ZXR105900/5200SeriesUserManual(EthernetSwitchingVolume)
ConfiguringVLAN
Translation
Step
CommandFunction
1
ZXR10(config)#vlantranslatesession-no
<session_id>ingress-port<interface-name>
ingress-vlan<vlan-list>egress-vlan<vlanId>
ThisconguresVLAN
Translation.
2
ZXR10(config)#showvlantranslate
Thisviewstheconguration
ofVLANTranslation.
3
ZXR10(config)#vlanegr-translatesession-no
<session_id>egress-port<interface-name>
egress-vlan<vlan-list>ingress-vlan<vlanId>
ThisconguresVLAN
egr-translation.
ExamplePortgei_1/1receivesapacketwhichbelongstovlan100.This
packetistobesenttoxgei_2/1.Portxgei_2/1belongstoVLAN
200.Asforthedownlinkdata,usershopethatVLAN200for-
wardedfromxgei_2/1isconvertedtoVLAN100.
Thedetailedcongurationisasfollows:
Congurationofswitch:
ZXR10(config)#vlantranslatesession-no1
ingress-portgei_1/1ingress-vlan100egress-vlan200
ZXR10(config)#vlanegr-translatesession-no1
egress-portgei_1/1egress-vlan200ingress-vlan100
ZXR10(config)#interfacegei_1/1
ZXR10(config-gei_1/1)#ingressfilteringdisable
ZXR10(config-gei_1/1)#switchportmodehybrid
ZXR10(config-gei_1/1)#switchporthybridvlan100,200
ZXR10(config-gei_1/1)#exit
ZXR10(config)#interfacegei_2/1
ZXR10(config-gei_2/1)#switchportmodehybrid
ZXR10(config-gei_2/1)#switchporthybridvlan200
ZXR10(config-gei_2/1)#exit
ConfiguringSuperVLAN
Step
CommandFunction
1
ZXR10(config)#interface{supervlan<supervlan-id
>|<supervlan-name>}
ThiscreatesaSuperVLAN.
2
ZXR10(config-vlanX)#supervlan<supervlan-id>Thisaddssub-VLANsonto
SuperVLAN.
3
ZXR10(config)#supervlaninter-subvlan-routing
{enable|disable}
Thisenables/disablesrouting
functionamongsub-VLANs.
4
ZXR10#showsupervlanThisviewsSuperVLAN
congurationinformation.
ExampleAsshowninFigure5,congureaSuperVLANonswitchA,withits
subnetas10.1.1.0/24andgatewayas10.1.1.1.Conguretwo
14CondentialandProprietaryInformationofZTECORPORATION
