin Matsui Matsushita Matsuviama Maxam MCE McMichael Mediator Medion Megas Megatron MEI 00067 00294 00102 00586 00324 00609 00067 00086 00472 00031 00400 00032 00039 00407 00062 00586 00247 00049 00060 00744 00068 00246 00439 00461 00320 00504 00193 00674 00090 00208 00636 00139 01964 00728 01408 00
Meile Melectronic Memorex Memphis Mercury Metronic Metz MGA Micromaxx Microstar Midland Minato Minerva Minoka Mirror Mitsubishi Mitsuri General Mivar Monaco Morgan's Motorola MTC MTEC Mudan Multitec Multitech Murphy Myryad NAD Naiko Nakimura Nanbao Nansheng Naonis NAT National NEC Neckermann NEI 00294 00442 00847 00878 01940 00039 00376 00067 00542 00134 00139 00193 00277 00135 00247 00317 00404 00510 00246 00441 00586 00664 00391 00225 00039 00086 00184 00208 00209 00090 01954 00367 00102 00039 00031 00
Nesco Netsat Network Neufunk New Tech Newave Nfren Nicam Nicamagic Nikkai Nikko Nikon Nisato Noblex Nobliko Nokia Norcent Nordmende Norfolk Normerel Novak Novatronic NTC NU-TEC Oceanic Odeon Omega Omni Onwa Optimus Optonica Orbit Orion Orline Ormond Orsowe Osaki Osio Oso Osume Otto Versand 00209 00277 01938 00067 00586 00062 00367 00067 00039 00586 00640 00248 00312 00744 00067 00039 00586 00247 00478 00039 00751 00676 00208 00191 00123 00122 00830 00574 00246 00676 00062 00102 00065 00248 00067 00586 002
Pace Pacific Pael Palladium Palsonic Panama Panashiba Panasonic Panda Pathe Cinema Pathe Marconi Pausa Peng Sheng Penney Perdio Phase Philco Philex Philharmonic Philips Phoenix Phonola Pilot Pioneer Pionier Plantron Playsonic Plus Policom Polytron Poppy Portland Powerpoint Prandoni-Prince Precision Premier Prima 01938 00067 00586 00744 00246 00400 00448 00067 01535 00230 00586 00277 00357 00117 00193 00247 00441 00744 00294 00314 00442 00803 00067 00809 00247 00407 00248 00728 00586 00478 00518 00031 00
Princess Prinz Prism Profex Profi Profitronic Proline Proscan Prosonic Protech Proton Provision Pulsar Pye Pymi Qingdao Qualcraft Quasar Quelle Questa R-Line Radiola Radiomarelli RadioShack Radiotone Rank Arena RCA Realistic Recor Rectiligne Rediffusion Redstar Reflex Relisys Reoc Revox Rex Rhapsody Ricoh Roadstar 00728 00102 00574 00391 00081 00039 00193 00391 00461 00039 00067 00586 00132 00067 00351 00586 00655 00664 00441 00042 00102 00777 00060 00067 00586 00400 00404 00401 00698 00744 00481 00246 00
Robotron Rodex Rowa Roxy Royal Lux Rukopir Runco Ruyi Saba Sagem Saige Saisho Saivod Sakan Sakyno Salora Salsa Sambers Sampo Samsung Samsux Sandra Sanjian Sansei Sansui Santon Sanyo Sanyuan Save Saville SBR Schaub Lorenz Schneider Scimitsu Scotch Scotland Scott 00117 00067 00586 00067 00294 00728 00039 00247 00742 00246 00617 00778 00847 00478 00451 00400 00442 00365 00586 00067 00047 00060 00257 00847 00139 00655 00193 00317 00365 00117 00546 00391 00528 00578 00501 00590 00744 00640 00485 00312 00039 0
Sears Seaway SEG SEI Sei-Sinudyne Seleco Semivox Sencora Sentra Shancha Shanghai Shaofeng Sharp Shen Ying Shencai Sheng Chai Sheng Chia Shenyang Sherwood Shintoshi Shivaki Shogun Show Siarem Siemens Siera Siesta Silva Silver Simpson Singer Sinotec Sinudyne Skantic Sky Skygiant Skymaster Skysonic Skyworth SLX Smaragd Solavox 00176 00777 00086 00184 00208 00209 00664 00066 00067 00247 00586 00294 00698 01467 01698 00517 00039 00193 00664 00132 00277 00392 00246 00248 01939 01931 00117 00132 00207 00546 01535
