READ ALL INSTRUCTIONS

SMOKE & FIRE ALARM WITH SILENCE FEATURE

AND ALARM ORIGINATION FEATURE

Table of Contents:

Page #

Smoke Alarm Limitations and Functions ................................. 2

Recommended Location of Alarms ......................................... 3

Avoid These Locations ........................................................... 4

Early Warning ......................................................................... 4

Installation Instructions ........................................................... 4

Electrical Shock Hazard ......................................................... 4

Locking/Tamper Feature ......................................................... 4

Wiring Instructions .................................................................. 5

Operation, Testing & Maintenance .......................................... 6

QUICK FIND

Alarm Originating Feature & Reset .................. 7

Cautions/Warnings ................................................................. 7

Backup Battery Replacement ................................................. 7

Develop and Practice a Plan of Escape .................................. 8

Operational Summary............................................................. 9

Warranty .................................................................Back Cover

SECURITY INSTRUMENTS, INC.

MODEL 3304, 3304L

MODEL 3895, 3895L

Summary of content (10 pages)

PAGE 1
MODEL 3304, 3304L SECURITY INSTRUMENTS, INC. MODEL 3895, 3895L SMOKE & FIRE ALARM WITH SILENCE FEATURE AND ALARM ORIGINATION FEATURE READ ALL INSTRUCTIONS Table of Contents: Page # Smoke Alarm Limitations and Functions ................................. 2 Recommended Location of Alarms ......................................... 3 Avoid These Locations ........................................................... 4 Early Warning .........................................................................
PAGE 2
SMOKE ALARM LIMITATIONS AND FUNCTIONS            There are three basic smoke alarm types: IoPhic® , Ionization and Photoelectric. IoPhic® is an ionization alarm containing a patent-pending Universal Smoke Sensing Technology.
PAGE 3
RECOMMENDED LOCATION OF ALARMS • Locate the first smoke alarm in the immediate area of the bedrooms. Try to protect the escape route as the bedrooms are usually farthest from an exit. If more than one sleeping area exists, locate additional smoke alarms in each sleeping area. If a hall is more than 40 feet (12 meters) long, install a smoke alarm at each end. • Locate additional smoke alarms to protect any stairway as stairways act like chimneys for smoke and heat.
PAGE 4
AVOID THESE LOCATIONS • the garage – products of combustion are produced when you start your vehicle. • near appliances or areas where normal combustion regularly occurs (kitchens, near furnaces, gas hot water heaters). Use smoke alarms with photoelectric sensors or smoke alarms with Silence Feature for these areas. • in areas with high humidity, like bathrooms or areas near dishwashers or washing machines. Install at least 3 feet (0.9 meters) away from these areas.
PAGE 5
ALARM/BRACKET BATTERY LOCKING 2. Insert the pin into the hole for the feature you are activating. Refer to the diagram below for correct placement. INSERT ALARM LOCKING PIN HERE INSERT BATTERY LOCKING PIN HERE TO DEACTIVATE THE LOCKING FEATURES: To remove the smoke alarm for cleaning or servicing or to replace the battery, you must first remove the appropriate locking pin, if it has been installed. 1. Turn off AC power to the circuit. 2. Use long nose pliers to pull the locking pin out of the hole.
PAGE 6
The yellow wire is used only for multiple station operation with USI ELECTRIC or UNIVERSAL Model alarms only. Connecting this yellow wire to any other circuits may result in damage and smoke alarm malfunction. When alarms are interconnected, all smoke alarms must be powered from a single AC branch circuit. If local codes do not permit, be sure the neutral wire is common to both phases. The maximum wire run distance between the first and last alarm/device in an interconnected system is 1,000 feet.
PAGE 7
b. c. Interconnected alarms will sound and then stop. The originating smoke alarm will continue to sound 60 seconds to allow ample time to quickly find originating alarm. RESET: To reset the QUICK FIND® Alarm Origination condition, press and hold the Test button on any alarm for at least 10 seconds and then release. Reset after each alarm. The reset feature will reset all interconnected units.
PAGE 8
OPTIONAL BATTERY DRAWER TAMPER LOCKING PIN: To make your battery drawer tamper resistant, a locking pin has been provided (breakaway part on mounting bracket). NOTE: If this feature has been activated, you will need to deactivate it by removing the battery drawer tamper pin located at side of battery drawer. Refer to Page 5. Pull the QUICK DRAW(R) battery drawer open and remove the battery. While observing polarity, push the replacement battery into the battery drawer until it is held securely in place.
PAGE 9
OPERATIONAL SUMMARY CONDITION OF ALARM AUDIBLE & VISUAL SIGNALS BEFORE SOLUTION / RECOMMENDATION HORN RED LED SOLUTION / RECOMMENDATION GREEN LED AC Power is present. DC Power is present. Silent Blinks On once approx every 40-45 seconds Stays On Silent Blinks On once approx every 40-45 seconds Off AC Power is not present and alarm is receiving DC Power. Check the breaker or fuse box for power. If the breaker or fuse box looks normal, call a licensed electrician for assistance.
PAGE 10
FIVE YEAR LIMITED WARRANTY MODELS 3304, 3304L MODELS 3895, 3895L USI ELECTRIC, INC./UNIVERSAL SECURITY INSTRUMENTS, INC. ("USI") warrants your USI product to be free from defects in material and workmanship for a period of five (5) years from the date of purchase. This warranty shall not apply to any batteries used in the product or to any damage which may be caused by such batteries.
