Instruction manual

4509/45 10/45 12
the machine is not in use, the slice adjustment knob should be turned fully back
to the closed position (beyond "0") so that the knife edge is not exposed.
Observe the cleaning instruction on Page 6 for best results and for safety. Also
remember to always turn off the slicer and disconnect the electrical supply cord
before cleaning.
When slicing, always work the carriage using only the carriage arm handle
(Figure 1 [8]). Do not hold or push the carriage from any other place.
OPERATION INSTRUCTIONS
The Univex slicer is designed to meet the cook's demand for an efficient, sturdy slicer. The
Univex slicer will give unfailing performance over a period of years, when operated and
maintained according to instructions contained herein.
START/STOP SWITCH
The slicer is started by toggling the ON/OFF switch (Figure 1 [10]) to the ON position.
SLICE ADJUSTMENT
Warning: Dial-type knob adjustment (Figure 1 [9]) allows for slice thicknesses ranging
from paper thin up to 1/2". Dial graduations allow you to precisely set up
specific slice thicknesses for various needs. When not in use, always return
knob back to its fully closed position (beyond "0") so that the knife edge is not
exposed.
POSITIVE HOLD CARRIAGE
Caution: A last slice gravity feed grip (Figure 1 [5]) is provided. Do not use this last slice
device to work the carriage back and forth. Use only the carriage arm handle
(Figure 1 [8]).
Always make sure the carriage is positively secured to the slicer by checking to
see that the carriage arm knob (Figure 1 [7]) is fully tightened. Failure to do
this could result in the carriage striking and damaging the knife edge.
PROTECTIVE GUARD
Warning: The protective guard (Figure 1 [4]) covers the knife edge completely except
under the sharpener cover and the forward edge where slicing will be performed.
This forward edge is covered by the edge of the fence, but only when the slice
adjustment is completely closed.
The knife guard (Figure 1 [3]) can be removed for cleaning by unscrewing the
knife guard knob (Figure 3 [11]). For safety, keep the knife guard on at all
times except when cleaning. Never operate the slicer with the knife guard
removed.
Page 4