Sonawa Songba Soniko Sonitron Sonoko Sonolor Sontec Sony Sound & Vision Soundesign Soundwave Sowa Spectra Ssangyong SSS Staksonic Standard Starlite Stenway Stern Strato Stylandia Sunic Line Sunkai Sunstar Sunwood Superla Supersonic SuperTech Superton Supra Susumu Sutron SVA Sydney Sylvania Symphonic Synco Sysline Sytong T+A Tacico Tactus Tai Yi Taishan 00248 00039 00067 00586 00238 00400 00369 00247 00039 00067 00586 00294 00312 00247 00193 00238 00067 00586 00400 00324 00039 01535 00041 00066 00680 00132
Tandberg Tandy Tashiko Tatung TCL TCM Teac TEC Tech Line Techica Technics TechniSat Technol Ace Techwood Teco Tedelex Tek Teknika Telefunken Telefusion Telemeister Telesonic Telestar Teletech Teleton Televideon Teleview Telexa Tempest Tensai Tenson Tera Tesla Tevion Texet Thomas 00397 00441 00139 00367 00392 00391 00193 00069 00248 00102 00123 00247 00193 00277 00066 00751 00073 00247 00680 00063 00176 00122 00062 00246 00193 00085 00039 00066 00067 00586 00081 00102 00546 00090 00247 00184 00302 00041 00
Thomson Thorn Thorn-Ferguson Tiane TMK TNCi Tobishi Tobo Tokyo Tomashi Tongguang Tongtel Tophouse Toshiba Totevision Towada Toyoda Trakton Trans Continens Transonic Triad Trical Trident Tristar Triumph Tuntex TVTEXT Uher Ultra Ultravox Unic Line United Universum Univox Utax Vector Research Vestel Vexa Vibrant Victor Video Concepts Videologic 00139 00655 00317 00590 00501 00365 00067 00586 00604 00065 00067 00139 00102 00255 00104 00134 00220 00391 01535 00308 00529 00542 00565 00586 00041 00042 00365 000
Videosat VideoSystem Videotechnic Videoton Vidikron Vidtech Viper Visiola Vision Vistar Vortec Voxson Waltham Wards Warumaia Watson Watt Radio Wega Wegavox Weipai Weltblick Welttech Weston Wharfedale White Westinghouse Windstar Windy Sam Wintel Worldview Xenius Xiahua Xianghai Xiangyang Xihu Xinaghai Xingfu Xinghai Xingyu Xinrisong Xinsida XLogic Xrypton Xuelian Yamaha Yingge 00277 00067 00586 00247 00386 00193 00461 00132 00049 00066 00208 00367 00246 00062 00067 00294 00586 00504 00247 00518 00236 00391
Yokan Yoko Yongbao Yonggu Yorx Youlanasi Yousida Yuhang Zanussi Zenith Zenor Zhuhai Zonda ZX 00067 00586 00067 00247 00294 00586 00248 00039 00461 00451 00400 00369 00246 00277 00878 01940 00039 00248 00847 00039 00878 01940 00039 00236 00247 00047 00122 00208 01939 00369 00039 00404 00728 00809 00314 01938 6.
Curtis Mathes Creative Cyrus Daewoo Dantax Denon Diamond DMTECH Dual Elektra Elta Eroica Firstline Fisher Fujitsu Siemens Garrard Genexxa Goldmund GoldStar Goodmans GPX Grundig Harman/Kardon Harwood Heco Hitachi HiTo Hypson Hyundai Inkel Intersound JBL JVC Kenwood Kinyo Koss Krell Kysho Kysho Japan Lenoxx Lenoxx Sound LG Lifetec Linn 10110 11501 10563 11470 10437 11280 11466 10761 11390 10034 10801 10302 10761 11420 10437 10854 11250 11420 10034 10718 10774 10827 11420 10470 10437 10390 10249 10831 10874 1
Lloyd's Loewe LXI Marantz Mark Mark Levinson Matsui McIntosh MCS MEI Melectronic Meridian Micromega Midiland Mitsubishi Minton Modulaire Musical Fidelity Myryad NAD Naim Nakamichi Nikkai Nikkei Nordmende NTDE Okano Onkyo Optimus Orient Power Orion Palladium Panasonic Philips Phonotrend Pioneer Prima Electronic Primare Proline Quad Quasar Radiola RadioShack 10225 11119 11219 11319 10774 11119 11219 11319 10249 10921 10672 10650 11504 10351 10922 10671 10859 11119 11219 11319 11033 11513 10827 11158 10225 10
RCA Realistic Reoc Revox Revoy Roadstar Roberts Rotel S.A.T.
