Specification

20-hr. (0.45A)
10-hr. (0.83A)
5-hr. (1.54A)
1-hr. (5.40A)
Absorbant Glass Mat (AGM) technology for superior performance. Valve regulated, spill proof construction allows safe
operation in any position. Approved for transport by air. D.O.T., I.A.T.A., F.A.A. and C.A.B. certied.
Sealed Lead-Acid Battery
L: 5.94 in (151 mm)
W: 2.56 in (65.0 mm)
H: 3.78 in (96.0 mm)
TH: 4.06 in (103 mm)
Tolerances are +/- 0.04 in. (+/- 1mm)
and +/- 0.08 in. (+/- 2mm) for height
dimensions. All data subject to
change without notice.
488 S. Royal Lane Coppell, Texas 75019 P 469.892.1122 T 866.892.1122 F 469.892.1123 [e-mail]
www.upgi.com
Nominal Voltage
Nominal Capacity
Approximate Weight
Internal Resistance (approx.)
Shelf Life (% of normal capacity at 68º F (20º C)
3 Months 6 Months 12 Months
12 volts
9.00 Ah
77º F (25º C)
8.30 Ah
7.69 Ah
5.40 Ah
5.17 lbs (2.35 kgs)
19mΩ
91% 83% 64%
2.7 A or smaller
14.6 - 14.8 V
Charge Method (Constant Voltage)
Cycle Use
Float Use
Initial Current
Control Voltage
13.6 - 13.8 V
Control Voltage
(Repeating Use)
Specification
Physical Dimensions: in (mm)
Terminals
L1713-1
All specifications are subject to change without notice.
UPG No. 40749
Maintenance-Free
UB1290
2.56 (65.0)
5.94 (151)
3.78 (96.0)
4.06 ( 103)
5MIN
33.7
31.6
29.7
10MIN
21.1
19.8
18.6
15MIN
16.7
16.0
15.1
30MIN
9.8
9.4
8.9
1HR
5.8
5.6
5.3
3HR
2.3
2.3
2.2
5HR
1.6
1.5
1.5
10HR
0.8
0.8
0.8
20HR
0.45
F.V/Time
9.60V
10.20V
10.50V
5MIN
369
351
331
10MIN
237
225
212
15MIN
189
182
174
30MIN
109
106
102
1HR
66.5
63.8
61.0
3HR
27.1
26.7
26.2
5HR
18.5
18.3
17.9
10HR
10.1
10.0
9.6
20HR
5.4
F.V/Time
9.60V
10.20V
10.50V
Constant Current Discharge Characteristics Unit:A (25°C, 77°F)
Constant Power Discharge Characteristics Unit:W (25°C, 77°F)
Temperature Dependancy of Capacity
104 F (40 C) 77 F (25 C)
(20 hour rate)
102% 100% 85%
32 F (0 C) 5 F (-15 C)
65%
AGM Operational Temperature
AGM Storage Temperature
(0 C to 40 C)32 F to 104 F
5 F to 113 F
5 F to 104 F
(-15 C to 45 C)
Charge
Discharge
(-15 C to 40 C)
Copyright 2017 Universal Power Group. All rights reserved.
Due to continuous improvements to our products, product may vary slightly from depiction.
