A-9
Appendix
Paper
This section explains the paper sizes and types that can be used in the paper source.
Cassettes 1
Cassettes 2 and the optional paper feeder (500-sheet x 2)
Optional large capacity feeder (1,500-sheet x 2)
Multi Purpose tray (MP tray)
Supported paper sizes No. of sheets
A3, B4, A4, A4-R, B5, B5-R, A5-R, Ledger, Legal, Oficio II, 12 × 18", Letter,
Letter-R, Statement-R, Folio, 8K, 16K, 16K-R
216 × 340 mm
550 (64 g/m
2
)
500 (80 g/m
2
)
Supported paper sizes No. of sheets
A3, B4, A4, A4-R, B5, B5-R, A5-R, Ledger, Legal, Oficio II, 12 × 18", Letter,
Letter-R, Statement-R, Folio, 8K, 16K, 16K-R
216 × 340 mm
550 (64 g/m
2
)
500 (80 g/m
2
)
Supported paper sizes No. of sheets
A4, B5, Letter 3,500 (64 g/m
2
)
3,000 (80 g/m
2
)
Supported paper sizes No. of sheets
A4, A4-R, B5, B5-R, A5-R, B6-R, A6-R, Letter, Letter-R, Executive-R,
Statement, Folio, 16K, 16K-R
Other sizes:
Portrait - 3 7/8 to 11 5/8" or 98 to 297 mm
Landscape - 5 7/8 to 17" or 148 to 432 mm
165 (64 g/m
2
)
150 (80 g/m
2
)
A3, B4, Ledger, Legal, Oficio II,
12 × 18", 8K
55 (64 g/m
2
)
50 (80 g/m
2
)
Postcards (100 × 148 mm)
Return postcard (148 × 200 mm)
30
Envelope DL, Envelope C5, Envelope C4, Envelope #10 (Commercial #10),
Envelope #9 (Commercial #9),
Envelope #6 (Commercial #6 3/4), Monarch, ISO B5, Youkei 2, Youkei 4
Other sizes:
Portrait - 3 7/8 to 11 5/8" or 98 to 297 mm
Landscape - 5 7/8 to 17" or 148 to 432 mm
10
Transparency (OHP film) (A4, A4-R, Letter, Letter-R) 10