Velleman Venturer Victor Videologic Vorx Voxson Wharfedale XMS Yamaha Yorx Yukai Zenith 10809 11063 11155 11420 10104 11125 11557 11618 10470 10639 11420 11496 11277 10206 10112 10216 10742 1136 110173 10384 10878 11624 10225 11382 10311 10774 DStv PVR Remote Control Manual Page 48
7. Complete Table of Functionality 7.
28 29 30 31 32 33 34 35 V- [4] V+ [4] Red (Playlist) Blue (Bookmark) White (SlowMo) Yellow (Status Bar) Green (PVR Menu) Stop 36 Rewind 37 Play / Pause 38 Fast Forward 39 40 41 42 43 44 45 46 47 48 49 REC 1 2 3 4 5 6 7 8 9 MENU 50 51 0 HELP Low Voltage [3] [5] Undefined Rotary position [2] [3] [5] [1] [2] [3] [4] [5] Volume down Volume up Displays the Playlist Sets a Bookmark Watch in slow motion Displays the Status Bar Goes to the PVR Menu Stops the playback of a recording / Stops a recording
7.
28 V- 29 V+ 30 31 35 36 37 38 39 40 Red (Playlist) Blue (Bookmark) White (SlowMo) Yellow (Status Bar) Green (PVR Menu) Stop Rewind Play / Pause Fast Forward REC 1 41 2 42 3 43 4 44 5 45 6 46 7 47 8 48 9 49 MENU 50 0 51 HELP 32 33 34 Low Voltage Undefined Rotary position DStv PVR Remote C
7.
35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 Stop Rewind Play / Pause Fast Forward REC 1 2 3 4 5 6 7 8 9 MENU 0 HELP Low Voltage Fingerprinting Undefined Rotary Position [1] [2] [2] [2] [2] [2] [2] [2] [2] [2] [2] [2] Digit 1 Digit 2 Digit 3 Digit 4 Digit 5 Digit 6 Digit 7 Digit 8 Digit 9 CD DVD SAT TUNER TV VCR 5.
8. Troubleshooting rd 8.1 Close encounters of the 3 blink This remote control communicates through a blinking mechanism. Once you understand the logic behind the speed, position, colour and number of blinks, you will understand what the remote control is “saying”. Blinking location Both the mode window and the SHIFT button can “blink”. (See “What’s New” on page 5).
8.2 Resets 8.2.1 Reset Macros and Favourite Channels To reset the macros and favourite channels for both environments (they cannot be reset individually) follow the steps below : 1. 2. Press and hold the SHIFT button until the mode window blinks 3 times. Press the BLUE button. (The mode window will blink 3 times to indicate successful completion). Devices programmed on X, Y and Z will not be affected. 8.2.
9. Specifications 9.1 Quality o o o CE – EN 61000-6-1 Electromagnetic Compatibility Generic Standard. (Immunity for Residential, Commercial and Light Industrial Equipment). EN 61000-4-2 Electrostatic Discharge Immunity (ESD). EN 61000-4-3 Radiated, Radio Frequency, Electromagnetic Field Immunity test. (Radiated Immunity). 9.2 Battery Life Battery life should be at least nine months assuming 100 button presses per day with each button press lasting 0.5 seconds.
10. Legal Matters & Warranty 10.1 Universal Functionality Disclaimer The universal control functionality of this remote control covers approximately 98% of all TV sets available in the DStv reception area. It is also possible that TV sets manufactured after the database was compiled will not be included. As most new systems make use of existing control methods, chances are very good that an equivalent code will be available. 10.
10.5 Product Warranty Apart from replacing the batteries, you should never attempt to open or service the DStv PVR Remote Control. Any attempt to do so, will invalidate the warranty. The manufacturer and MultiChoice warrant that the DStv PVR Remote Control will be free from defects in design, materials and workmanship for a period of 12 months from the date of sale to the consumer.
11. Hotlines 11.1 Call Centres MultiChoice (South Africa) Call Centres Johannesburg (011) 289 2222 Durban (031) 710 2222 Cape Town (021) 508 2222 Bloemfontein (051) 503 2222 Port Elizabeth (041) 395 2222 Pretoria (012) 422 2222 MultiChoice Africa (Sub-Sahara) Call Centres Sub-Sahara +27 11 289 2266 Swaziland +268 404 2881 / 404 6371 / 404 1786 Botswana +267 360 5666 Malawi +265 1 623505 / 623508 Mocambique +258 21 220217 / 8 Namibia +264 61 270 5222 / 5111 Zambia +260 1 41261616 Zimbabwe +263 4 253325 11.
